Vivotek AM-105 Manuel utilisateur

IP Surveillance

Installation Guide

VIVOTEK Fixed Dome Series

AM-105 Recessed-mount Bracket

Rev. 1.0

Corresponding part number: 900026800G

2

AM-105 Recessed-mount Bracket Mechanical Drawing

205

146

90

66.2

71.5

Compatible VIVOTEK Cameras

I

Fixed Dome series FD8167, FD8138-H

You may also refer to VIVOTEK's website for the list of supported models. Support for other models can

be available through time.

77.3°

5M

121°

5M

Before installing your camera, make sure the built-in PIR (Passive Infrared Sensor) can be

directed toward the area of interest, where possible intrusion may occur. (The sensitivity

of PIR sensor depends on the object size and temperature differences between the object

and the background environment.)

Top View Side View

IMPORTANT:

Package Contents

• Recessed-mount bracket

• Screws: 3x round head M4x8L; 3x truss head

M3x8L .

• 3x adhesive foam washers

• Alignment sticker

Revision History

• Rev. 1.0: Initial release.

• Screwdriver: T10 stardriver

3

English

Installation

II

190mm

24mm

Up to

Ceiling Hole Template Sticker

186mm

Mounting Hole Denitions

1. Determine a secure location for the recessed-mount bracket.

2. Drill or cut a 190mm hole (in diameter). The maximum thickness of the ceiling/board is

24mm. The ceiling should be able sustain at least a weight of 1.4kg.

3. Remove dome cover from the

camera using the stardriver

included in kit.

4

5-1. Install camera to the recessed-mount bracket by driving 3 screws.

4. Use the included stardriver to detach the dome cover from the recessed mount bracket.

FD8182, FD9171-HT, FD9181-HT, FD816B

5

English

NOTE:

1. Connect and route cables before you secure the recessed-mount bracket to a ceiling.

2. For details on the cable connections with each camera, please refer to their Quick

Installation Guide.

FD8167 and FD8138-H

5-2. Attach foam washers to the top of

screw holes.

5-3. Install camera to the bracket.

Foam washers • 3x round head M4x8L

6

7. Use a #2 Phillips screwdriver to loosen the clamping plates (see drawing below) and

insert the recessed-mount bracket through the hole in the ceiling.

6. Pass cables through the routing hole and connect cables to the camera.

7

English

8. Use a #2 Phillips screwdriver to move the clamping plates down so that the ceiling/

boardiscaughtbetweentheclampsandtheangeontheothersideoftheceiling.

Clockwise Counter-

clockwise

9. Adjust shooting angle and check for a satisfactory image over a web session. When

you have a satisifactory live view, tighten the tilt screw, and secure the dome cover

from below the ceiling using the T10 stardriver.

8

10. You are done with the installation.
