PORTABLE MP3/WMA PLAYER WITH FM RADIO

MODEL VT3794 SR

INSTRUCTION MANUAL

www.vi ekaus.com

3794A.qxd 08.07.2005 9:04 Page 1

ACCESSORIES/АКСЕССУАРЫ

3794A.qxd 08.07.2005 9:04 Page 2

3794A.qxd 08.07.2005 9:04 Page 3

NAMES OF CONTROLS & INDICATORS

1 LCD WINDOWS LCD WINDOWS

2 MIC MIC

3 MENU Enter Menu to manage the player

4 PLA /PAUSE Power On/Play/pause/power off

5 STOP Stop/exit

6 LINE IN JACK Connect to external audio source

7 STRAP HOLE Connect with the necklace

8 SD/MMC SLOT External SD/MMC Card

9 EARPHONE JACK Connect to Earphone

10 VOLUME + Increase the volume level

11 VOLUME  Decrease the volume level

12 USB JACK Connect player to computer

13 BATTER DOOR Place "AAA" Battery

14 NEXT Skip forward to next track

15 PREV Skip backward to previous track

16 HOLD Key Lock or Key Release

ACCESSORIES

1. Installation CD

2. Stereo Earphone

3. User Manual

4. USB Cable

5. "AAA" Battery (included)

Environment type battery

6. Linein Cable

ENGLISH

3794A.qxd 08.07.2005 9:04 Page 4

LCD DISPLAY INFORMATION

1. Track number

2. E: External memory card in used.

3. Equalizer: Normal Rock Jazz Classic POP User EQ

4. Folder Name

5. Time of current song

6. Play Mode Setting: Normal 1 Repeat 1 Normal Repeat all

7. Hold

8. Battery Status

9. File Format

10. File decoding sampling rate

11. File compress bits rate

12. Song title

13. Music level display bar

ENGLISH

3794A.qxd 08.07.2005 9:04 Page 5

GETTING PLAYBACK STARTED

1. POWER ON/OFF

POWER ON  Press "PLA /PAUSE" to switch on the power; the "MP3 Player" logo will be displayed on

the LCD.

POWER OFF  Press and hold "PLA /PAUSE" over 2 seconds to power off when the unit in stop mode.

CAUTION: Don' t remove the battery while the player is Power On, it will damage the firmware & the

Player.

2. PLAYING START

Press "PLA /PAUSE" button once, it will play the track.

3. FAST TRACKING

While the track is being played, press and hold "PREV" or "NEXT" for fastforward or backward the

track.

4. SKIP / RETURN TRACKING

Press "NEXT" to skip forward to the next track.

Press "PREV" to skip backward to the previous track.

5. DIGITAL VOLUME CONTROL

To adjust the volume, press "VOLUME +" to increase the volume or press "VOLUME " to decrease the

volume.

6. PAUSING PLAYBACK

While the track is being played, press "PLA / PAUSE" for pausing the playback.

Press "PLA /PAUSE" button again to start playback.

7. STOPPING PLAYBACK

Press "STOP" button for stopping the playback.

8. HOLD FUNCTION

Slide "HOLD" button to key lock

9. LOW BATTERY INDICATOR

Indicates high battery level .

Indicates medium battery level .

Indicates low battery level .

Indicates that the battery level is empty and the player need to replace a new battery.

10. EXT.MMC/SD/CARD USAGE

Inserted MMC/SD Card to Card Slot.

"EXTERNAL DISK WAS INSERTED" indicated.

ENGLISH

3794A.qxd 08.07.2005 9:04 Page 6

Press "MENU" and hold for 2 second to change external memory card.

The total number of music file will be shown.

Press "PLA /PAUSE" to start play, or press "MENU" with "+" / "" button to browse other folder.

Press "MENU" and hold 2 second return to internal memory.

"Chang drive NAND" will be shown in Display.

CAUTION

In case of using unqualified SD/MMC/USB device or by some electrical shock this unit may be locked.

ollow procedure described as below to settle:

1. Position LOCK switch ON

2. While press VOL-button, press POWER key shortly

3. Confirm message is displayed

4. By pressing PLAY button, formatting is start and all function will be normal

11. DELETE FILE

Press "STOP" to stop playback file.

Press "PREV" or "NEXT" to select file to delete.

Press "STOP" and hold 2 second until display "Delete ES: Play".

Press" PLA /PAUSE" to confirmed other key to abort.

OPERATING THE FM RADIO

1. ENTER TO THE FM RADIO MODE

While playing in [Music Mod], press "MENU" and select the [FM Mode] with "+" or " ".

Press "MENU" to enter the Radio Mode.

Please make sure that the earphone is connected to the MP3

Player it is because the earphone wire is the antenna of FM radio.

2. AUTO SCANNING THE WHOLE FM BAND

While in [FM MODE] and press "MENU".

Press "PREV" or "NEXT" button for select [AUTOSCAN].

Press "PLA /PAUSE" to start auto scan.

First 20 FM station detected will be stored in the preset memory.

3. How o save desired FM band in Memory Channel

While in [FM MODE], press "MENU" with "PREV" or "NEXT" button for selecting [CH SAVE].

Adjust the channel position by passing "NEXT" AND "PREV".

Save the Frequency into the memory channel by press "PLA /PAUSE".

4. FM RECORDING

ENGLISH

3794A.qxd 08.07.2005 9:04 Page 7

In [FM MODE] Press the "STOP" button for FM Recording.

The file name "FMRCXXX" will be shown on the display.

The player will enter the "FM Recording Mode" and it will start recording automatically.

Press "STOP" button again for stopping the recording.

5. PLAYBACK THE RECORDED FILE

Press "STOP" button again for stopping the recording.

Press "MENU" button with "+" or "" button to select [MUSIC MODE] on the LCD display.

Press "MENU" button for confirming the selection.

The player will back to the "Music MODE".

Select the saved FM file with "PREV" or"NEXT".

Press "PLA /PAUSE" for playback the saved FM file.

6. RETURN TO THE MUSIC MODE

Press "MENU" button with "PREV" or "NEXT" for select [EXIT FM MODE].

Press "PLA /PAUSE"button for retuning to "Music Mode".

CAUTION: Please note that the better receiving audio will have better effect when saved M band in

the memory channel.

REMARK: FM radio receiving quality will be affected by the location.

Make sure the location can be received FM broadcast signal.

VOICE RECORDING AND ENCODING SETTING

ou can record the message by the builtin microphone. This player also includes WMA encoding

function.

1. RECORD SOURCING SETTING

Press "MENU" and select { REC MODE SET } with "PREV" or "NEXT".

Press "MENU" button again.

Select [ SOURCE ] with "+" or "" then press "MENU" button for confirming the selection.

Select [ MIC ] by recording the voice.

Select [ LINE IN ] to encode the audio signal to WMA format.

There are two functions that bring convenience to the user. User can record or encode the voice easy

by these two functions.

CAUTION: iles saved location depends on memory selected before recording.

ENGLISH

3794A.qxd 08.07.2005 9:04 Page 8

2. START RECORDING

Press "MENU" with "PREV" or "NEXT" to choose {MODE SELECT}

Press "+" or "" to choose [ RECORD MODE ].

Press "MENU" to confirm enter Record Mode.

Press "STOP" to start recording,Display will show "VORCXXX" file name.

Press "STOP" again to finishing recording file and saved.

3. WMA ENCODING

After select [ LINE IN ] and connect with external audio source by connecting cable (3.5 to 3.5mm jack

cable).

Press "MENU" with "PREV" or "NEXT" to choose {MODE SELECT}.

Press "+" or "" to choose "Record Mode".

Press "MENU" to confirmed enter record mode.

ou can heard sound from earphone now. If earphone connected.

Press "STOP" to start WMA encoding, the file name show "AUDIXXX" in display.

Press "STOP" again for finishing recording and saved file.

ADJUSTING MENU MODE

1. ENTRY MENU MODE

Press "MENU" to enter Menu mode.

Press "NEXT" and "PREV" to select the required mode.

Press "MENU" to confirm the selected mode.

Press "+" or "" to select the desired.

Press "MENU" to confirm.

2. FILE BROWSER

If the file saved by folder format in the player, press "MENU" with "PREV" or "NEXT" for find [BROWS

ER] mode.

Press "MENU" to confirm selected.

Press "+" or "" to select the folder and press "MENU" .

Press "+" or "" to select the file or UDIR to the previous folder by press "MENU" confirm.

3. GENERAL SET

A. CONTRAST

Press "MENU" button and select { GENERAL SET } by "PREV" or "NEXT" and "+" or"" to select [ LCD

CONTRAST ].

Press "MENU" for confirming the selection.

ENGLISH

3794A.qxd 08.07.2005 9:04 Page 9

Display show the icon " LCD Contrast".

Press "+" or "" for increasing or decreasing the contrast.

Press "MENU" for confirming.

Press "STOP" will back to the "Music Mode".

B. ID3 LANGUAGE

Select [ ID3 LANGUAGE ] by pressing "+" or"" button.

It have 7 types of language for choosing ,"ENGLISH', "WEST EUROPE", "EAST EUROPE",

"CHINESES", "CHINESET", KOREAN", "JAPANESE".

Press "+" or "" buton for selecting the language.

Press "MENU" for confirming the selection.

CAUTION: The information of ID3 and the playing file should be matched. Otherwise, the player can-

not show the correct language information.

C. FORMAT

Select [ FORMAT ] by pressing "+" or "" button.

Press "MENU" to confirm.

Select "QUICK" or "NORMAL" by press "+" or "" button.

Press "MENU" to select choice.

Press "PLA /PAUSE" to confirm, other to cancel.

D.FREE MEMORY

Select [ FREE MEMOR ] by pressing "+" or "" button.

Press "MENU" to confirm.

Total memory and Free Memory show in Display.

4. PLAY MODE SET

A. E Q

Press "MENU" button and select { PLA MODE SET }.

Select [ SET EQ ] icon with "+" or "" button.

Press "MENU" for confirming the selection.

It have 6 type of EQ for choosing, "Normal", "Rock", "Jazz", "Classic", "POP" and "User EQ".

Press "MENU" for confirming the selection.

Press "STOP" to return to music mode.

B. REPEAT

Press "MENU" for entering the { PLA MODE SET }.

Select [ REPEAT ] icon with "+" or "".

Press "MENU" for confirming the selection

It have 4 options for choosing, "Normal 1", "Repeat 1", "Normal", "Repeat All".

ENGLISH
