MFR User Manual

User Guide for the MFR

Optical/Thermal PTZ Camera

MFR August 2017

Visual Engineering

Video solutions. Integrated

visualengineering.co.uk

Page 2

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Change History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Warranty and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Conguring the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• Boot Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• Comm Port Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• Motor Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

• Video Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

• Select Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Software Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

• Overall Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

• Base Plate Hole Centres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Table of Contents

MFR August 2017

Visual Engineering

Video solutions. Integrated

visualengineering.co.uk

Page 3

Change History

Version Date Change Summary Author

v1.0 17/8/2017 Initial Draft RE

Warranty and Support

All Visual Engineering products are supplied as standard with a 12 month ‘Return to Base’ warranty.

In the event of a suspected product failure, users should contact the Visual Engineering support

team on the telephone number +44 (0) 1206 211842 or please email us at:

[email protected]

Should the fault persist or if the support team are unable to resolve the fault, it may be necessary

to return the equipment.

Equipment should only be returned using the RMA (Returns Management Authorisation) process.

Users should contact the support team on the above number and request an RMA form and RMA

number.

MFR August 2017

Visual Engineering

Video solutions. Integrated

visualengineering.co.uk

Page 4

Conguring the Camera

The MFR can be congured for a specic user prole, to include; communications settings, motor

control, video format and camera type. Once congured the camera will remember these settings.

The camera is congured using a menu structure on its control interface which is only accessible

at power on. To access the control menu it is necessary to connect the camera to a serial comms

software application, such as TeraTerm.

• Connect the D-Type connector on the

control cable to a Comm port on a PC.

• Open the terminal application and

congure the Comm port to 9600 baud

• Re-power the camera, a > will appear and

shortly after !

• As soon as the ! appears type ‘v’ ‘e’ in quick

succession.

• The Main Menu shown on the right will then

be displayed.

• Select the required option.

• The function of each option will now be

described in the tables that follow.

Boot Menu

Comm Port Options

Sub Menu Description Options

Mode The serial comms standard

RS485, No Parity , RS232, No Parity,

RS485, Odd Parity, RS232, Odd Parity

RS485, Even Parity, RS232, Even Parity

Baud Rate The serial comms baud rate 1200, 2400, 4800, 9600, 19200,

38400, 57600, 115200

Protocol The PTZ control protocol Auto Detect, Visca, Pelco P,

Pelco D, Forward Vision

Unit Address

The camera’s unit address, this allows

several cameras to be connected on the

same comms bus.

1, 2, 3, 4, 5, 6, 7

MFR August 2017

Visual Engineering

Video solutions. Integrated

visualengineering.co.uk

Page 5

Motor Options

Sub Menu Description Options

Auto Position

Correction

Whether the camera automatically corrects

its actual position if external forces

act upon it

Disabled, Enabled

Stall Detection Detects a stall in the motor drive Disabled, Enabled

Motor Speed The speed at which the motors are driven High, Medium, Low

Hold Torque The torque force which the camera uses to

hold position High, Medium, Low

Video Options

Sub Menu Description Options

Output Mode The output video format

PAL, NTSC, 720p/25, 720p/29.97, 720p/50,

720p/59.94, 1080i/50, 1080i/59.94, 1080p/25,

1080p/29.97, 1080p/50, 1080p/59.94

Digital Zoom If disabled only optical zoom is allowed Disabled, Enabled

On Screen

Display The OSD in the camera’s video Disabled, Enabled

Select Model

Description Options

Sets the camera type, set to either MFR or MFR-TI MKVI, TEDAS, MKIV, 10178, MKIVH, MFR, MFR-TI

MFR August 2017

Visual Engineering

Video solutions. Integrated

visualengineering.co.uk

Page 6

Software Control

The MFR camera supports serial communication control over RS232 and RS485. It supports PelcoD,

PelcoP & Sony Visca protocols.

The user may choose to use a software controller of their choice or use the VE Camera Controller.

This software application can be downloaded from the Visual Engineering website:

www.visualengineering.co.uk/supportdownload/9

The user should install the Software application on a PC. The image below shows what the software

application looks like.

MFR August 2017

Visual Engineering

Video solutions. Integrated

visualengineering.co.uk

Page 7

It is necessary to connect a USB to serial comms lead to the PC. The operating system of the

computer will allocate this a COM port number.

Once this connection between the comms lead and the computer’s operating system has been

made the user can go ahead and connect the application to the COM port. In the example below

the port COM3 has been selected. Now select Connect.

Now that the software application is connected to the comms lead the functions of the software

can be used. In the example below the pan right command has been selected. This will cause the

MFR camera to pan right. Similar commands for pan left, tilt up & down and zoom functions can

also be tried out using the intuitive software user interface.

MFR August 2017

Visual Engineering

Video solutions. Integrated

visualengineering.co.uk

Page 8

Specications

Amphenol Connector Information.

Part Number: 62GB-57A12-10PN-760

Mating Half Part Number: 62GB-16J12-10SN

Connections

Amphenol Connector Pinout

Pin Signal

AV PWR

BGND

CTX

DRX

EGND

FNC

GCVBS

HGND

KGND

JSDI Video

The MFR is tted with either a Fischer or

Amphenol connector in the base of the camera.

The pinout for the Amphenol connector is

described in the table to the right.

The Amphenol connector part number

information is described below to aid with

system integration.

Specications

Optical Sensor 1/2.8” Type CMOS User Presets 8

Optical Sensitivity <0.05 Lux, ICR On Protocol RS232/485 Visca, PelcoD

Optical Resolution 1920 x 1080 Pixel Pan & Tilt Range 270° tilt, Continuous pan

Optical SNR >50dB Lens Drive Silent Stepper

Optical Field of View 63.7° Pan & Tilt Drive Low Noise Stepper

Optical Zoom 30x Power Requirement 9-18V DC, 6W

Thermal Output PAL or NTSC Environmental IP68

Thermal Pixel Size 17um Weight 1.5kg

Thermal Spectral Range 8 ~ 14um Dimensions ø115 x 182.4mm

NETD <60mk@30°C Casing Aluminium

Visual Engineering Technologies LTD

Kemps Farm

Stanway

Colchester

Essex Tel: +44 (0)1206 211842

CO3 8NB Web: www.visualengineering.co.uk

UK Email: [email protected]

MFR August 2017

Visual Engineering

Video solutions. Integrated

visualengineering.co.uk

Page 9

Dimensions

182.4

ø 115

43 43

Overall Dimensions

Base Plate Hole Centres
