CE INFORMATION

The product must be installed according to the currently valid installation regulations for EMC to

guarantee the designed use and to prevent EMC problems.

The device supplied with this manual is according to the EC, EMC Directive,

2004/108/EC & LVD 2006/95/EC

SAFETY PRECAUTIONS

1. Do not modify the three-prong grounding type monitor power plug in any way.

2. Operate this unit only from the type of power source indicated on the label.

3. Do not block or cover ventilation openings on the back or bottom of the monitor cabinet.

4. Do not place this monitor near a radiator or heating vent.

5. Do not push objects of any kind through cabinet openings. This may result in fire or electrical shock.

6. Before adding attachments always ask a service technician to perform routine safety tests to

determine that equipment is in safe operating condition. Ground potential tests should be part of the

routine safety check made by the service technician.

7. Do not place monitor on an unstable cart, stand, or shelf where it may fall and injure personnel or

damage equipment.

8. Route power cords so that they cannot be walked upon or tripped over. Do not allow anything to rest

on the power cord.

9. Do not install monitor in wet areas, or where it may be exposed to rain or water. Do not spill liquid of

any kind on the unit.

10. Unplug the power cord from the unit before cleaning the display. Use only a damp cloth. Do not use

alcohol, spirits, or ammonia to clean the display. DO NOT ATTEMPT TO CLEAN THE INTERIOR OF

THIS UNIT- THIS ACTION MUST BE PERFORMED BY THE SERVICE TECHNICIAN AS

REQUIRED DURING NORMAL MAINTENANCE.

11. Refer all servicing to qualified service personnel. REMOVAL OF BACK COVER BY

UNAUTHORIZED PERSONNEL MAY EXPOSE THE USER TO DANGEROUS VOLTAGES OR

OTHER HAZARDS.

12. Unplug the unit immediately and notify the service technician.

A. If liquid has been spilled into the display or the display has been exposed to rain or water.

B. If the unit has been dropped or the cabinet damaged.

C. If fuses continue to blow.

D. If the power cord is damaged or frayed.

E. If a distinct change from normal operation is apparent.

When replacement parts are required, be sure that the service technician uses components specified by

the manufacturer which have the same characteristics as the original parts. UNAUTHORIZED

SUBSTITUTIONS MAY RESULT IN FIRE, ELECTRICAL SHOCK OR OTHER HAZARDS.

Upon completion of any service or repairs, ask the technician to perform safety checks to determine that

the equipment is in safe operating condition.

WARNING: SERIOUS SHOCK HAZARDS EXIST WITHIN THE COVERS OF THIS MONITOR. DO

NOT OPEN THE COVERS UNDER ANY CIRCUMSTANCES,

THERE ARE NO USER SERVICEABLE COMPONENTS INSIDE

BEFORE YOU BEGIN

Read these instructions before installing or operating this product.

Note: This installation should be made by a qualified service person and should conform to local codes.

This manual provides installation and operation information. To use this document,

you must have the following minimum qualifications:

A basic knowledge of CCTV systems and components

A basic knowledge of electrical wiring and low-voltage electrical connections

Intended use

Only use this product for its designated purpose; refer to the product specification and

user documentation.

Customer Support

For assistance in installing, operating, maintaining and troubleshooting this product

refer to this document and any other documentation provided. If you still have

questions, please contact Norbain Technical Support and Sales:

Vista, 210 Wharfedale Road, IQ Winnersh, Wokingham, Berkshire RG41 5TP, England.

UK +44 (0) 118 912 5000

Note: You

should be at

the

equipment

and ready

with details

before calling

Technical

Support.

Conventions Used in this Manual

Boldface or button icons highlight command entries. The following WARNING,

CAUTION and Note statements identify potential hazards that can occur if the

equipment is not handled properly:

* WARNING:

Improper use of this equipment can cause severe bodily injury or equipment

damage.

** Caution:

Improper use of this equipment can cause equipment damage.

Note: Notes contain important information about a product or procedure.

This apparatus is manufactured to comply with the radio interference.

A Declaration of Conformity in accordance with the following EU standards

has been made. The manufacturer declares that the product supplied with

this document is compliant the provisions of the EMC Directive

2004/108/EC, the CE Marking Directive 93/68 EEC and all associated

amendments.

All lead-free products offered by the company comply with the

requirements of the European law on the Restriction of Hazardous

Substances (RoHS) directive: 2011/65/EU, which means our manufacture

processes and products are strictly “lead-free” and without the hazardous

substances cited in the directive.

The crossed-out wheeled bin mark symbolizes that within the European

Union the product must be collected separately at the product end-of-life.

This applies to your product and any peripherals marked with this symbol.

Do not dispose of these products as unsorted municipal waste.

* This symbol indicates electrical warnings and cautions.

** This symbol indicates general warnings and cautions.

NORBAIN SD LTD reserves the right to make changes to the product and specification of the product from time to

time without prior notice.

WARNINGS AND CAUTIONS:

To reduce the risk of fire or electric shock, do not insert any metallic objects through the ventilation grills or other

openings on the equipment.

WARNING

This is a Class A product. In a domestic environment this product may cause radio interference in which case the user

may be required to take adequate measures.

CAUTION

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Scope

This document is used to define the performance of the LCD Public View Monitor (PVM) series.

The system supports video and PC inputs, as well as from the built-in camera. In video mode,

the display automatically detects NTSC and PAL signals. The On Screen Display (OSD) menu

makes the system easy to operate.

Functional Specifications

Power Supply

27” PVM Monitor Power Requirements:

Voltage: 12Vdc or 24Vdc

Current: 4 A max (12Vdc) or 2A max (24Vdc)

Use only a PSU rated at 12dc, with a minimum current rating of 4A; or 24Vdc, with a minimum

current rating of 2A

Video Characteristics

Composite Video (CVBS): 1.0Vp-p (0.5 –1.5Vpp), Automatic switching from 75 unbalanced

termination to Hi-Z with loop-through operation.

Composite Video (Camera output): 1.0Vp-p (0.5 –1.5Vpp), loop-through camera signal.

VGA Input

Analog RGB: 0.707Vrms.

Support VESA Standard Timing

Controls: Back Push Buttons

CHANNEL: Select the input signal

: Scrolling the cursor or adjust the value

+: Scrolling the cursor or adjust the value

MENU: Select On-Screen Display (OSD)

POWER: Switch power On/Off

HDMI Input

HDMI 1.3 Compatible Interface

HDMI Timing Modes

480i / 480p

576i / 576p

720p

1080i / 1080p

Audio Input

Signal Level: 1.0Vrms

Environmental

Temperature:

Operating: 00C to +400C

Storage: -200C to +600C

Humidity:

Operating: 10% to 85% (non-condensing)

Storage: 10% to 95% (non-condensing)

EDID

This series of displays support EDID.

Controls and Indicators

Connectors

DC-In USB HDMI VGA Video-out ideo-in CAM-out Audio-in SD-card

(A) (B) (C) (D) (E) (F) (G) (H) (I)

Power

Video

A–DC 12V/24V IN

connector

C–HDMI

B –USB SLOT

D–VGA In

E–BNC connector, CVBS Loop through

out

F –BNC connector, CVBS input

G –BNC connector, Camera signal out

H –AUDIO IN: Stereo Phone Jack x1

I –SD CARD SLOT

Table des matières

Autres manuels Vista Moniteur

Vista

Vista VFS-300LED Mode d’emploi

Vista

Vista TV14E Instructions de fonctionnement

Vista

Vista DIAMOND Manuel utilisateur

Vista

Vista VFS-200LED Mode d’emploi

Vista

Vista VLFSM15D_h Manuel utilisateur

Vista

Vista VK2-PVM27CAM Manuel utilisateur

Vista

Vista VM215 Manuel utilisateur

Vista

Vista VK2-PVM10CAM Manuel utilisateur

Vista

Vista VFS100LEDe Series Manuel utilisateur

Vista

Vista VFS132WHDA Mode d’emploi

Vista

Vista VFS24/32HDIP Manuel utilisateur

Vista

Vista VFS-300 Series Mode d’emploi

Vista

Vista PVM27DEC Manuel utilisateur

Vista

Vista PVM10CAMN Manuel utilisateur

Vista

Vista PVM18DEC Manuel utilisateur

Vista

Vista VFS-200/HI-LITE Series Manuel utilisateur

Vista

Vista VK2-PVM32CAM Manuel utilisateur

Vista

Vista VK2-PVMxxDEC Series Manuel utilisateur

Vista

Vista VFS-221WHDA Manuel utilisateur

Vista

Vista PVM19CAM Manuel utilisateur

Vista

Vista VFSM15 Manuel utilisateur

Vista

Vista TV14 Instructions de fonctionnement

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
