Motion Sensor Battery Installation - Visonic CLIP SMA

What You’ll Need

•CLIP SMA Motion Sensor

•A Phillips-head screwdriver

•One CR123A battery

•Double-sided tape (optional)

How to Install the Battery

Before proceeding, please be sure that your system is disarmed. Working on devices while the system is armed can

generate false alarms.

Did You Know? You may want to have some double-sided tape on hand if you need to remove your Sensor from the

wall to install a battery. Cut the tape to size and reattach your Sensor if the existing adhesive fails to hold it in place.

Is This Your Sensor? Make sure that your

Sensor looks like the one in the image. If it

does, you have the right document to find out

how to install a battery in your Sensor.

1. Locate the screw on the top of the Sensor.

2. Using a Phillips-head screwdriver, turn the

screw counterclockwise until the cover is

loose.

3. Gently pull the top of the cover away from

the screw, then pull down to free the

bottom tab on the cover from the slot in the

bottom of the Sensor. The battery slot is on

the circuit board.

Take a Look. If a battery is already present,

remove it by using your fingertip to gently pull

one end of the battery up until the battery is

loose and you can pull it free from the slot.

4. Install a CR123A battery by aligning the

positive (+) and negative (-) ends of the

battery with the positive (+) and negative

(-) indicators on the circuit board and

pressing the battery into the battery clasps.

5. When the battery is inserted correctly, the

red light on the circuit board will light up.

Did You Know? The Motion Sensor and

tamper are exposed once you remove the

cover (shown below within the blue squares).

Take care not to touch them. Repeated contact

with the Sensor may compromise the

functionality of your device and pressing down

the tamper will default the Sensor.

6. Slide the tab on the bottom of the cover

into the slot at the bottom of the Motion

Sensor.

7. Press and hold the top of the cover against

the Sensor's body and use a Phillips-head

screwdriver to turn the screw clockwise

until tight.

Confirm that the low battery alert has resolved and the equipment appears on your list of connected devices. You

should also ensure that sensor events such as door opening or motion registers as an activity on your system.

Need Help? Find these instructions online at

https://customer.xfinity.com/help-and-support/home-security/installing-battery-clip-sma-motion-sensor. Get more

troubleshooting support at https://www.xfinity.com/support/gettingstarted/troubleshooting/ or contact a customer service

expert at 1-800-XFINITY.

Help Protect Our Environment: Please properly recycle your discarded batteries. For your convenience, batteries are

accepted for recycling at various locations. Check www.call2recycle.org or call 1-800-8-Battery (1-800-8-228-8379) to

find a recycling location near you.
