Vision CS-1900 Manuel utilisateur

CS-1900_manual_en

CS-1900 OWNERS MANUAL

www.visionaudiovisual.com/techaudio/cs-1900

CS-1900_manual_en

DECLARATION OF CONFORMITY

Where applicable Vision products are certified and comply with all known local regulations to a

‘CB Certification’ standard. Vision commits to ensure all products are fully compliant with all

applicable certification standards for sale in the EU and other participating countries.

The product described in this owner manual is in compliance with RoHS (EU directive

2002/95/EC), and WEEE (EU directive 2002/96/EC) standards. This product should be returned

to the place of purchase at the end of its useful life for recycling.

WARNINGS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user

to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle, is intended to alert the user to the presence of

important operating and maintenance (servicing) instructions in the literature accompanying the

appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR MOISTURE.

All products are designed and imported into the EU by ‘Vision’ who is wholly owned by ‘Azlan

Logistics Ltd.’, Registered in England Nr. 04625566 at Lion House, 4 Pioneer Business Park,

Clifton Moor, York, YO30 4GH. WEEE Registration: GD0046SY

DECLARATION OF ORIGIN

All Vision products are made in the People’s Republic of China (PRC).

CS-1900_manual_en

PLACE OF INSTALLATION

Avoid installing this product under the following conditions:

• Moist or humid places

• Places exposed to direct sunlight or close to heating equipment

• Extremely cold locations

• Places subject to excessive vibration or dust

• Poorly ventilated places

Do not expose this product to dripping or splashing. DO NOT PLACE OBJECTS FILLED WITH

LIQUIDS ON OR NEAR THIS PRODUCT!

PACKAGING

Save all packing material. It is essential for shipping in the event the unit ever needs repair.

NOTE: If original packaging is not used to return the unit to the service centre, damage in transit

will not be covered by warranty.

POWER HANDLING

Power rating with regards to loudspeakers denotes how much power the loudspeaker can

handling for a sustained period of time without distortion. These speakers are rated to accept up

to 60 watts RMS.

WATTS

The most consistent standards for measuring watts are “Program Power” and “RMS” because

these measure average sustained levels. Any low impedance amplifiers without an output from 2

x 10w to 2 x 70w (@ 8 ohms) are suitable for these speakers.

NOTE: The power output from an amplifier depends on the number of loudspeakers attached.

8 ohms normally denotes two loudspeakers attached

4 ohms normally denotes four loudspeakers attached

CS-1900_manual_en

INSTALLATION

1. CUT HOLES IN CEILING TILES Draw around the cardboard template included (the circle

will have diameter 210 mm / 8.3"). Cut along this line.

6.5” CEILING SPEAKER

Φ210

CUT ALONG OUTSIDE EDGE OF TEMPLATE

(Φ210mm)

NOTE: These loudspeakers can only be fitted where there is a false ceiling.

2. Draw the Cutting Hole and Cut along It

CS-1900_manual_en

3. Pull the Speaker Wires through the Cutout

4. Connect Speaker Wires with Terminals

5. Install the Speaker

CS-1900_manual_en

6. Install the Grill

NOTE: These loudspeakers are not waterproof and are not designed to work in

high humidity areas.

TROUBLESHOOTING

If your system is not operating properly, please refer to the following information. If

the problem persists, disconnect from power and contact your AV reseller immediately.

Problem Correction

Sound only coming out

Turn off amplifier and switch output connections. If the side

one side

changes the amplifier is okay and the fault is with one of the

loudspeakers.

Switch input connections and check input cabling.

Sound very quiet

Have you used unshielded speaker cables? Use cable with

gauge of 0.75mm or higher. Note: Phono or minijack cable is

shielded and is not appropriate.

CS-1900_manual_en.doc

SPECIFICATIONS

LOUDSPEAKER DIMENSIONS: 227 x 87 mm/ 9" x 3.4"

CUTOUT SIZE: 210 mm / 8.3"

CARTON DIMENSIONS: 267 x 265 x 225 mm / 10.5" x 10.4" x 8.9"

SPEAKER WEIGHT: 1.84 kg / 4.05 lbs (each)

CARTON WEIGHT: 4 kg / 8.8 lbs (per pair)

POWER HANDLING: 60 Watt RMS

WOOFER: 6.5" Kevlar Woven Cone

TWEETER: 0.75" Titanium Dome

CONTRUCTION MATERIAL: ABS Plastic

SPEAKER TERMINALS: Binding post

NOMINAL IMPEDANCE: 8 ohms

SENSITIVITY: 90dB (1w/1m)

FREQUENCY RESPONSE: 60Hz-20kHz

COLOUR: White

ACCESSORIES INCLUDED: n/a

WARRANTY: Lifetime return-to-base

2 years onsite (UK only)

COMPLIANCES: RoHS, CE

CS-1900_manual_en.doc

LIFETIME RETURN-TO-BASE WARRANTY

This product comes with a lifetime return to base warranty. If you have a problem you are

required to provide a DETAILED DESCRIPTION of the fault.

Some Vision products are very technical and require troubleshooting all elements of the

installation as it may not be the Vision product at fault. Because of this the manufacturer may

refuse to replace the item if an adequate description is not provided.

•This warranty applies only to the original purchaser and is not transferable.

•This warranty protects you against the following:

oFailure of any components, including the power supply.

oDamage when the product is first removed from its packaging if reported within 24

hours of purchase.

•If the product is DOA (dead on arrival), you have 21 days from purchase date to notify the

national distributor via your AV reseller.

•The original purchaser is responsible for shipment of the product to the Vision’s appointed

service centre.

•The liability of Vision is limited to the cost of replacement of the faulty unit under warranty

except for death or injury (EU85/374/EEC).

•If the product is end of line (EOL) the Vision will provide a credit instead of replacement.

•This warranty does not protect this product against faults caused by abuse, misuse, incorrect

installation, unstable or faulty power input, or modification.

Vision aims to send a replacement item within 5 working days however this may not always be

possible, in which case it will be sent as soon as practicably possible. UK End users and resellers

can request support at http://www.visionaudiovisual.com/support

LEGAL DISCLAIMER: Because we are committed to improving our products, the details above may

change without prior warning. This User Manual is published without warranty and any

improvements or changes to the User Manual necessitated by typographical errors, inaccuracies

of current information, or improvements to programs and/or equipment, may be made at any

time and without notice. Such changes will be incorporated into new editions of the User Manual.

CS-1900_manual_de

CS-1900 BEDIENUNGSANLEITUNG

www.visionaudiovisual.com/techaudio/cs-1900

CS-1900_manual_de

KONFORMITÄTSERKLÄRUNG

Falls zutreffend sind Vision-Produkte zertifiziert und entsprechen allen bekannten lokalen

Vorschriften der Normen für „CB-Zertifizierung“. Vision verpflichtet sich sicherzustellen, dass alle

Produkte mit allen anwendbaren Zertifizierungsnormen für den Verkauf in der EU und anderen

teilnehmenden Ländern in vollem Umfang übereinstimmen.

Das in dieser Bedienungsanleitung beschriebene Produkt erfüllt die Anforderungen von RoHS

(EU-Richtlinie 2002/95/EC) und WEEE (EU-Richtlinie 2002/96/EC). Dieses Produkt ist nach Ende

der Nutzungsdauer zum Zwecke des Recycling an die Verkaufsstelle zurückzubringen.

WARNHINWEISE

VORSICHT : UM STROMSCHLÄGE ZU VERMEIDEN, GEHÄUSE (UND RÜCKSEITE) NICHT

ÖFFNEN. ENTHÄLT KEINE VOM BENUTZER ZU WARTENDEN TEILE IM INNEREN DES

GERÄTS. WARTUNG NUR DURCH QUALIFIZIERTES FACHPERSONAL DURCHFÜHREN

LASSEN.

Der Blitz mit dem Pfeilkopf im gleichseitigen Dreieck soll den Benutzer auf „gefährliche Spannung” durch

nicht isolierte Teile im Gehäuseinneren hinweisen. Diese kann so hoch sein, dass die Gefahr eines

Stromschlags besteht.

Das Ausrufezeichen im gleichseitigen Dreieck soll den Benutzer auf wichtige Bedienungs- und

Wartungsanweisungen in der dem Gerät beiliegenden Bedienungsanleitung aufmerksam machen.

ACHTUNG: UM EINEN BRAND ODER EINEN STROMSCHLAG ZU VERMEIDEN, SETZEN

SIE DAS GERÄT NIEMALS REGEN ODER FEUCHTIGKEIT AUS.

Alle Produkte werden von Vision entwickelt und in die EU importiert. Vision ist eine 100%-ige

Tochter der Azlan Logistics Ltd. Das Unternehmen ist in England unter der Registernummer

04625566 eingetragen und hat seinen Sitz an folgender Adresse: Lion House, 4 Pioneer Business

Park, Clifton Moor, York, YO30 4GH. WEEE-Registrierung: GD0046SY

URSPRUNGSERKLÄRUNG

Alle Vision-Produkte werden in der Volksrepublik China (VR China) hergestellt.
