VIRTUFIT CTR 1.0 Manuel utilisateur
User manual
EN
CTR 1.0 Crosstrainer
EN
VirtuFit CTR 1.0 Crosstrainer 2
INDEX
SAFETY INSTRUCTIONSSAFETY INSTRUCTIONS
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
MAINTENANCEMAINTENANCE
TROUBLE SHOOTINGTROUBLE SHOOTING
CONTROL PANELCONTROL PANEL
EXPLODED DRAWINGEXPLODED DRAWING
PARTS LISTPARTS LIST
TRAINING INSTRUCTIONSTRAINING INSTRUCTIONS
3 - 4
5 - 9
10
11
12 - 14
15 - 16
17 - 18
19
EN VirtuFit CTR 1.0 Crosstrainer
3
– It is important to read this entire manual before assembling and using the device. Safe and
effective use can only be achieved if the device is assembled, maintained and used properly.
It is your responsibility to ensure that all users of the device are informed of all warnings and
precautions.
– Before starting any exercise program, you should consult your doctor to determine if you have
any medical or physical conditions that could put your health and safety at risk, or prevent you
from using the device properly. Your doctor’s advice is essential if you are taking medication
that affects your heart rate, blood pressure or cholesterol level.
– Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest, irregular
heartbeat, extreme shortness of breath, lightheadedness, dizziness or feelings of nausea. If you do
experience any of these conditions you should consult your doctor before continuing with your
exercise program.
– Keep children and pets away from the device. The device is designed for adult use only.
– Use the device on a solid, flat level surface with a protective cover for your floor or carpet. To
ensure safety, the device should have at least 0.5 metres of free space all around it.
– Before using the device, check that the nuts and bolts are securely tightened.
– The safety of the device can only be maintained if it is regularly examined for damage and/or
wear and tear.
ATTENTION
WARNING
Before beginning any exercise program consult your physician. This is especially
important for people who are over 35 years old or who have pre-existing health
problems. Read all instructions before using any fitness equipment. Do not operate this
device without properly fitted guards, as the moving parts can present a risk of serious
injury if exposed.
SAFETY INSTRUCTIONS
EN
VirtuFit CTR 1.0 Crosstrainer 4
– Always use the device as indicated. If you find any defective components while assembling or
checking the device, or if you hear any unusual noises coming from the device during use,
stop immediately. Do not use the device until the problem has been rectified.
– Wear suitable clothing while using the device. Avoid wearing loose clothing that may get caught
in the device or that may restrict or prevent movement.
– The max user weight is 115 KGS. Braking ability is independent of speed.
– The device is not suitable for therapeutic use.
– Care must be taken when lifting or moving the device so as not to injure your back. Always use
proper lifting techniques and/or seek assistance if necessary.
– Please keep the space at least 1 to 2 meter at the end of base frame to escape any accidents!
– Place the device on a clean and flat surface. Do not place the device on a thick carpet.
– The device is for indoor use and not for outdoor use to prevent damage. Keep the storage location
dry, clean and flat. It is forbidden to use the device for purposes other than training.
– Only use the machine in an environment with an ambient temperature between 10 °C and 35 °C.
Only store the device at an ambient temperature between 5 °C and 45 °C.
Warranty claim is excluded if the cause of the defect is the result of:
– Maintenance assembly and repair work not carried out by an official dealer.
– In the event of improper use, neglect and / or poor maintenance.
– Failure to maintain the device in accordance with the manufacturer’s instructions (see the enclosed
manual).
SAFETY INSTRUCTIONS
EN VirtuFit CTR 1.0 Crosstrainer
5
STEP 1
Missing parts: If you think you are missing certain parts in your package, carefully check the styrofoa and
the device. Some parts (bolts, screws, etc.) are already attached to/in the device.
Error message: Ensure that all cables are carefully attached. The aluminum legs are very sensitive and
must remain straight. Do you receive an error message after mounting your device? Then you have to
straighten these aluminum legs again, this may cause the error message to disappear.
Socket screws: The device contains socket screws, make sure that the allen key is firmly in the
bolt before you apply force to the key. In this way you prevent the head of the socket head screw from
being rotated.
Transport wheels: Make sure that the transport wheels are attached to the front of the appliance.
• Attach the Front Stabilizer (35) and the Rear Stabilizer (36) to the Main Frame (40) with Carriage Bolt
(33), Domed Nut (23) and Arc Washer (22).
ASSEMBLY INSTRUCTIONS
EN
VirtuFit CTR 1.0 Crosstrainer 6
STEP 2
• Turn the resistance knob all the way. Cable (53) needs to be as long as possible.
• Connect the Sensor 16 and 38,and Tension Control wire 53 and 39 as shown above, x the Upright
Post (15) with the Main Frame (40) with Bolt (26), Arc Washer (22). Fasten tightly.
NOTE! Tighten the Screw (27) and the Arc Washer (22) after STEP 3.
ASSEMBLY INSTRUCTIONS
EN VirtuFit CTR 1.0 Crosstrainer
7
STEP 3
ASSEMBLY INSTRUCTIONS
• Fix the Lower Handle Bar (25L/R)to the Upright Post (15) with Bolt (18) ,Washer (9), D Washer (19).
• Fix the Pedal Tubes (42L/R) with the Pedal Crank by Pedal Hinge Bolt (46L/R)Curved Washer (50), and
Nylon Nut (51L/R). Install the Pedal (44) on the Pedal Tube (42L/R) with Hex Head Bolt(43), Knob (27).
EN
VirtuFit CTR 1.0 Crosstrainer 8
STEP 4
• Install the Middle handlebar (4) on the Upright Post (15) with bolt (8) Arc Waser (9).
• Fix the Handlebar ( 11 L / R ) to the Lower Handle Bar ( 25 L / R ) with Bolt (21), Arc Washer (85) and
Domed Nut (23).
ASSEMBLY INSTRUCTIONS
EN VirtuFit CTR 1.0 Crosstrainer
9
STEP 5
ASSEMBLY INSTRUCTIONS
• Connect wires ( 1a / 1b ) to wires ( 4a / 4b ) Handle Pulse Wire (1a) and (1b), then connect Sensor
wire (16) to the Computer (1); x the Computer (1) onto the Upright Post (15) with Screw (2) and
Washer (103).
• Attach the Bottle Holder (98) to the Support Tube (15) with Crosshead (99).
• Then, put the Bottle (100) in the Bottle Holder (98).
NOTE! Make sure that all nuts and bolts are tight before you start training. The end cap of the front
stabilizer tube is movable, making it easier for you to move the crosstrainer.
EN VirtuFit CTR 1.0 Crosstrainer
10
CLEANING
WARNING
Before cleaning the machine, please make sure the power has been switched o.
Cleaning:General cleaning of the device will extend the life of the treadmill. Hold clean the treadmill by
dusting regularly. Be sure to clean the exposed area of the belt and the foot rails of the treadmill on both
sides.
In addition, wear clean shoes to reduce the risk of contamination of the treadmill. Remove the hood at least once
a year to vacuum underneath.
MAINTENANCE
SEMI-ANNUAL MAINTENANCE
DAILY MAINTENANCE
• Clean and remove sweat after each use Do not use aggressive cleaning agents and ensure that
the device remains free of moisture.
• Check that the rail and the wheels under the seat are free from dust and dirt.
• Inspect all bolts and nuts in connection with moving parts of the device, tighten as required.
• Check the mobility of moving parts and components of the use equipment, silicone spray if
necessary.
Safeandeectiveusecanonlybeachievedifthedevicewillbeassembledandmaintained
well. It is your responsibility to ensure that the equipment is regularly maintained. Parts
that are already used and / or damaged must be replaced before continuing using. The
rower machine may only be used indoors and stored away, prolonged exposure to
weathering and changes in temperature / humidity can have a serious impact on the
electrical components and moving parts of the device.
