Viper 5606V Manuel utilisateur
OWNER’S GUIDE MODEL
®
NO ONE DARES
COME CLOSE ®
5606V
Congratulations
Congratulations on the purchase of your state-of-the-art remote start
and security system. Reading this Owner’s Guide prior to using your
system will help maximize the use of your system and its many fea-
tures. For any additional questions please contact your authorized
Directed dealer or contact Directed at 1-800-753-0600.
Additional Guide Information
Only basic commands, features and essential information are covered
in this compact guide. Your product has many advanced features
which are not discussed here, please consult the expanded online ver-
sion for these on the website listed on the back cover. Most sections in
this guide also contain additional information which can be found in
the expanded online version.
Important information
Government Regulations and Safety information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
Optional Remote Controls
A choice of two optional remote controls with additional features is
also available for use with your system. These remote control choices
are: LED 2-way (P/N 7856) and LCD 2-way (P/N 7756). See your
authorized dealer for purchasing details. Once purchased, please
go online to our website (listed on the back cover) and use system
model number 5806 or 5706 respectively to search for the appropri-
ate owner’s guide, which provides instructions on how to use these
remote controls.
Replacement Remote Controls
Please see your authorized dealer or visit us at www.directedstore.
com to order additional remote controls , or the optional LED and LCD
remote controls. Remote control part numbers are found on the back
of the device.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an autho-
rized Directed dealer.
Contents
Remote Control ................................................................................................... 3
Control Center .................................................................................................... 3
Using your System............................................................................................... 4
Commanding the system....................................................................... 4
Performing Commands ......................................................................... 4
Remote Control Command table ............................................................ 5
Basic Commands (Direct Access) .......................................................................... 6
Arm ................................................................................................... 6
Disarm ............................................................................................... 6
Remote Start........................................................................................ 7
AUX/Trunk.......................................................................................... 7
Battery Information.............................................................................................. 8
Battery Disposal .................................................................................. 8
Patent Information ............................................................................................... 8
Government Regulations ...................................................................................... 9
Warning! Safety First......................................................................................... 10
Installation ........................................................................................ 10
Remote Start Capable ........................................................................ 10
Manual Transmission Vehicles ............................................................. 11
Interference....................................................................................... 13
Upgrades ......................................................................................... 13
Water/Heat Resistance ...................................................................... 13
Limited lifetime consumer warranty ..................................................................... 14
3
© 2013 Directed. All rights reserved.
Remote Control
Feature Description
Internal Antenna Used for transmitting information
Transmit LED Active when transmitting information
Command buttons (4)
A U X
Used to perform arming, disarming, auxiliary channel and
remote start commands
Function button Used to access function levels for commands, configuration
menus for programming and Car Selection
Control Center
Control CenterLED Button
The Control Center, typically located on the upper part of the front
windshield. It consists of:
• The In-vehicle system antenna.
• The Status LED, as a visual indicator of the system’s status.
• The Control button, for placing the system into Valet Mode* and
to perform the Emergency Override** operation.
* See Remote and System Operations section for details.
** See Alarm Features for details.
4© 2013 Directed. All rights reserved.
Using your System
Commanding the system
Commands, Basic or Advanced, are used to activate system features
and are performed by pressing one of the Command buttons. Basic
commands control the most often used security and remote start fea-
tures while Advanced commands control more specialized features.
Confirmations for Basic or Advanced commands are indicated
by siren chirps and parking light flashes. A description of each feature
confirmation is found in the following Basic command and Advanced
command sections.
Performing Commands
Perform Basic commands by pressing a Command button.
Perform Advanced Commands by first accessing Levels 1-4 using the
button and then by pressing a Command button while within a
level.
Advanced command example: Silent Arm
1. Press the button once to access Function Level 1, The trans-
mit LED single flashes for 3 seconds.
2. Press the button while the transmit LED is still flashing to
perform the Silent Arm command.
3. The system will arm, lock the doors and flash the parking lights
without siren chirps.
5
© 2013 Directed. All rights reserved.
Remote Control Command table
Button
Level Direct Access x 1
LEVEL 1
x 2
LEVEL 2
x 3
LEVEL 3
x 4
LEVEL 4
Arm/Lock
(Panic)
Silent Arm Sensor
Bypass
Sensor Silent
Arm
Full Silent
Arm
Disarm/Unlock Silent Disarm Remote Valet Car Finder
Remote Start Runtime
Reset
Timer Start Smart Start Defogger
AUX Aux/Trunk AUX 1 AUX 2 AUX 3 AUX 4
Advance Level,
Enter program-
ming (8 sec)
6© 2013 Directed. All rights reserved.
Basic Commands (Direct Access)
Arm
Press and release
The alarm arms, doors lock (if connected), and the siren chirps and
parking lights flash once. If Valet mode* is On, the doors lock without
siren chirps, the alarm is disabled. Exit Valet mode to arm the alarm
normally.
If a trigger zone fault is detected the siren chirps once again and the
control center LED generates a Trigger Zone Fault report**.
To Arm and Panic
Press and hold
The alarm Arms (or Locks in Valet) and, after two seconds, sounds
the siren and flashes the parking lights. Press the or button
to stop the output.
Disarm
Press and release
The alarm disarms, doors unlock (if connected), and the siren chirps
and parking lights flash twice.
An Alarm Report** alert of four or five siren chirps will replace the
normal disarm chirps if the alarm was triggered.
7
© 2013 Directed. All rights reserved.
Remote Start
Press and release
Activates (or if On, deactivates) the remote starter. The engine and
parking lights turn On, or the engine and parking lights turn Off ac-
cordingly. If a Remote start configuration issue prevents the engine
from starting, the parking lights flash a Remote Start fault report***
to identify the fault.
AUX/Trunk
Press and hold
AUX
The Trunk opens (if connected) when this button is pressed for 2 sec-
onds.
* See Remote and System Operations in online guide.
** See Alarm Features in online guide.
*** See Remote Start Faults in online guide.
For Manual transmission vehicles see Manual Transmission Start in online
guide.
8© 2013 Directed. All rights reserved.
Battery Information
The remote controls are powered by one coin cell battery (CR-2032)
that can be purchased at most retailers. When the battery begins to
weaken, the operating range is reduced.
Battery Disposal
Directed cares about the environment. If you need to dis-
pose of the battery, please do so in accordance with your
municipal requirements for battery disposal.
Patent Information
This product is covered by one or more of the following United States
patents:
Remote Start Patents:
5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936;
5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053;
7,483,783
Vehicle Security Patents:
5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591;
5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667;
5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484
Other patents pending.
