Viking Use/Installation Guide

Brigade Range/Rangetop Accessories

screw

holes

HIGH-SHELF BACK

(rear view)

Rear Trim Accessories

Backguards come equipped with Nylon Spacers (See Figure 1), which are needed to space the range off a

combustible wall at a prescribed safe distance.

Important: If installing the range with a backguard against a combustible wall, then the spacers are

mandatory and must remain in place on the backguard.

If installing the range with a backguard against a non-combustible wall, then the spacers can be removed

(See Figure 2).

Once you determine whether or not your product needs the provided spacers, the backguard is ready to be

attached.

ATTACHING HIGH-SHELF

Simply slide the high-shelf back down onto the rear of the unit until it settles on the shoulder screws located on

the back of the range.

ATTACHING BACKGUARD

Figure 1 Figure 2

Simply slide the backguard down onto the

rear of the unit until it settles on the shoulder

screws located on the back of the range.

screw

holes

Once the backguard is in position, attach using the

(4) screws provided.

Once the high-shelf back is in position, attach using the (4) screws provided. Once secured to the range, place

the top rolled edge (X) of the high shelf over the front lip of the high-shelf back.

HIGH-SHELF

(side-view)

Place the countertop side trim template against the side of the range or rangetop. The flange of the

template should be wrapped around the back of the unit. The top of the template should be even

with the top edge of the outer trim. Mark the holes and remove template. Using a 9/64” drill bit, drill

the three designated holes into the side of the range or rangetop. Place the countertop side trim into

place and secure with the (3) provided screws.

Countertop Side Trim

1. Locate screw hole openings (A) on back of island trim near the top.

2. Align screw hole openings on countertop rear trim with the ones on the back of the island trim.

3. Attach rear trim to island trim with enclosed screws.

Countertop Rear Trim

Curb Bases

Alternate Curb Base View

for Custom Ranges

STANDARD CURB BASE FRONT

1. The standard curb base front (A) is completely assembled.

2. Remove the assembly from the carton and simply clip onto the front range legs.

3. The assembly is adjustable about 2” (5.1 cm) front to back so that alignment with the cabinet toe front is

possible. Loosen brackets on each side, but allow snug fit. Clip assembly onto range legs; determine

front to back setting; remove, tighten bolts, and reattach.

Important Note: The range must be installed as specified in the range installation guide for proper airflow

when using the standard curb base.

CUSTOM CURB BASE FRONT

1. Remove the standard curb base front assembly from the carton.

2. Remove the front (A) from the mounting assembly (B).

3. Attach locally supplied front (C) to the mounting assembly (B) and simply clip onto the front

range legs.

Important Note: The locally supplied front must not be any taller than 3-1/8” (7.9 cm) tall. Fronts taller

than 3-1/8” (7.9 cm) could obstruct the airflow.

4. The assembly is adjustable about 2” (5.1 cm) front to back so that alignment with the cabinet

toe front is possible. Loosen brackets on each side, but allow snug fit. Clip assembly onto

range legs; determine front to back setting; remove, tighten bolts, and reattach.

Curb Bases

Important Note: The range must be installed as specified in the range installation guide for proper

airflow when using the custom curb base.

Stainless Steel Surface Grates

To install the accessory stainless steel surface grates, simply remove the cast iron grate which came standard

with the range or rangetop.

Replace with the appropriate stainless grate.

Stainless Steel Grate Care

and Cleaning Tips

These stainless steel surface burner grates are the same as what is commonly used in commercial and

restaurant style ranges. Over time they will naturally start to darken and discolor. This is the standard process

of how stainless steel reacts when it is exposed to high heat temperatures. The discoloration of the grates will

not affect the performance.

While the stainless steel surface burner grates will never return to the original color, there are some steps which

can be taken to help minimize the discoloration of these components. To ensure that the stainless steel

maintains adequate corrosion resistance, it should be cleaned regularly. Surface contaminates vary in terms of

corrosiveness, effect on surface finish, and ease of removal. The mildest form of cleaning should always be

used first.

To clean a lightly soiled surface

•It is recommended to use warm water, a mild, non-abrasive detergent, and a soft cloth.

For more highly soiled/discolored surfaces

•It is recommended to scrub the grates using a dry heavy duty green Scotch Brite pad. Note -

scrubbing the grates with a Scotch Brite pad will help improve the look of the heat tarnished grate but

will not completely restore it to its original look.

Things to avoid when cleaning stainless steel

•Steel brushes or steel wool

•Abrasive cleaners

•Bleach or hydrochloric acid based cleaners

•Detergents containing chloride

•Avoid using cleaning cloths that have been used on ordinary steel

•Never rub against the grain with a cleaning agent or polish as it will alter the surface of the steel and

reduce the corrosion resistance.

•DO NOT permit citrus or tomato juice to remain on stainless steel surface, as citric acid will

permanently discolor stainless steel. Wipe up any spills immediately
