Viking FBCI1240GR Mode d’emploi
REFRIGERATION
Undercounter/Freestanding
2 ”W. Beverage Center
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1- -VIKING1
All models include
• Electronic controls with digital
temperature readout
oInside temperature can be adjusted
from 36 – 4 ºF
oFactory set at 42ºF
oSabbath mode
oTemperature can be displayed in
either Fahrenheit or Celsius
• Capacity—5.3 cu. ft. (150.0 L)
• One full-extension wire shelf
o75 lbs. capacity
oRemovable and adjustable
• Two full-extension wine shelves
oAccommodate 16 bottles of wine
oShelves can be removed and
adjusted to store large bottles
• Dual pane and argon-filled Low-E
energy efficient glass doors
• LED display lighting
• Forced air cooling system with
powerful 700 BTU compressor
• Tru-Flush™design allows unit to fit
flush in 24” deep cutout
• Undercounter or freestanding
installation
• Self-closing door
• Super quiet 32-39 db sound rating
• Black kickplate
• Must be ordered right or left hinge
(As you face unit, RIGHT has hinge on
right side and handle on left side; LEFT
has hinge on left side and handle on
right side.)
VBCI1240G
Professiona
FINISH DETAILS FOR VBCI MODELS
• Clear glass doors
oStainless Steel (SS)—stainless steel
frame around large window door,
stainless steel handle with chrome-
plated brackets, and stainless steel
exterior cabinet.
oStainless steel interior
Standard Features & Accessories
ORDERING INSTRUCTIONS
First specify model number, then specify hinge preference (“R” for right or “L” for left), and then color code (VBCI1240GRSS).
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
FINISH DETAILS FOR FBCI MODELS
• Clear glass doors.
• Stainless steel interior
• Handle not included—opt for custom
handle, or purchase a Viking
Professional Series handle kit (see
Insta ation Notes & Accessories).
• Accepts 3/4”-thick custom wood frame.
• See Custom Pane s section for more
information and additional
specifications.
FBCI1240G
Custom Pane
Model Options
REFRIGERATION
Undercounter/Freestanding
2 ”W. Beverage Center
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1- -VIKING1
✪
Please see
Insta ation Notes &
Accessories
for important
information,
including handle
kits.
Dimensions & Specifications
VBCI12 0G FBCI12 0G
Overall width 23-7/8” (60.6 cm)
Overall height 3 -1/ ” (87.0 cm) min. to 35” (89.0 cm) max.
Overall depth (from rear)
To front of handle 26-9/16” (67.5 cm) Varie
Approx. hip weight 215 lbs. (98.0 kg)
VBCI1240G
Professiona
FBCI1240G
Custom Pane
PRODUCT DIMENSIONS
See Custom Pane s section for
more information and additional
specifications.
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
22-1/16”
(56.0cm)
24-1/16”
(61.1cm)
26-9/16”
(67.5cm)
34-1/4”
(87.0cm)
min.
to
35”
(89.0cm)
max.
23-7/8”
(60.6cm)
23-7/8”
(60.6 cm)
23-7/8”
(60.6cm)
30-1/8”
(76.5cm)
PROFESSIONAL
REFRIGERATION
Undercounter/Freestanding
2 ”W. Beverage Center
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1- -VIKING1
Dimensions & Specifications
DOOR SWING
VBCI1240G
Professiona
FBCI1240G
Custom Pane
See Custom Pane s section for
more information and additional
specifications.
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
7-9/16”
(12.9 cm)
94.0 Swing
required for
pull-out shelf
clearance
2-27/32”
(5.6 cm) min.
clearance
from a corner
to achieve 94°
door swing
24-25/32”
(40.1 cm)
min. clearance
for door swing
Power cord 6-7/16”
(16.8 cm) off floor.*
50” (127.0 cm) area in which
electrical outlet must be located
PROFESSIONAL
REFRIGERATION
Undercounter/Freestanding
2 ”W. Beverage Center
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1- -VIKING1
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cord
with grounded
three-prong plug
attached to
product
• 115V/60 Hz; 15
amp dedicated
circuit
• Maximum amp
usage—3.0
PLUMBING
Not applicable
Installation Requirements
34-1/2” (87.6 cm) min.
35-1/2” (90.2 cm) max.
24”
(61.0 cm)
24” (61.0 cm)
ACCESS REQUIREMENTS
All models
Cutout width 2 ” (61.0 cm)
Cutout height 3 -1/2” (87.6 cm) min. to 35-1/2” (90.2 cm) max.
Cutout depth 2 ” (61.0 cm)
VBCI1240G
Professiona
FBCI1240G
Custom Pane
See Custom Pane s section for
more information and additional
specifications.
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
REFRIGERATION
Undercounter/Freestanding
2 ”W. Beverage Center
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1- -VIKING1
Hand e Kits
•
For use with custom panel 24”W. beverage center
• For use on locally supplied custom panels
•Handles allow custom panel products to coordinate with other Professional products
• Kit includes one handle and installation hardware
Compliance Information
WARRANTY SUMMARY*
• Three-year full warranty—complete unit
• Six-year full warranty—sealed refrigeration system (includes compressor, condenser,
dryer/strainer, evaporator, and connecting tubing)
• Twelve-year limited warranty—sealed refrigeration system
• Ninety-day limited warranty—cosmetic parts such as glass, painted items, and decorative items
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
PHK30-SS Profe ional handle (Stainle Steel) 6 (2.7)
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
