Viking RVEC3305B Manuel utilisateur

Warranty Highlights

•Three-year full – complete product

•Ninety-day full – cosmetic parts such as glass, painted items,

and decorative items

•Five-year limited – surface burners

ELECTRIC COOKTOPS

RVEC330-5B – 30” WIDE

RVEC336-5B – 36” WIDE

RVEC345-6B – 45” WIDE

45” Wide Electric Cooktop

Features and Functions

•Wide variety of surface element sizes and wattages

–30” wide model – 5 burners

• Left front – 8 1/2”, 2,000-watt dual element

•Left rear – 6 1/2”, 1,200-watt single element

•Center – 12”, 3,200-watt triple element

•Right front – 8 1/2”, 2,000-watt dual element

•Right rear – 6 1/2”, 1,200-watt single element

–36” wide model – 5 burners

•Left front – 8 1/2”, 2,000-watt dual element

•Left rear – 6 1/2”, 1,200-watt single element

•Center – 12”, 3,200-watt triple element

•Right front – 8 1/2”, 2,000-watt dual element

•Right rear – 6 1/2”, 1,200-watt single element

–45” wide model – 6 burners

•Left front – 8 1/2”, 2,000-watt dual element

•Left rear – 6 1/2”, 1,200-watt single element

•Left center – 12”, 3,200-watt triple element

•Right center – 8 1/2”, 2,000-watt dual element

•Right front – 8 1/2”, 2,000-watt dual element

•Right rear – 6 1/2”, 1,200-watt single element

•QuickCookTM Surface Elements utilize ribbon technology to

reach full power in about three seconds

• High infrared transmission for fast cooking, regardless of the

type of cookware used

Easy Operation and Cleanup

•Strong, wear-resistant glass ceramic surface with stainless steel

frame offers excellent cleanability

•Durable metal die-cast knobs with child-proof, push-to-turn

safety feature

•Customer-removable knobs for easy cleaning

•Overall/burner box dimensions designed to fit the majority of

similarly sized cooktop cutouts

Finish

•Available in Stainless Steel/Black (SB), featuring black glass

36” Wide Electric Cooktop

30” Wide Electric Cooktop

F60260

Viking Range, LLC | 1-888-845-4641 or 662-455-1200

For detailed product information, model numbers, or to request a quote visit vikingrange.com

0713

DESCRIPTION ELECTRIC 30”, 36”, AND 45” WIDE COOKTOPS

RVEC330-5B RVEC336-5B RVEC345-6B

Overall Width 30 3/4” (78.1 cm) 36 3/4” (93.3 cm) 45” (114.3 cm)

Overall Height 4 1/2” (11.4 cm)

Overall Depth 21" (53.3 cm)

Cutout Width 28 7/8” (73.3 cm) minimum

29 7/8” (75.9 cm) maximum

34 7/8” (88.6 cm) minimum

35 7/8” (91.1 cm) maximum

43 1/8” (109.5 cm) minimum

44 1/8” (112.1 cm) maximum

Cutout Height 3 1/8” (7.9 cm)

Cutout Height

with Conduit 4 1/8” (10.5 cm)

Cutout Depth 20” (50.8 cm) minimum; 20 1/4” (51.4 cm) maximum

Electrical Requirements 240-208/120VAC/60Hz; factory-installed, agency-approved 4 ft. (121.9 cm) flexible steel conduit

3-wire with ground included; rated 60-amp 125-250VAC minimum

Maximum Amp Usage 240V – 40.0 amps

208V – 34.6 amps

240V – 48.3 amps

208V – 41.9 amps

Element Rating

Left Front – 2,000 watts

Left Rear – 1,200 watts

Center – 3,200 watts

Right Front – 2,000 watts

Right Rear – 1,200 watts

Left Front – 2,000 watts

Left Rear – 1,200 watts

Center – 3,200 watts

Right Front – 2,000 watts

Right Rear – 1,200 watts

Left Front – 2,000 watts

Left Rear – 1,200 watts

Left Center – 3,200 watts

Right Center – 2,000 watts

Right Front – 2,000 watts

Right Rear – 1,200 watts

Approximate Shipping

Weight 52 lb. (23.4 kg) 60 lb. (27.0 kg) 71 lb. (32.0 kg)
