Copyright @2008 by this company. No. Part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system or translated into any language
or computer language, in any form or any means. Electronic, mechanical, magnetic,
optical, chemical, manual or otherwise, without the prior written permission of this
company.
SAFETY INSTRUCTION
1. Never push objects of any kind, or spill liquid of any kind into these products.
2. Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage points or other risk. Refer all servicing to
qualified service personnel, if any misuse mentioned above happened or any
accident dropping, miss-operations occurred.
Page 1 of 6
7. Security notes
The unit is only suitable for indoor use. The heat being generated in the unit has
to be removed via air circulation. Therefore the circulation vents at the housings
must not be covered with any objects.. Do not insert or drop anything into the air
vents ! This could result in a short-circuit. If the unit is used for purposes other
than originally intended, if it is connected in the wrong way or not repaired by
authorized skilled personnel, there is no liability for possible damage. To
cleaning only use a dry, soft cloth, by no means chemicals or water. If the unit is
to be scrapped then take it to a local recycling plant for disposal.
8. Technical Data
LCD technology : TFT active matrix
Display size: Diagonally measured 5.6”
Color system: NTSC and PAL Dual System
Sync. :.hor. 15 625 Hz, vert. 50 Hz.
Number of pixels: 960 x 234
Audio level: 1V/10k Battery Charger:15V 1A
Dimensions : LSM-6323 Front panel 193.8x 133.2 mm
Weight : 2 Kgs
