ViewSonic P220f - 22" CRT Display Manuel utilisateur

User Guide

Guide de l’utilisateur

Bedienungsanleitung

Guía del usuario

Guida dell’utente

Guia do usuário

Användarhandbok

Руководство пользователя

Podręcznik użytkownika

With Plug & Play

✘

22" (20" Viewable Diagonal)

P220f Color Monitor

Contents

Electronic Warranty Registration.......................... 2

For Your Records................................................. 2

Getting Started

Package Contents................................................ 3

Precautions .......................................................... 3

Quick Installation.................................................. 4

Using the Monitor

Setting the Timing Mode ...................................... 5

Adjusting the Screen Image ................................. 7

Other Information

Specifications ..................................................... 12

Troubleshooting ................................................. 13

Customer Support .............................................. 14

Cleaning the Monitor .......................................... 15

Limited Warranty ................................................ 16

Appendix

Power Cord Safety Guidelines ........................... 17

FCC Information................................................. 18

ViewSonic P220f 105/02/03 B

OSD Lock Setting ................................................ 6

Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.

Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft

Corporation in the United States and other countries.

ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of

ViewSonic Corporation.

VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC

are trademarks of VESA.

ENERGY STAR®is a registered trademark of the U.S. Environmental Protection Agency (EPA).

As an ENERGY STAR®partner, ViewSonic Corporation has determined that this product meets the

ENERGY STAR®guidelines for energy efficiency.

Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions

contained herein; nor for incidental or consequential damages resulting from furnishing this

material, or the performance or use this product.

In the interest of continuing product improvement, ViewSonic Corporation reserves the right to

change product specifications without notice. Information in this document may change without

notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any purpose

without prior written permission from ViewSonic Corporation.

Electronic Warranty Registration

To meet your future needs, and to receive any additional product information as it becomes available,

please register your monitor's warranty on the Internet at: http://www.viewsonic.com

Product disposal at end of product life

ViewSonic is concerned about the preservation of our environment. Please dispose of this product

properly at the end of its useful life. Your local waste disposal company may provide information

about proper disposal.

For Your Records

Product Name:

Model Number:

Document Number:

Serial Number:

Purchase Date:

ViewSonic P220f

VCDTS26344-1

A-CD-P220f-3

______________

ViewSonic P220f 2

Getting Started

Congratulations on your purchase of a ViewSonic color monitor.

Important! Save the original box and all packing material for future shipping

needs.

NOTE: The word “Windows” in this user guide refers to the following refers

to the following Microsoft operating systems: Windows ‘95, Windows NT,

Windows ‘98, Windows 2000,Windows ME (Millennium) and Windows XP.

Package Contents

Your package includes:

•Color monitor

• DB-15 video cable

• Power cord

•ViewSonic Wizard CD-ROM

Precautions

• For best viewing conditions sit at least

18"from the monitor.

• AVOID TOUCHING THE SCREEN

WITH YOUR FINGERS. Oils from the

skin are difficult to remove.

• NEVER REMOVE THE REAR

COVER. The monitor contains high-

voltage parts. You may suffer serious

injury if you touch these parts.

• Avoid exposing the monitor to direct

sunlight or another heat source. The

monitor should be facing away from

direct sunlight to reduce glare.

• Do not place your monitor near a source

of water or moisture.

• Place your monitor in a well ventilated

area. Do not place anything on the

monitor that blocks the ventilation slots

or prevents adequate dissipation of heat.

• Do not place heavy objects on the

monitor, video cable, or power cord.

• If smoke, abnormal noise, or strange

odor is present, immediately switch the

monitor off and call your dealer or

ViewSonic. It is dangerous to operate

your monitor under these conditions.

• Keep the monitor away from magnets,

motors, transformers and televisions.

ViewSonic P220f 3

NOTE: The CD jacket contains the Quick Start Guide, and the CD includes the

User Guide PDF files and INF/ICM display optimization files. The INF file

ensures compatibility with Windows operating systems, and the ICM file (Image

Color Matching) ensures accurate on-screen colors. ViewSonic recommends

that you install both files.

Quick Installation

1 Connect video cable(s)

Make sure both the monitor and computer

are powered OFF.

The monitor can be connected to one or two

computers using either the DB-15 video

cable (included) or a BNC video cable

(purchased separately). To toggle between

two computers: connect the DB-15 video

cable from the monitor to the first computer,

and the BNC video cables from the monitor

to the second computer.

Macintosh users: Models older than G3

require a ViewSonic Macintosh adapter.

Attach the adapter to the computer and plug

the video cable into the adapter.

To order a ViewSonic®Macintosh adapter,

contact ViewSonic. See Customer Support

in this user guide.

2 Connect power cord

Connect the power cord from the monitor to

a properly grounded AC outlet.

3 Power-ON monitor and computer

Power-ON the monitor, then power-ON the

computer. This sequence (monitor before

computer) is very important.

NOTE: At this point Windows users may

receive a message asking them to install the

P220f INF file.

4 Install Display Optimization files

(1) Insert the ViewSonic wizard CD-ROM

into your computer’s CD-ROM drive.

NOTE: if your computer does not have a

CD-ROM drive, see the Customer Support

section of this user guide.

(2) Wait for the CD-ROM to auto-start.

NOTE: if the CD-ROM does not auto-start:

double-click on the CD-ROM icon in

Windows Explorer, then double-click on

viewsonic.exe

(3) Follow the on-screen instructions.

5 Windows users: Set the Timing

Mode (resolution and refresh rate)

Example: 1600 X 1200 @ 85 Hz.

For instructions on changing the resolution

and refresh rate, see the user guide for your

computer's graphics card.

Installation is complete. Enjoy your new

P220f monitor!

To be best prepared for any future customer

service needs:

Write the serial number (see back of the

monitor) in “For your Records” on page 2

of this guide.

Internet at: www.viewsonic.com

Port for DB-15

video cable

Power Cord

from monitor

to AC outlet

Power Cord

from computer

to AC outlet

ViewSonic P220f 4

Using the Monitor

Setting the Timing Mode

Setting the timing mode is important for maximizing the quality of the

screen image and minimizing eye strain. The timing mode consists of the

resolution (example 1280 x 1024) and refresh rate (or vertical frequency;

example 75 Hz). After setting the timing mode, use the OnView®controls

to adjust the screen image.

The recommended timing mode for this monitor is:

VESA 1600 x 1200 @ 85 Hz.

To set the Timing Mode:

1Set the resolution: Right-click on the Windows®desktop > Properties >

Settings > Desktop Area (Screen Area for Windows 95 and newer) > set the

resolution.

2Set the refresh rate: See your graphic card's user guide for instructions.

NOTE: To minimize the adjustments required for an optimal screen image,

select a timing mode from the Preset Timing Modes table below.

WA R N I N G : Do NOT set the graphics card in your computer to exceed the

maximum refresh rates; doing so may result in permanent damage to your

monitor.

(NI = Non Interlaced)

Preset Timing Modes

VGA 640 x480@60Hz

VGA 720 x 400 @ 70 Hz

VESA 800 x 600 @ 85 Hz

VESA 1024 x 768 @ 75 Hz

VESA 1024 x 768 @ 85 Hz

VESA 1280 x 1024 @ 75 Hz

VESA 1280 x 1024 @ 85 Hz

VESA 1600 x 1200 @ 75 Hz

VESA 1600 x 1200 @ 85 Hz

VESA (GTF) 2048 x 1536 @ 60 Hz

Macintosh 1152 x 870 @ 75 Hz

Timing Modes with Maximum Refresh Rates

2048 x 1536 NI @ 68 Hz

1920 x 1440 NI @ 73 Hz

1600 x 1200 NI @ 87 Hz

1280 x 1024 NI @ 101 Hz

1152 x 864 NI @ 118 Hz

1024 x 768 NI @ 132 Hz

800 x 600 NI @ 160Hz

640 x 480 NI @ 160Hz

ViewSonic P220f 5

ViewSonic P220f 6

OSD Lock Settings

You have the option of using the On Screen Display (OSD) locking feature,

OSD LOCK, to prevent unwanted changes to the current image settings.

•OSD Lock: Press and hold the [1] and [▼]buttons on the face of the monitor

for 5 seconds. The message “OSD LOCK” will then display briefly,

indicating that the OSD image settings are now locked.

•OSD Unlock: Press and hold the [1] and [▼]buttons again for 5 seconds. The

message “OSD UNLOCK” will then display briefly, indicating that the OSD

image settings are now unlocked.

Adjusting the Screen Image

Beginning with the Main Menu shown below, use the buttons on the front

control panel to adjust the OnView®controls which display on the screen. The

OnView controls are explained in the four steps at the top of the next page and

are further explained on pages 8-10.

IMPORTANT: The monitor should be warmed up for 30 minutes prior to

making any adjustments.

Main Menu with OnView controls

ViewSonic P220f 7

Power Light

Power On/Off

Displays control screen for

highlighted control (or pair

of controls). Also, toggles

between pairs of controls on

some control screens.

Displays Main Menu;

also saves changes/

exits Main Menu.

Scrolls through menu

options and adjusts

the displayed control.

Front Control Panel

Zoom expands and contracts the entire screen image

To adjust the screen image:

1To display the Main Menu (parts 1-3 shown below), press button [1].

2To select a control you want to adjust, press the arrow buttons on the front

control panel of your monitor (▼▲) and scroll through the choices.

When the control you want to adjust is highlighted, press button [2].

NOTE: Some controls on the Main Menu are listed in pairs, such as

Contrast/Brightness. Press button [2] to toggle between control pairs after

displaying a control screen.

3To adjust the selected control, press the arrow buttons (▼▲).

4To save the control setting and Exit the menu, press button [1] twice.

With Main Menu

highlighted, as

shown on the left,

press button [2] to

toggle to the next

Main Menu.

With a control

highlighted, button [2]

displays a control

screen for making

adjustments.

ViewSonic P220f 8

Main Menu Controls

The menu items shown below can be adjusted by using the arrow buttons (▲▼)

on the front of your monitor.

Control Explanation

Contrast adjusts the difference between the image

background (black level) and the foreground (white level).

Shortcut: Before displaying the Main Menu, press ▼or ▲

to display the Contrast/Brightness control screen.

Brightness adjusts the background black level of the screen

image.

Horizontal Size adjusts the width of the screen image.

Horizontal Position moves the screen image left or right.

Vertical Size adjusts the height of the screen image.

Vertical Position moves the screen image up or down.

Pincushion straightens curves along the vertical edges of

the screen image that bow inward or outward.

Pin Balance straightens curves along the vertical edges of

the screen image that bow in the same direction.

Trapezoid adjusts the top and bottom of the screen image

until they have equal length.

Parallel slants the vertical edges of the screen image until

they are parallel.

Zoom expands and contracts the entire screen image.

Tilt rotates the entire screen image.

ViewSonic P220f 9

Degauss removes the build-up of magnetic fields that can

cause irregular colors to appear around the edges of screen

images. Your monitor will degauss automatically each time

you power it on.

Table des matières

Autres manuels ViewSonic Moniteur

ViewSonic

ViewSonic VE150m Manuel utilisateur

ViewSonic

ViewSonic VE902m Manuel utilisateur

ViewSonic

ViewSonic VE500 - 15" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic TD1655 Manuel utilisateur

ViewSonic

ViewSonic VA2246m-LED Manuel utilisateur

ViewSonic

ViewSonic VA2757-2K-HD Manuel utilisateur

ViewSonic

ViewSonic ND4210w Manuel utilisateur

ViewSonic

ViewSonic E773 Manuel utilisateur

ViewSonic

ViewSonic VA2223WM - 21.5" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VA1703w-1 Manuel utilisateur

ViewSonic

ViewSonic CDP4260-TL Manuel utilisateur

ViewSonic

ViewSonic ViewBoard IFP50 Series Manuel utilisateur

ViewSonic

ViewSonic VA912B - 19" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic OptiSync VX710 Guide de référence

ViewSonic

ViewSonic VX2239w Manuel utilisateur

ViewSonic

ViewSonic VG730M - 17" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VA902B - 19" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VA703M - 17" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VS12415 Manuel utilisateur

ViewSonic

ViewSonic VG2450-2 Manuel utilisateur

ViewSonic

ViewSonic VA1913w Manuel utilisateur

ViewSonic

ViewSonic VA2432-h Manuel utilisateur

ViewSonic

ViewSonic VA1930wm-1 Manuel utilisateur

ViewSonic

ViewSonic VG2030WM - 20" LCD Monitor Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
