ViewSonic LCD Display VA1912w-1 Manuel utilisateur

Model No. VS10866

19” Color TFT LCD Display

Service Manual

ViewSonic VA1912w-1

ViewSonic

381 Brea Canyon Road, Walnut, California 91789 USA - (800) 888-8583

(VA1912W-1_VA1912Wb-1_SM Rev. 1b Aug. 2006)

VA1912wb-1

Revision History

Revision SM Editing Date ECR Number Description of Changes Editor

1a 10/25/05 Initial Release G. Han

ViewSonic CorporationConfidential

Do Not Copy

1b08/23/06 6224 Scaler change (updated RSPL , BOM , Schematic diagram)J. Chang

VA1912w-1

VA1912wb-1

may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any

language or computer language, in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual or otherwise, without the prior written permission of ViewSonic

Corporation.

Disclaimer

ViewSonic makes no representations or warranties, either expressed or implied, with respect to

the contents hereof and specifically disclaims any warranty of merchantability or fitness for any

particular purpose. Further, ViewSonic reserves the right to revise this publication and to make

changes from time to time in the contents hereof without obligation of ViewSonic to notify any

person of such revision or changes.

Trademarks

Optiquest is a registered trademark of ViewSonic Corporation.

ViewSonic is a registered trademark of ViewSonic Corporation.

All other trademarks used within this document are the property of their respective owners.

ViewSonic CorporationConfidential

Do Not Copy VA1912w-1

VA1912wb-1

TABLE OF CONTENTS

1. Precautions and Safety Notices

2. Specification

3. Front Panel Function Control Description

4. Circuit Description

5. Adjustment Procedure

6. Troubleshooting Flow Chart

7. Recommended Spare Parts List

8. Exploded Diagram and Exploded Parts List

9. Block Diagram

10. Schematic Diagrams

11. PCB Layout Diagrams

1. Precautions and Safety Notices

1. Appropriate Operation

(1) Turn off the product before cleaning.

(2) Use only a dry soft cloth when cleaning the LCD panel surface.

(3) Use a soft cloth soaked with mild detergent to clean the display housing.

(4) Use only a high quality, safety approved AC/DC power cord.

(5) Disconnect the power plug from the AC outlet if the product will not be used for a long period of time.

(6) If smoke, abnormal noise, or strange odor is present, immediately switch the LCD display off.

(7) Do not touch the LCD panel surface with sharp or hard objects.

(8) Do not place heavy objects on the LCD display, video cable, or power cord.

(9) Do not use abrasive cleaners, waxes or solvents for your cleaning.

(10) Do not operate the product under the following conditions:

- Extremely hot, cold or humid environment.

- Areas containing excessive dust and dirt.

- Near any appliance generating a strong magnetic field.

- In direct sunlight.

2. Caution

No modification of any circuit should be attempted. Service work should only be performed after you are thoroughly

familiar with all of the following safety checks and servicing guidelines.

3. Safety Check

Care should be taken while servicing this LCD display. Because of the high voltage used in the inverter circuit, the voltage

is exposed in such areas as the associated transformer circuits.

4. LCD Module Handling Precautions

4.1 Handling Precautions

(1) Since front polarizer is easily damaged, pay attention not to scratch it.

(2) Be sure to turn off power supply when connecting or disconnecting input connector.

(3) Wipe off water drops immediately. Long contact with water may cause discoloration or spots.

(4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.

(5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.

(6) Since CMOS LSI is used in this module, take care of static electricity and ensure human earth when handling.

(7) Do not open or modify the Module Assembly.

(8) Do not press the reflector sheet at the back of the module in any direction.

(9) In the event that a Module must be put back into the packing container slot after it was taken out of the

container, do not press the center of the CCFL Reflector edge. Instead, press at the far ends of the

CFL Reflector edge softly. Otherwise the TFT Module may be damaged.

(10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate or tilt the Interface

Connector of the TFT Module.

ViewSonic CorporationConfidential

Do Not Copy VA1912w-1

VA1912wb-1

(11) After installation of the TFT Module into an enclosure (LCD monitor housing, for example), do not twist or

bend the TFT Module even momentarily. When designing the enclosure, it should be taken into consideration

that no bending/twisting forces may be applied to the TFT Module from outside. Otherwise the TFT Module

may be damaged.

(12) The cold cathode fluorescent lamp in the LCD contains a small amount of mercury. Please follow local

ordinances or regulations for disposal.

(13) The LCD module contains a small amount of materials having no flammability grade. The LCD module

should be supplied with power that complies with the requirements of Limited Power Source

(IEC60950 or UL1950), or an exemption should be applied for.

(14) The LCD module is designed so that the CCFL in it is supplied by a Limited Current Circuit (IEC60950

or UL1950). Do not connect the CCFL to a Hazardous Voltage Circuit

ViewSonic CorporationConfidential

Do Not Copy VA1912w-1

VA1912wb-1

Correct methods : Incorrect Methods :

Only touch the metal-frame of the panel or the front

cover of the monitor.

Do not touch the surface of the polarizer .

Surface of the panel is pressed by fingers & this may

cause “ MURA “

Take out the monitor with cushion Take out the monitor by grasping the LCD panel.

That may cause “ MURA“.

Place the monitor on a clean & soft foam pad . Place the monitor on foreign objects .

That could scratch the surface of panel

ViewSonic CorporationConfidential

Do Not Copy

VA1912w-1

VA1912wb-1

2. Specification

ViewSonic CorporationConfidential

Do Not Copy

INTRODUCTION

FEATURES VA1912w / VA1912wb

Size 19” wide

Luminance (Typ, cd/㎡) 300 cd/㎡

Contrast Ratio (Typ) 500:1

Colors ( 6 bit + 2 bit FRC) 16.2 M colors

Response Time (Typ) 8 ms

Viewing Angle (H/V) 150 ° / 130 °

TFTLCD PANEL

Recommend resolution 1440 x 900@60Hz

Analog (75ohms, 0.7/1.0 Vp-p) Yes

Input Signal Digital Yes

Separate Sync Yes

Composite Sync No

Sync Compatibility

Sync on Green No

PC Yes

Power Mac Yes

Compatibility

TV Box (NextVision 6) Yes

Power Voltage AC 100-240V, 50/60Hz Yes

On Mode(Max / Typ) 36W(max) / 32W(typ)

Power

Consumption Sleeping Mode (Max) ≦2W

Audio Amplifier / Speaker 1.5 W / 2.5W x 2

Tilt ( 20 ° to -5 °) Yes

Swivel No

Pivot No

Ergonomics

Height Adjust No

OSD Control [;X] [ 1 ] [▼] [▲] [ 2 ] [ ] Yes

Physical (W x H x D mm) 451 x 391 x 197 (mm)

17.8 x 15.4 x 7.8 (in)

Dimension

Package (W x H x D mm) 538 x 470 x 158 (mm)

21.2 x 18.5 x 6.2 (in)

Physical (Net kg/lb) 4.5kg (9.9lb)

Weight Package (Gross Kg/lb) 6.2kg (13.7lb)

Temperature ( / )℉℃ 41℉-95 /℉+5℃-+35℃Operating

Condition Humidity (%) 20 % - 80 %

Temperature ( / )℉℃ -4℉-131 /℉-20℃-55℃

Storage Condition Humidity (%) 20 % - 85 %

Regulation

CB / TCO03 / UL/cUL / FCC-B / ICES 003 / Argentina-TUV/S /

NOM / EPA Energy Star / TUV/Ergo / ISO13406-2 / TUV/GS / CE

/ GOST-R / SASO / BSMI / PSB / C-Tick / Korea (MIC) / CCC

GENERAL specification

Test Resolution & Frequency 1440 x 900 @ 60Hz

Test Image Size Full Size

Contrast and Brightness Controls Factory Default:

Contrast = 70%, Brightness = 100%

VA1912w-1

VA1912wb-1

VIDEO INTERFACE

Analog Input Connector DB-15 (Analog), refer the appendix A

Digital Input Connector N/A

Default Input Connector Defaults to the first detected input

Video Cable Strain Relief Equal to twice the weight of the monitor for five minutes

Video Cable Connector DB-15 Pin out Compliant DDC 2B

Video Signals

1. Video RGB (Analog)

2. DVI (Digital)

Separate

Video Impedance 75 Ohms (Analog)

Maximum PC Video Signal 950 mV with no damage to monitor

Maximum Mac Video Signal 1250 mV with no damage to monitor

Sync Signals TTL

DDC 2B Compliant with Revision 1.3

Sync Compatibility Separate Sync

Video Compatibility Shall be compatible with all PC type computers,

Macintosh computers, and after market video cards

Resolution Compatibility

640 x 350*, 640 x 480, 720 x 400* (640 x 400*), 800 x

600, 832 x 624, 1024 x 768, 1152 x 864, 1280 x 768,

1280 x 960, 1280 x 1024, 1440 x 900

* The image vertical size might not be full screen.

But the image vertical position should be at the center.

Exclusions Not compatible with interlaced video

ViewSonic CorporationConfidential

Do Not Copy

VA1912w-1

VA1912wb-1

PRODUCT DEFINITION AND SPECIFICATION

Region VSA (M) VSAP (J) VSE (E) VSCN (G)

Product Name VA1912w / VA1912wb

Model Number VS10866

OSD Languages

English, French, German, Italian, Spanish,

Finnish, Japanese, Traditional Chinese,

Simplified Chinese

TFT LCD Panel and Model # Vendor : CMO, Model # : A190A2

Scalar Model # : Mstar TSU M57AK

Input Signal Analog / Digital

Sync Compatibility Separate

Audio Amplifier 1.5W x 2 / Speaker 2.5W x 2

Adapter NO

Power Cable Refer to Appendix D

Analog Cable (1.8 m, color : black), with PC

2001 and Hot Plug Detect &DDC YES

Audio Cable (1.8m, Color: black) with PC

2001 YES

DVI Cable(1.8m, color: black) with PC 2001 Yes Yes No Yes

ViewSonic CD Wizard

ViewSonic Quick Start Guide

Arabic, English, Finnish, Spanish, German,

Italian, Swedish, Polish, Korean, Portuguese,

Russian, French, Simplified Chinese,

Traditional Chinese, Hungary, Czech, Turkish

Screen Protector Mylar YES YES YES YES

Warranty Sticker NO NO NO YES

Warranty Card NO NO NO YES

Carton Sticker NO NO NO YES

PE bag of Carton NO NO NO NO

ViewSonic CorporationConfidential

Do Not Copy

ELECTRICAL REQUIREMENT

Horizontal / Vertical Frequency

Horizontal Frequency 30 – 82 KHZ

Vertical Refresh Rate 50 – 85* HZ.

Maximum Pixel Clock 135 MHz (EDID file is 140MHz)

Sync Polarity Independent of sync polarity.

VA1912w-1

VA1912wb-1

Power Supply (Adapter) Part Number: 27-D003247

Input Voltage Range 90 TO 264 VAC

Input Frequency Range 47 TO 63 HERTZ

Short Circuit Protection Output can be shorted without damage

Over Current Protection FUSE 3.15A typical at 250 VAC

Leakage Current 75 mA (Max) at 240VAC / 50Hz

EFFICIENCY 80 % typical at 100VAC @60Hz

Fuse Internal and not user replaceable

Power Dissipation 36 Watts

Max Input AC Current 1.6 Arms @ NOMINAL range

INRUSH CURRENT (COLD START) 80 A @ 240VAC , 50Hz

Power Supply Cold Start

Shall start and function properly when

under full load, with all combinations of

input voltage, input frequency, and

operating temperature

Power Supply Transient Immunity Shall be able to withstand an EN61000-4-4

±2KV transient test with no damage

Power Supply Line Surge Immunity Shall be able to withstand ±2KV (L-L) and

±2.3KV (L-PE) with no damage

Power Supply Missing Cycle Immunity

Shall be able to function properly, without

reset or visible screen artifacts, when ½

cycle of AC power is randomly missing at

nominal input

Power Supply Acoustics

The power supply shall not produce audible

noise that would be detectable by the user.

Audible shall defined to be in compliance

with ISO 7779 (DIN EN27779:1991) Noise

measurements of machines acoustics.

Power Switch noise shall not be considered

Power Saving Operation(Method) VESA DPMS Signaling

Power Consumption

ON Mode < 36 W (max) / 32 W (typ)

SEELPING MODE < 2W

OFF MODE < 1W

Recovery Time ON MODE = N/A, ACTIVE OFF < 5 SEC

4-3 POWER SUPPLY

FRONT PANEL CONTROLS AND INDICATORS

Front Panel Hardware Controls

Power Switch (Front Head) Power Control, soft Power Switch.

Power LED (Front Head) Green – ON

Orange – Active Off

Dark = Soft Power Switch OFF

Front Panel Controls (Head)

[;X] [ 1 ] [▼] [▲] [ 2 ] [ ]

[] Power

[ 1 ] Button 1

[ 2 ] Button 2

[▲] Up arrow button

[▼] Down arrow button

[;X] AUDIO MUTE ON/OFF

Note: Power Button, Button 1 and Button 2 and Mute

Button must be one-shot logic operation. (i.e. there should

be no cycling)

Reaction Time OSD must fully appear within 0.5s after pushing Button 1

Short Cuts Function from the button(s)

[1] Main Menu

[2] Input toggle (Analog or Digital)

[▼] or [▲] To immediately activate Contrast menu. It should be change to Brightness

OSD by push button [2]

[▼] + [▲] Recall both of Contrast and Brightness to default

[1] + [2] Toggle 720x400 and 640x400 mode when input 720x400 or 640x400

mode

[1] + [▼] + [▲] White Balance. (Not shown on user’s guide)

[1] + [▼] Power Lock

[1] + [▲] OSD Lock

[;X] Audio Mute on /off

Remark : All the short cuts function are only available while OSD off

ViewSonic CorporationConfidential

Do Not Copy

VA1912w-1

VA1912wb-1

Timing Table

Item Timing Analog Digital

1 640 x 350 @ 70Hz, 31.5kHz Yes Yes

2 640 x 400 @ 60Hz, 31.5kHz Yes* Yes

3 640 x 400 @ 70Hz, 31.5kHz Yes Yes

4 640 x 480 @ 60Hz, 31.5kHz Yes Yes

5 640 x 480 @ 67Hz, 35.0kHz Yes Yes

6 640 x 480 @ 72Hz, 37.9kHz Yes Yes

7 640 x 480 @ 75Hz, 37.5kHz Yes Yes

8 640 x 480 @ 85Hz, 43.27kHz Yes Yes

9 720 x 400 @ 70Hz, 31.5kHz Yes Yes

10 800 x 600 @ 56Hz, 35.1kHz Yes Yes

11 800 x 600 @ 60Hz, 37.9kHz Yes Yes

12 800 x 600 @ 75Hz, 46.9kHz Yes Yes

13 800 x 600 @ 72Hz, 48.1kHz Yes Yes

14 800 x 600 @ 85Hz, 53.7kHz Yes Yes

15 832 x 624 @ 75Hz, 49.7kHz Yes Yes

16 1024 x 768 @ 60Hz, 48.4kHz Yes Yes

17 1024 x 768 @ 70Hz, 56.5kHz Yes Yes

18 1024 x 768 @ 72Hz, 58.1kHz Yes Yes

19 1024 x 768 @ 75Hz, 60.0kHz Yes Yes

20 1024 x 768 @ 85Hz, 68.67kHz Yes Yes

21 1152 x 864@ 75Hz, 67.5kHz Yes Yes

22 1280 x 1024 @ 60Hz, 63.4kHz Yes Yes

23 1280 x 1024 @ 75Hz, 79.97kHz Yes No

24 1280x 768 @ 60Hz, 47.78kHz Yes Yes

25 1280 x 960 @60Hz, 60kHz Yes Yes

26 1440 x 900 @ 60Hz, 55.96kHz Yes Yes

*The image vertical size might not be full screen.

Autres manuels pour LCD Display VA1912w-1

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ViewSonic Moniteur

ViewSonic

ViewSonic VA2418-SMH Manuel utilisateur

ViewSonic

ViewSonic VLED221WM - 22" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VG921m-4 VS11369 Manuel utilisateur

ViewSonic

ViewSonic VX900 - 19" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic XG2402 Manuel utilisateur

ViewSonic

ViewSonic Q71B - Optiquest - 17" CRT Display Manuel utilisateur

ViewSonic

ViewSonic TD2465 Manuel utilisateur

ViewSonic

ViewSonic VS17729 Manuel utilisateur

ViewSonic

ViewSonic VX2000-1 Manuel utilisateur

ViewSonic

ViewSonic VG2030WM - 20" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VS17984 Manuel utilisateur

ViewSonic

ViewSonic VSD243 Manuel utilisateur

ViewSonic

ViewSonic VP930 Manuel utilisateur

ViewSonic

ViewSonic VA1703WB - 17" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic ND4200 Manuel utilisateur

ViewSonic

ViewSonic VA2759 Manuel utilisateur

ViewSonic

ViewSonic E75 Manuel utilisateur

ViewSonic

ViewSonic VP950B - 19" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VA2431wm Manuel utilisateur

ViewSonic

ViewSonic VG2236wm-LED Manuel utilisateur

ViewSonic

ViewSonic PF790 - 19" CRT Display Manuel utilisateur

ViewSonic

ViewSonic VX2718-2KPC-mhd Manuel utilisateur

ViewSonic

ViewSonic VA703B - 17" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VG712 Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
