ViewSonic G510b Manuel utilisateur

With Landscape & Portrait Display Modes

Full 15" Diagonal Viewable Screen

VG510b LCD Display

VG510s

User Guide

Guide de l’utilisateur

Bedienungsanleitung

Guía del usuario

Guida dell'utente

Guia do usuário

Användarhandbok

Käyttöopas

Jmdh\h^kl\hihevah\Zl_ey

,QVWUXNFMDREVáXJL

Contents

Product Registration .................................................. 2

For Your Records ...................................................... 2

Getting Started ..................................................... 3

Package Contents ..................................................... 3

Precautions ............................................................... 3

Quick Installation ....................................................... 4

Installation of Wall Mount (Optional) ......................... 5

Using the LCD Display ......................................... 6

Setting the Timing Mode ...........................................6

OSD and Power Lock Settings .................................. 6

Adjusting the Screen Image ...................................... 7

Main Menu Controls .................................................. 9

Other Information ............................................... 12

Specifications .......................................................... 12

Troubleshooting ...................................................... 13

Customer Support ................................................... 14

Cleaning the LCD Display ....................................... 15

Limited Warranty ..................................................... 16

Safety Guidelines .................................................... 17

Compliance Information for U.S.A. ..........................18

08/11/03 A ViewSonic

VG510b/VG510s 1

CE Conformity for Europe ....................................... 18

Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.

Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft

Corporation in the United States and other countries.

ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of

ViewSonic Corporation.

VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC

are trademarks of VESA.

ENERGY STAR®is a registered trademark of the U.S. Environmental Protection Agency (EPA).

As an ENERGY STAR®partner, ViewSonic Corporation has determined that this product meets the

ENERGY STAR®guidelines for energy efficiency.

Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions

contained herein; nor for incidental or consequential damages resulting from furnishing this mate-

rial, or the performance or use of this product.

In the interest of continuing product improvement, ViewSonic Corporation reserves the right to

change product specifications without notice. Information in this document may change without

notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any purpose

without prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes available,

please register your product on the Internet at: www.viewsonic.com. The ViewSonic®Wizard CD-

ROM also provides an opportunity for you to print the registration form, which you may mail or fax

to ViewSonic.

Product disposal at end of product life

ViewSonic is concerned about the preservation of our environment. Please dispose of this product

properly at the end of its useful life. Your local waste disposal company may provide information

about proper disposal.

For Your Records

Product Name:

Model Number:

Document Number:

Serial Number:

Purchase Date:

ViewSonic VG510b/VG510s

VLCDS27955-2W/VLCDS27955-1W

A-CD-VG510b-1/A-CD-VG510s-1

______________

ViewSonic

VG510b/VG510s 2

Getting Started

Congratulations on your purchase of a ViewSonic®LCD Display®.Important!

Save the original box and all packing material for future shipping needs.

NOTE: The word “Windows” in this user guide refers to the following

Microsoft operating systems: Windows ‘95, Windows NT, Windows ‘98,

Windows 2000, Windows Me (Millennium), and Windows XP.

Package Contents

• LCD display

• VGA cable

•

AC/DC power adapter

•

Power cords

•

Audio cable (for speakers)

ViewSonic Wizard CD-ROM

•NOTE: The CD jacket contains the Quick Start Guide, and the CD includes

the User Guide PDF files and INF/ICM display optimization files. The INF

file ensures compatibility with Windows operating systems, and the ICM file

(Image Color Matching) ensures accurate on-screen colors. ViewSonic

recommends that you install both files

Precautions

• Sit at least 18" from your LCD display.

•Avoid touching the screen. Skin oils are

difficult to remove.

•Never remove the rear cover. Your LCD

display contains high-voltage parts. You may

be seriously injured if you touch them.

• Avoid exposing your LCD display to direct

sunlight or another heat source. Orient your

LCD display away from direct sunlight to

reduce glare.

• Always handle your LCD display with care

when moving it.

• Place your LCD display in a well-ventilated

area. Do not place anything on your LCD

display that prevents heat dissipation.

• Ensure the area around the LCD display is

clean and free of moisture.

• Do not place heavy objects on the LCD

display, video cable, or power cord.

• If smoke, abnormal noise, or strange odor is

present, immediately switch the LCD display

off and call your dealer or ViewSonic. It is

dangerous to continue using the LCD display.

ViewSonic

VG510b/VG510s 3

Quick Installation

1 Connect power cord and AC/DC

adapter

2 Connect video cable

• Make sure both the LCD display and

computer are turned OFF

• Remove rear panel covers if necessary

• Connect the video cable from the LCD

display to the computer

Macintosh users: Models older than G3

require a Macintosh adapter. Attach the

adapter to the computer and plug the video

cable into the adapter.

To order a ViewSonic®Macintosh adapter,

contact ViewSonic Customer Support.

3 Turn ON LCD display and

computer

Turn ON the LCD display, then turn ON the

computer. This sequence (LCD display

before computer) is important.

NOTE: Windows users may receive a

message asking them to install the INF file.

This is on the CD.

4 Insert the ViewSonic Wizard CD

into the computer’s CD drive.

Follow the on-screen instructions

If your computer does not have a CD-ROM

drive, see “Customer Support."

(1) Wait for the CD-ROM to auto-start.

NOTE: If the CD-ROM does not auto-start:

double-click on the CD-ROM icon in the

Windows Explorer, then double-click on

viewsonic.exe.

4 Wizard CD (continued)

(2) Follow the on-screen instructions.

5 Audio Installation (optional)

• Speakers Connect the audio cable (lime-colored) to

the AUDIO OUT port of your computer’s sound

card, then to the LCD display’s AUDIO IN port

(see illustration below).

• Microphone Connect the microphone cable (pink-

colored to the MIC IN port of your computer’s

sound card, then to the LCD display’s MIC OUT

port (See illustration below.)

6 Windows users: Set the timing

mode (resolution and refresh

rate)

Example: 1024 x 768 @ 60 Hz.

For instructions on changing the resolution

and refresh rate, see the graphic card’s user

guide.

Installation is complete. Enjoy your new

ViewSonic, LCD display.

To be best prepared for any future customer

service needs: print this user guide and write

the serial number in "For Your Records" on

page 2. (See back of LCD display.)

You can register your product online at the

website for your region. See the Customer

Support table in this guide.

The ViewSonic Wizard CD-ROM also

provides an opportunity for you to print the

registration form which you may mail or fax

to ViewSonic.

AC IN

Power cord

and AC/DC

adapter

Rear panel

covers

Audio

cable

Video

cable

AC outlet

(wall socket) Computer

power cord

ViewSonic

VG510b/VG510s 4

Installation of Wall Mount (Optional)

To obtain a wall-mounting kit, contact ViewSonic or your local dealer. Refer to

the instructions that come with the base mounting kit. To convert your LCD

display from a desk-mounted to a wall-mounted display, do the following:

1Disconnect Power.

2Lay the LCD display face down

on a towel or blanket. If you

remove the base for a wall mount,

the microphone in the base is

disconnected. But, you can leave

the base attached to the LCD

display with the wall mount.

Notice the four screw holes for

the wall mount on the back as

shown on the left.

3Attach the mounting bracket

from the VESA compatible wall-

mounting kit (75mm x 75mm

distance).

4Attach the LCD display to the

wall, following the instructions in

the wall-mounting kit.

Four screw holes for wall mount

ViewSonic

VG510b/VG510s 5

Using the LCD Display

Setting the Timing Mode

Setting the timing mode is important for maximizing the quality of the

screen image and minimizing eye strain. The timing mode consists of the

resolution (example 1280 x 1024) and refresh rate (or vertical frequency;

example 60 Hz). After setting the timing mode, use the OnView®controls

to adjust the screen image.

For the best picture quality set your LCD display timing mode to:

VESA 1024 x 768 @ 60 Hz.

To set the Timing Mode:

1Set the resolution: Right-click on the Windows®desktop > Properties >

Settings > set the resolution.

2Set the refresh rate: See your graphic card's user guide for instructions.

WA R N I N G : Do not set the graphics card in your computer to exceed the

maximum refresh rate of 85Hz; doing so may result in permanent damage to

your LCD display.

OSD and Power Lock Settings

•OSD Lock: Press and hold [1] and the up arrow ▲for 10 seconds. If any

buttons are pressed the message OSD Locked will display for a few seconds.

•OSD Unlock: Press and hold [1] and the up arrow ▲again for 10 seconds.

•Power Button Lock: Press and hold [1] and the down arrow ▼for 10

seconds. If the power button is pressed the message Power Button Locked

will display for a few seconds. With or without this setting, after a power

failure, your LCD display’s power will automatically turn on when power is

restored.

•Power Button Unlock: Press and hold [1] and the down arrow ▼again for

10 seconds.

ViewSonic

VG510b/VG510s 6

Adjusting the Screen Image

Use the buttons on the front control panel to display and adjust the OnView®

controls which display on the screen. The OnView controls are explained at the

top of the next page and are defined in “Main Menu Controls” on page 9.

Scrolls through menu options and

adjusts the displayed control.

Also a shortcut to display the

Contrast adjustment control

screen.

Power

On/Off

Displays the control

screen for the highlighted

control.

Also toggles between two

controls on some

screens.

Also a shortcut to toggle

between analog and

digital connections.

Power light

Green = ON

Orange = Power

Saving

Main Menu with OnView controls

Front Control Panel shown

below

Audio Mute button

turns the sound off.

Displays the Main Menu

or exits the control screen

and saves adjustments

Decreases or

increases volume

Speaker Speaker

ViewSonic

VG510b/VG510s 7

The following tips may help you optimize your display:

• Adjust your computer's graphic card so that it outputs a video signal 1024 x

768 @ 60 Hz to the LCD display. (Look for instructions on "changing the

refresh rate" in your graphic card's user guide.)

• If necessary, make small adjustments using H POSITION and V POSITION

until the screen image is completely visible. (The black border around the

edge of the screen should barely touch the illuminated "active area" of the

LCD display.)

Do the following to adjust the screen image:

1To display the Main Menu, press button [1].

NOTE: All OnView menus and adjustment screens disappear automatically

after about 30 seconds. This time period is adjustable through the Setup

menu and the OSD timeout control described on page 11.

2To highlight a control you want to adjust, press ▲or ▼to scroll up or down

the Main Menu.

3To select the highlighted control, press button [2]. A control screen appears

like the example shown below.

4To adjust the control, press the up ▲or down ▼buttons.

5To save the adjustments and exit the menu, press button [1] twice.

The ▼down

arrow decreases,

▲up arrow

increases.

The line at the

bottom of the screen

tells you what you

can do next - in this

example, either EXIT

or select the

BRIGHTNESS

control.

ViewSonic

VG510b/VG510s 8

Main Menu Controls

Adjust the menu items shown below by using the up and down buttons.

Control Explanation

Auto Image Adjust automatically sizes, centers, and fine tunes

the video signal to eliminate waviness and distortion.

Press the [2] button to obtain a sharper image.

NOTE:Auto Image Adjust works with most common video

cards. If this function does not work on your LCD display, then

lower the video refresh rate to 60 Hz and set the resolution to its

pre-set value.

Contrast adjusts the difference between the image background

(black level) and the foreground (white level).

Brightness adjusts background black level of the screen image.

Color Adjust provides several color options: preset color

temperatures and User Color which allows you to adjust red (R),

green (G), and blue (B). The factory setting for this product is

6500K (6500 Kelvin).

9300K — Adds blue to the screen image for cooler white (used

in most office settings with fluorescent lighting).

6500K — Adds red to the screen image for warmer white and

richer red. Default setting.

5400K —Adds green to the screen image for a darker color.

User Color —Individual adjustments for red, green, and blue.

1To select color (R, G or B) press button [2].

2To adjust selected color, press ▲or ▼.

3When you are finished making all color adjustments, press

button [1] twice.

ViewSonic

VG510b/VG510s 9

Input Select toggles between inputs if you have more than one

computer.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ViewSonic Moniteur

ViewSonic

ViewSonic VA705b Manuel utilisateur

ViewSonic

ViewSonic VX2758-P-mhd Manuel utilisateur

ViewSonic

ViewSonic VX1962wm - 19" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic UltraBrite A70f+ Manuel utilisateur

ViewSonic

ViewSonic VE720m Manuel utilisateur

ViewSonic

ViewSonic UltraBrite A90f+ Manuel utilisateur

ViewSonic

ViewSonic E771 - 17" CRT Display Manuel utilisateur

ViewSonic

ViewSonic P75F+ Manuel utilisateur

ViewSonic

ViewSonic VA2436-H Manuel utilisateur

ViewSonic

ViewSonic LD163-181 Manuel utilisateur

ViewSonic

ViewSonic Q201WB - Optiquest - 20" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VX2418-P-mhd Manuel utilisateur

ViewSonic

ViewSonic VA712 VS10697 Manuel utilisateur

ViewSonic

ViewSonic VG2437mc-LED Manuel utilisateur

ViewSonic

ViewSonic VA2463-H Manuel utilisateur

ViewSonic

ViewSonic VA2452S Manuel utilisateur

ViewSonic

ViewSonic VG1930wm - 19" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VE510+-1 Manuel utilisateur

ViewSonic

ViewSonic TD2421 Manuel utilisateur

ViewSonic

ViewSonic VP231WB - 23" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic PD1011 Manuel utilisateur

ViewSonic

ViewSonic VA2220W Manuel utilisateur

ViewSonic

ViewSonic Q71 - Optiquest - 17" CRT Display Manuel utilisateur

ViewSonic

ViewSonic VA2037a-LED-2 Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
