ViewSonic EP4220 Manuel utilisateur

EP4220

Multimedia Digital Poster

User Guide

Model No. VS15186

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specic languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Compliance Information

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the interference at his own

expense.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: To comply with the limits for the Class A digital device, pursuant to Part 15 of the FCC Rules, this

device must be installed in computer equipment certied to comply with the Class A limits. All cables used to

connect the computer and peripherals must be shielded and grounded. Operation with non-certied computers

or non-shielded cables may result in interference to radio or television reception. Changes and modications

not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

For Canada

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

Important Safety Instructions

1. Read these instructions completely before using the equipment.

2. Keep these instructions in a safe place.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this equipment near water. Warning: To reduce the risk of re or electric hock, do not expose this

apparatus to rain or moisture.

6. Do not block any ventilation openings. Install the equipment in accordance with the manufacturer’s

instructions.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices (including

ampliers) that produce heat.

8. Do not attempt to circumvent the safety provisions of the polarized or grounding-type plug. A polarized plug

has two blades with one wider than the other. A grounding type plug has two blades and a third grounding

prong. The wide blade and the third prong are provided for your safety. If the plug does not t into your

outlet, consult an electrician for replacement of the outlet.

9. Protect the power cord from being tread upon or pinched, particularly at the plug, and he point where if

emerges from the equipment. Be sure that the power outlet is located near the equipment so that it is easily

accessible.

10. Only use attachments/accessories specied by the manufacturer.

11. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with

the equipment. When a cart is used, use caution when moving the cart/equipment combination to

avoid injury from tipping over.

12. Unplug this equipment when it will be unused for long periods of time.

13. Refer all servicing to qualied service personnel. Service is required when the unit has been damaged in

any way, such as: if the power-supply cord or plug is damaged, if liquid is spilled onto or objects fall into the

unit, if the unit is exposed to rain or moisture, or if the unit does

iii

Declaration of RoHS2 Compliance

This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European

Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic

equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the

European Technical Adaptation Committee (TAC) as shown below:

Substance Proposed Maximum

Concentration Actual Concentration

Lead (Pb) 0.1% < 0.1%

Mercury (Hg) 0.1% < 0.1%

Cadmium (Cd) 0.01% < 0.01%

Hexavalent Chromium (Cr6+) 0.1% < 0.1%

Polybrominated biphenyls (PBB) 0.1% < 0.1%

Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%

Certain components of products as stated above are exempted under the Annex III of the RoHS2 Directives as

noted below:

Examples of exempted components are:

1. Mercury in cold cathode uorescent lamps and external electrode uorescent lamps (CCFL and EEFL) for

special purposes not exceeding (per lamp):

(1) Short length (≦500 mm): maximum 3.5 mg per lamp.

(2) Medium length (＞500 mm and ≦1,500 mm): maximum 5 mg per lamp.

(3) Long length (＞1,500 mm): maximum 13 mg per lamp.

2. Lead in glass of cathode ray tubes.

3. Lead in glass of uorescent tubes not exceeding 0.2% by weight.

4. Lead as an alloying element in aluminium containing up to 0.4% lead by weight.

5. Copper alloy containing up to 4% lead by weight.

6. Lead in high melting temperature type solders (i.e. lead-based alloys containing 85% by weight or more lead).

7. Electrical and electronic components containing lead in a glass or ceramic other than dielectric ceramic in

capacitors, e.g. piezoelectronic devices, or in a glass or ceramic matrix compound.

ViewSonic©and the three birds logo are registered trademarks of ViewSonic Corporation.

Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained

herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance

or use of this product.

In the interest of continuing product improvement, ViewSonic Corporation reserves the right to change product

specications without notice. Information in this document may change without notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without

prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes available, please

The ViewSonic

Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may

mail or fax to ViewSonic.

For Your Records

Product Name:

Model Number:

Document Number:

Serial Number:

Purchase Date:

EP4220

ViewSonic Multimedia Digital Poster

VS15186

EP4220_UG_ENG Rev. 1C 06-10-14

Product disposal at end of product life

ViewSonic respects the environment and is committed to working and living green. Thank you for being part of

Smarter, Greener Computing. Please visit ViewSonic website to learn more.

USA & Canada: http://www.viewsonic.com/company/green/recycle-program/

Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/

Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

Table Of Contents

Compliance Information ........................................................................................................................i

Important Safety Instructions...............................................................................................................ii

Declaration of RoHS2 Compliance .....................................................................................................iii

Copyright Information..........................................................................................................................iv

Product Registration............................................................................................................................iv

1. Unpacking and Installation............................................................................................................1

1.1. Unpacking ................................................................................................................................1

1.2. Package Contents....................................................................................................................1

2. Parts and Functions .......................................................................................................................1

2.1. Input/Output Terminals .............................................................................................................1

2.2. Remote Control ........................................................................................................................2

3. OSD Menu........................................................................................................................................3

3.1. Select the input signal: .............................................................................................................3

3.2. Image Section ..........................................................................................................................4

3.3. Audio Section ...........................................................................................................................5

3.4. Time Section ............................................................................................................................6

3.5. OSD Settings ...........................................................................................................................8

3.6. Media supported format: ........................................................................................................10

4. TechnicalSpecications ..............................................................................................................11

4.1. EP4220 ..................................................................................................................................11

4.2. RS232 Command Table .........................................................................................................12

Customer Support...............................................................................................................................13

Limited Warranty .................................................................................................................................14

1. Unpacking and Installation

1.1. Unpacking

• This product is packed in a carton, together with the standard accessories.

• Any other optional accessories will be packed separately.

• Due to the size and weight of this display it is recommended for two people to move it.

• After opening the carton, ensure that the content is in good condition and complete.

1.2. Package Contents

Please verify that you received the following items with your package content:

• CD ROM

• Remote control with

batteries

• Power cord

• VGA cable

• Quick Installation Guide

For EU For China

For North America For UK

* *

CD ROM

Remote Control

and Batteries

Video Signal Cable

(D-SUB to D-SUB Cable)

* The supplied power cord varies depending on destination.

NOTES:

• Please make sure that for all other regions, apply a power cord that conforms to the AC voltage of the power

socket and has been approved by and complies with the safety regulations of the particular country.

• You might like to save the package box and packing material for shipping the display.

2. Parts and Functions

2.1. Input/Output Terminals

1 2 43 5 6

1RS232C (IN)

RS232C input connection for the use of RS232

command.

2USB

USB port

3CF/SD

CF/SD slot

4HDMI IN

Connect the HDMI output of an AV device, or the

DVI-D output of a PC by using a DVI-HDMI cable.

5VGA IN (D-Sub)

Connect the computer VGA output.

6PC Audio

PC audio input

2.2. Remote Control

1[POWER] button

Press to switch on the display from standby

mode. Press again to turn it off and back into

standby mode.

2[VOL DOWN] button

Press to decrease the audio output level.

3[MENU] button

Press to turn the OSD menu on/off.

4[ ] button

Press to move the selection up in OSD menu.

5[ ] button

• Press to move the selection left in OSD menu.

• Press to decrease the value in OSD menu.

6[ ] button

Press to move the selection down in OSD menu.

7[ ] button

Press to stop playing video.

8[ ] button

Switch between play/pause mode.

9[MUTE] button

Press to turn the mute function on/off.

10 [VIDEO SOURCE] button

Press to toggle Video Source Menu. Press [ ]

or [ ] button to select one of the video sources

among HDMI, VGA, or MEDIA. Press [ENTER]

button to conrm and exit.

11 [VOL UP] button

Press to increase the audio output level.

12 [ ] button

• Press to move the selection right in OSD

menu.

• Press to increase the value in OSD menu.

13 [ENTER] button

Press to activate the setting inside the OSD

menu.

14 [ ] button

Press to next part.

15 [ ] button

Press to previous part.

16 [ ] button

Speed forward.

17 [ ] button

Speed backward.

3. OSD Menu

3.1. Select the input signal:

Press “SOURCE” button coming to the signal list (PC-RGB, HDMI, Multi-media);

Press ▲/▼ button to select your channel;

Press “ENTER” button to conrm your selection;

Select input signal

3.2. Image Section

Press “MENU” button to open the main page;

Press ◄/► button to select “Picture”, and press “ENTER” button to the sub-page;

1. Please press ▲/▼ button to select the item;

2. Press ◄/► button to adjust the parameters;

3. Press “MENU” button to save the settings and back to last menu;

Picture Mode:

Press ▲/▼ button to select the “Picture mode”, “ENTER” button to the next level, ◄/► to set. Option: standard,

mild, user, dynamic;

Under “User” mode, the user can modify contrast, brightness, sharpness and color;

Color Temperature

Press ▲/▼ button to select “Color Temperature”, press “ENTER” to the sub-menu, ◄/► to set. Options:

medium, warm, user and cool;

Under “User” mode, the user can modify value of red, green and blue;

Aspect Ratio:

Press ▲/▼ button to select the “Aspect Ratio”, press “ENTER” to the sub-menu,and ◄/► to select. Options:

Auto, Just Scan(under HDMI input), Zoom1, Zoom2, Full, 4:3;

Noise Reduction:

Press ▲/▼ button to select the “Noise Reduction Mode”, “ENTER” button to enter sub-menu and ◄/► button

to select: Off, Medium, Low, High.


Autres manuels pour EP4220

Table des matières

Autres manuels ViewSonic Moniteur

ViewSonic

ViewSonic CD4225 Manuel utilisateur

ViewSonic

ViewSonic VG2230WM - 22" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VP2468a Manuel utilisateur

ViewSonic

ViewSonic Q95-3 - Optiquest - 19" CRT Display Manuel utilisateur

ViewSonic

ViewSonic EP1032r-T Manuel utilisateur

ViewSonic

ViewSonic VS10715 VA902-3 Manuel utilisateur

ViewSonic

ViewSonic CDE3201LED Manuel utilisateur

ViewSonic

ViewSonic Q19wb-3 Manuel utilisateur

ViewSonic

ViewSonic VG2753-CN Manuel utilisateur

ViewSonic

ViewSonic VG2453-CN Manuel utilisateur

ViewSonic

ViewSonic VA2013wm Manuel utilisateur

ViewSonic

ViewSonic VA1703WB - 17" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic N1900w Manuel utilisateur

ViewSonic

ViewSonic CDE5510 Manuel utilisateur

ViewSonic

ViewSonic Q71 - Optiquest - 17" CRT Display Manuel utilisateur

ViewSonic

ViewSonic VA2406-h Manuel utilisateur

ViewSonic

ViewSonic VS11234 Manuel utilisateur

ViewSonic

ViewSonic VX2776-2K-PRO-2 Manuel utilisateur

ViewSonic

ViewSonic P95f+ Guide de démarrage rapide

ViewSonic

ViewSonic TD2421 Manuel utilisateur

ViewSonic

ViewSonic E50-8 Manuel utilisateur

ViewSonic

ViewSonic VA503m Manuel utilisateur

ViewSonic

ViewSonic VA1616W Manuel utilisateur

ViewSonic

ViewSonic VS17100 Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
