ViewSonic CDE7051-TL Manuel utilisateur

Full HD 1080p for superior pixel

performance

Each Smart Whiteboard features Full HD 1920x1080

resolution to deliver superior pixel-by-pixel

performance for a more realistic viewing

Advanced 6-point touch capability for

group interaction

With 6-point simultaneous touch technology, this

display encourages group interaction. Two users

can simultaneously write or draw on the display's

The ViewSonic 69.5’’ CDE7051-TL is the ideal interactive display solution for in-classroom teaching, online

training sessions, video conferencing and more. The 6-point touch-enabled display allows two users to

simultaneously write or draw on the board using their ﬁngers or stylus. A Full HD LED screen guarantees crisp

and vivid image quality, and with 350-nit brightness the CDE7051-TL provides better visual performance in

well-lit rooms. Visually attractive, the CDE7051-TL has an ergonomic design with a tempered glass overlay,

anti-glare treatment and rounded corners. The ViewSonic CDE7051-TL delivers a more interactive learning and

meeting environment!

CDE7051-TL

experience. At this resolution you’ll experience

greater image clarity and detail—qualities that will

bring high-deﬁnition multimedia content to life.

surface using styluses or their ﬁngers – or both at

the same time! And its superior touch report rate

provides a smoother user touch experience for both

educational and corporate applications.

Protective rounded-corner design

A rounded-corner design provides a safer learning

environment for active students by helping to

prevent injuries in the classroom—offering you

greater peace of mind.

Tough anti-scratch, anti-glare cover

ViewSonic Smart Whiteboards feature glass covers

with a 7H scratch-resistant surface hardness to

ensure durability, in addition to a consistent and

highly responsive touch experience. In addition, it

has an anti-glare ﬁlm layer that improves on-screen

visibility in brighter environments.

Energy-saving LED backlight

ViewSonic Smart Whiteboards feature an energy-

saving LED backlight with a lifespan of over 30,000

hours—that's more than a decade of durability. This

display consumes less power, provides a lower cost

of ownership and produces a high ROI, making the

CDE7051-TL a great long-term investment.

Versatile input selection for ﬂexible

connectivity

With a versatile selection of inputs, our touch

display enables you to easily connect to and use a

variety of digital devices. Plus, it has an HDMI input

that connects to high-deﬁnition content sources,

and USB, DVI and VGA ports that deliver additional

connectivity options.

CDE7051-TL

ViewBoard software provides tools for

effective teaching

This software lets you write, highlight, edit, and

transform documents and images on-screen in

real-time. It also features screen recording,

magniﬁer, and spotlight features that make ofﬁce

presentations, classroom learning, and distance

education more productive, interactive, and

efﬁcient.

Large-panel display accessories for

improved usability and mobility

The touch display includes 3 stylus that can be used

to write on the display. Although the touch display

can be wall mounted for a solid and safe user touch

experience, we also offer a trolley mount that

provides the ﬂexibility of a mobile display.

Panel Size

Type / Tech

Display Area

Optimum

Resolution

Contrast Ratio

Aspect Ratio

Viewing Angles

Technical Speciﬁcations

69.5”

TFT LCD Module with LED Backlight

1538.88 (H) x 865.62 (V) (69.5” diagonal)

1920 x 1080

4000:1 Typ.

16:9

88º Horizontal, 88º Vertical

LCD PANEL

CDE7051-TL

Response Time

Backlight

Backlight Life

HDMI

RGB

PC Audio (Mini-

stereo)

CVBS IN

CVBS OUT

Shared RCA Audio

YPbPr

SPIDF

MIC IN

RS232

A Type (for F/W)

B Type (for Touc h )

RGB PC/HDMI PC

CVBS

S-Video

YPbPr

HDMI

Physical Top


Sound

Time

Lock

Setup

Voltage

Temperature

Humidity

Physical

Packaging

6ms

LED

50,000 Hours Typ.

15W x2

Refer to timing table

480i

480i, 576i

480i, 480p, 720p, up to 1080p

POWER, INPUT, PC/VGA, VOL+, VOL-, ZOOM, ENERGY SAVING

Picture Mode, Contrast,Brightness, Color, Tint, Sharpness, Color

Temp., Noise Reduction

Sound Mode, Treble, Bass, Balance, Auto Volume, SPDIF MODE,

AD Switch

Clock, Time Zone, Sleep Timer, Auto Standby, OSD Timer

Lock System, Set Password, Block Program, Parental Guidance,

Key Lock

OSD Language, TT Language, Hearing Impaired, PVR File

System, Record List, Aspect Ratio, Blue Screen, Fist Time

Installation, Reset, Software Update(USB)

100-240VAC +/- 10% Wide Range

32°F to 104°F (0°C to 40°C)

20% ~ 80% non-condensing

64.9 x 39.3 x 3.8 (inches) / 1649 x 999 x 97 (mm)

70.3 x 44.9 x 10.8 (inches) / 1785x1140x275 (mm)

CONNECTOR

USB

SPEAKERS

COMPATIBILITY

CONTROLS

POWER

OPERATING

CONDITIONS

DIMENSIONS (W x H

x D)

CDE7051-TL

Net

Gross

VESA®

165.3 (lb) / 75 (kg)

187.4 (lb) / 85 (kg)

600 x 600

CE, CCC

VGA Cable x1, Power Cable x4, Remote Control x1, USB Cable

x1, Audio Cable x1, Stylus x3, User Manual CD Wizard x1

For more product information, visit us at www.viewsonic.com

trademarks are the property of their respective companies. E&EO. All prices and

speciﬁcations are subject to change without written notice. Images are for illustrative purpose only. Terms & Conditions Apply.

WEIGHT

WALL MOUNT

REGULATIONS

What's in the box?

CDE7051-TL
