Viessmann VITOPLANAR EI2 Mode d'emploi

Operating instructions

for the system user

VIESMANN

Infrared heater

VITOPLANAR EI2/EI3/EI5

5855602 GB 1/2020 Please keep safe.

Please follow these safety instruc-

tions closely to prevent accidents

and material losses.

Safety instructions explained

Danger

This symbol warns against the risk

of injury.

!Please note

This symbol warns against the risk

of material losses and environmen-

tal pollution.

Note

Details identified by the word "Note"

contain additional information.

Target group

These operating instructions are inten-

ded for users of the appliance.

This appliance can also be operated by

children aged 8 and older, as well as by

individuals with reduced physical, sen-

sory or mental faculties or those lacking

in experience and knowledge, provided

such individuals are supervised or have

been instructed in the safe use of this

appliance and any risks arising from it.

Keep children younger than the age of 3

away from the appliance. Children

between the ages of 3 and 8 may only

switch the appliance on and off if they

are supervised or have been instructed

in the safe use of the appliance and

have understood the resulting risks, pro-

vided that the appliance is placed or

installed in its normal position of use.

Children between the ages of 3 and

8 must not plug the appliance into a wall

socket, regulate the appliance, clean the

appliance or carry out maintenance.

!Please note

Supervise children in the proximity

of the appliance.

■Never permit children to play with

the appliance.

■Cleaning and user maintenance

must never be carried out by

unsupervised children.

Danger

Incorrectly executed work on the

appliance can lead to life threaten-

ing accidents.

Work on electrical equipment may

only be carried out by a qualified

electrician.

Safety instructions

5855602

Safety instructions for working on the system

Auxiliary components, spare and

wearing parts

!Please note

Components that were not tested

with the appliance may cause appli-

ance damage, or may affect its

functions.

Installation or replacement work

must only be carried out by a quali-

fied contractor.

Safety instructions for operating the system

If there is a fire

Danger

Failure to observe the operating

instructions may result in a fire haz-

ard.

The appliance must not be used in

small rooms inhabited by persons

who cannot leave the room inde-

pendently, unless constant monitor-

ing is ensured.

Installation room requirements

!Please note

Impermissible ambient conditions

can lead to damage to the appli-

ance (risk of overheating) and to a

fire hazard.

■Do not use the appliance in the

immediate vicinity of a bathtub,

shower or swimming pool.

■Do not install the appliance

directly below a wall socket.

■The appliance must not be used in

small rooms inhabited by persons

who cannot leave the room inde-

pendently, unless constant moni-

toring is ensured.

Information on operation

Danger

If the surface of the appliance or the

power cable with the ON/OFF

switch is damaged, there is a risk of

burns or electric shock.

The appliance must not be oper-

ated if damaged. Switch off the

appliance, unplug the standard plug

(if present) from the socket and

notify a qualified contractor.

Danger

The surface of the appliance can

become very hot and cause burns if

prolonged contact is made.

Do not leave children or vulnerable

persons unattended near the appli-

ance.

Danger

Covering the surface can cause

a fire hazard.

■Do not cover the appliance,

whether partially or wholly,

e.g. with a towel.

■Do not dry any objects on the

appliance.

Safety instructions

Safety instructions (cont.)

5855602

!Please note

Even covering parts of the front can

lead to overheating and damage to

the heating element.

■Do not cover the appliance,

whether partially or wholly, e.g.

with a towel.

■Do not dry any objects on the

appliance.

!Please note

Mechanical loads can damage the

appliance.

■Do not lean against the appliance

■Do not lean objects against the

appliance

Safety instructions

Safety instructions (cont.)

5855602

Symbol Meaning

Reference to another document containing

further information

Warning of material losses and environ-

mental pollution

Intended use

The appliance may only be used for its intended pur-

pose in areas where the occupants can leave the

rooms independently or where constant monitoring is

ensured. Using the appliance if it is not installed or for

any purpose other than room heating shall be deemed

inappropriate.

Intended use presupposes that a permanent installa-

tion in conjunction with permissible components

designed for this purpose has been carried out.

The appliance should be able to radiate freely into the

room.

This heater must not be used in the immediate vicinity

of a bathtub, shower or swimming pool.

All other use is deemed inappropriate. Any resulting

losses are excluded from the manufacturer's liability.

Any usage beyond this must be approved by the man-

ufacturer in each individual case.

Product information

Direct electric heating for rapid heating of living spaces

■Optimised insulation reduces proportion of convec-

tion

■Large infrared radiant surface

■Maintenance-free, no magnetic field

■Plug & play system for simple, individual control

Note

In conjunction with the Vitoplanar wireless thermostat

or the Vitoplanar switch mounting thermostat, the prod-

uct data corresponds to the EU regulations of the

directive on the environmentally sound design of

energy related products (ErP).

Vitoplanar EI2 (DI = Design)

Type Output in kW

EI2.A180DI 0.18

EI2.A350DI 0.35

EI2.A500DI 0.5

EI2.A700DI 0.7

Infrared heater, glass, design

■Individually designable glass surface

■TSG as an excellent radiation emitter

■Optimised surface temperature (70 °C)

Vitoplanar EI2 (M = Mirror)

Type Output in kW

EI2.A500M 0.5

EI2.A750M 0.75

EI2.A1000M 1

Infrared heater, glass, mirror

■Infrared heater as mirror version

■Glass is an excellent emitter of radiation

Vitoplanar EI2 (B = Bathroom)

Type Output in kW

EI2.A350B 0.35

EI2.A500B 0.5

EI2.A700B 0.7

Infrared heater, glass, mirror, bathroom version

■Infrared heater as mirror version

■Bathroom version with towel holder

■Optimised surface temperature (70 °C)

Vitoplanar EI3 (GW = Glass White)

Type Output in kW

EI3.A500GW 0.5

EI3.A750GW 0.75

EI3.A1000GW 1

Introductory information

Symbols

5855602

Infrared heater, glass, pure white

■Infrared heater as glass version

■Glass is an excellent emitter of radiation

Vitoplanar EI3 (B = Bathroom)

Type Output in kW

EI3.A350B 0.35

EI3.A500B 0.5

EI3.A700B 0.7

Infrared heater, glass, bathroom version

■Infrared heater as glass version

■Bathroom version with towel holder

■Optimised surface temperature (70 °C)

Vitoplanar EI5 (S = Steel)

Type Output in kW

EI5.A250S 0.25

EI5.A500S 0.5

EI5.A750S 0.75

EI5.A1000S 1

Infrared heater, steel, white

■Infrared heater as steel version

■Version only suitable for wall mounting

Permissible ambient conditions

Fig. 1

!Please note

If the appliance is operated without maintaining

the minimum clearances, flammable objects

may catch fire.

Observe the specified minimum clearances.

Commissioning

Commissioning the appliance

!Please note

If the appliance is operated without being instal-

led correctly, it may be damaged.

The appliance may only be operated when

installed correctly.

1. Ensure that the room thermostat is connected to

the heater according to the specifications. The

room thermostat must be switched on and ready

for operation.

Operating instructions for the wired room

thermostat or wireless thermostat

2. Only for version with standard plug:

Plug the standard plug of the heater into a perma-

nently installed standard socket.

3. Turn on the ON/OFF switch on the heater.

Danger

If the surface of the appliance or the power

cable is damaged, there is a risk of burns or

electric shock.

The appliance must not be operated if dam-

aged. Switch off the appliance, unplug the

standard plug (if present) from the socket

and notify a qualified contractor.

Danger

The surface of the appliance can become

very hot and cause burns if prolonged con-

tact is made.

Do not leave children or vulnerable persons

unattended near the appliance.

Introductory information

Product information (cont.)

5855602

Operation takes place exclusively via the wired room

thermostat or via the wireless thermostat.

Operating instructions for the wired room ther-

mostat or wireless thermostat

Switching on and off

Switching the appliance on

Danger

If the surface of the appliance or the power

cable is damaged, there is a risk of burns or

electric shock.

The appliance must not be operated if damaged.

Switch off the appliance, unplug the standard

plug (if present) from the socket and notify a

qualified contractor.

Danger

The surface of the appliance can become very

hot and cause burns if prolonged contact is

made.

Do not leave children or vulnerable persons

unattended near the appliance.

1. Only for version with standard plug:

Plug the standard plug into a permanently installed

standard socket.

2. Switch on the appliance at the ON/OFF switch.

The appliance is ready for operation.

Note

Depending on its size, the heater takes some time

to reach the operating temperature. Only then does

the heat radiation take full effect.

Switching the appliance off

Switch off the appliance at the ON/OFF switch.

Maintenance

The heater is maintenance-free.

Cleaning

!Please note

If the appliance is cleaned while hot, it may be

damaged.

Allow the heater to cool down completely before

cleaning.

!Please note

Incorrect cleaning agents (e.g. scouring agents)

may damage the surfaces of the appliance.

Only use commercially available glass cleaners

to clean the surfaces.

Clean the surfaces with a commercially available glass

cleaner.

Operation

Programming unit

5855602

Cause Remedy

The ON/OFF switch in the power cable is switched off. Turn on the ON/OFF switch.

Set temperature on the room thermostat is lower than

the actual temperature in the room.

Change the set temperature on the room thermostat.

Fuse has blown or is faulty. Check fuse in domestic distribution board.

Radiated heat is insufficient

Cause Remedy

Objects between heater and person are obstructing ra-

diation.

Remove objects between heater and person.

Distance between heater and person too great. Reduce distance to the heater.

Appliance size is too small. Select appliance with higher output.

What to do if...

Appliance does not heat

5855602

Disposal of packaging

Your contractor will dispose of the packaging from your

Viessmann product.

DE: Packaging waste is channelled for recycling to a

certified disposal contractor in line with statutory

regulations.

AT: Packaging waste is channelled for recycling to a

certified disposal contractor in line with statutory

regulations. Use the ARA statutory disposal sys-

tem (Altstoff Recycling Austria AG, licence num-

ber 5766).

Final decommissioning and disposal of the heater

Viessmann products can be recycled. The heater does

not belong in the household waste.

Speak to your contractor about the correct disposal of

your old system.

Appendix

Information on disposal

5855602

Your contact

Contact your local contractor if you have any questions about your system or wish to arrange maintenance or

repair work. You can find local contractors on the internet at www.viessmann.de.

Viessmann Limited

Hortonwood 30, Telford

Shropshire, TF1 7YP, GB

Telephone: +44 1952 675000

Fax: +44 1952 675040

E-mail: [email protected]

Viessmann Werke GmbH & Co. KG

D-35107 Allendorf

Telephone: +49 6452 70-0

Fax: +49 6452 70-2780

www.viessmann.com

5855602

Autres manuels pour VITOPLANAR EI2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Viessmann Chauffage

Viessmann

Viessmann VITOLADENS 300-T VW3B Mode d'emploi

Viessmann

Viessmann VITOPLANAR EI2 Manuel utilisateur

Viessmann

Viessmann VITOPLANAR EI6 Manuel utilisateur

Viessmann

Viessmann VITOPLANAR EI2 Manuel utilisateur

Viessmann

Viessmann Vitoplanar EC4 Series Manuel utilisateur

Viessmann

Viessmann EHE Mode d'emploi

Viessmann

Viessmann VITOLADENS 300-T Manuel utilisateur

Viessmann

Viessmann Vitoplanar EC4 Series Manuel utilisateur

Viessmann

Viessmann VITOPLANAR EI2 Manuel utilisateur

Viessmann

Viessmann VITOPLANAR EI2 Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
