Viavi Seeker D Lite Manuel utilisateur

Seeker D Lite

In-Home Leakage Detector

User’s Guide

Seeker D Lite User's Guide

Document Num., Rev. 4 May 2018Page 2

Notice

Every effort was made to ensure that the information in this manual was accurate at the time

of printing. However, information is subject to change without notice, and VIAVI reserves the

right to provide an addendum to this manual with information not available at the time that this

manual was created.

reproduced or transmitted, electronically or otherwise, without written permission of the

publisher. VIAVI Solutions and the VIAVI logo are trademarks of VIAVI Solutions Inc. (“Viavi”).

All other trademarks and registered trademarks are the property of their respective owners.

Reproduction and distribution of this guide is authorized for US Government purposes only.

Ordering information

This guide is a product of VIAVI Technical Publications Department, issued as part of the

product. The catalog number for a published guide is Catalog Number - printed. The catalog

number for an electronic guide on USB is Catalog Number - electronic.

Terms and conditions

Specications, terms, and conditions are subject to change without notice. The provision

of hardware, services, and/or software are subject to VIAVI standard terms and conditions,

available at www.viavisolutions.com/en/terms-and-conditions.

Seeker D Lite User’s Guide

Document Num., Rev. 4May 2018 Page 3

Table of Contents

Chapter 1.............................................................................................................. 5

General Information ..................................................................................................................5

Helpful Website ......................................................................................................................5

Where to Get Technical Support ............................................................................................5

How this Manual is Organized ...............................................................................................6

Optional Software...................................................................................................................6

Conventions Used in this Manual...........................................................................................7

Precautions ............................................................................................................................7

Chapter 2.............................................................................................................. 9

Introduction................................................................................................................................9

What is the Seeker D Lite? ....................................................................................................9

Overview...........................................................................................................................9

Testing with the Seeker D Lite Source Transmitter...........................................................9

Seeker D Lite Features ........................................................................................................10

Easy Frequency Conguration .......................................................................................10

Multiple Frequency Presets ............................................................................................10

Channel Tag Compatibility ..............................................................................................10

Squelch Operation..........................................................................................................11

Source Localization ........................................................................................................ 11

Chapter 3............................................................................................................ 13

Getting to Know Your Seeker D Lite ......................................................................................13

Overview ..............................................................................................................................13

Equipment Supplied with the Seeker D Lite.........................................................................13

Replacement Parts...............................................................................................................13

Field Accessories .................................................................................................................14

A Guided Tour of Your Seeker D Lite ...................................................................................15

Front View.......................................................................................................................15

Right Side View ..............................................................................................................16

Protective Carrying Case................................................................................................17

Display Screen................................................................................................................18

About the Battery of Your Seeker D Lite ..............................................................................20

USB Charging.................................................................................................................20

Seeker D Lite User's Guide

Document Num., Rev. 4 May 2018Page 4

Chapter 4............................................................................................................ 21

Seeker D Lite Operation..........................................................................................................21

Available Conguration Settings ..........................................................................................21

PC Communications Mode.............................................................................................22

Basic Operation....................................................................................................................22

Power On/Off ..................................................................................................................22

Low Battery Warning ......................................................................................................22

RF Signal Measurement Mode.......................................................................................23

No Signal Detected ...................................................................................................24

Untagged Signal Detected ........................................................................................24

Tagged Signal Detected on High/Low Frequency .....................................................24

Cruise Mode ...................................................................................................................25

Moving Between Measurement, Cruise, and Off Modes ................................................25

Device Information & Settings..............................................................................................26

Viewing the Battery Charge Level ..................................................................................26

Low Battery Alert .......................................................................................................27

Firmware Version ......................................................................................................27

Enable/Disable Peak Hold..............................................................................................28

Selecting a Preset Frequency.........................................................................................30

Preset Frequency Toggle ..........................................................................................30

Ambient Noise Level Measurement................................................................................32

Speaker Volume Level .........................................................................................................34

Chapter 5............................................................................................................ 35

Leakage Testing.......................................................................................................................35

Before You Begin Leakage Testing......................................................................................35

Testing For Leaks.................................................................................................................35

Chapter 6............................................................................................................ 37

Appendix ..................................................................................................................................37

Specications.......................................................................................................................37

Display Messages & Error Codes ........................................................................................38

Seeker D Lite Error Codes..............................................................................................38

Limited Warranty ..................................................................................................................40

Seeker D Lite User’s Guide

Document Num., Rev. 4May 2018 Page 5

General Information

Chapter 1

Ordering Information

Where to Get Technical Support

Phone US: +1-844-GO-VIAVI or +1-844-468-4284

Outside US: +1-855-275-5378

Email: T[email protected]

Website: https://support.viavisolutions.com/welcome

For additional information about our products and services, contact your local VIAVI

representative or visit https://www.viavisolutions.com/en-us/how-buy.

Seeker D Lite User's Guide

Document Num., Rev. 4 May 2018Page 6

How this Manual is Organized

This manual is divided into the following chapters:

• Chapter 1, “General Information” provides contact information and describes how this

operation manual is structured.

• Chapter 2, “Seeker D Lite Introduction” introduces what the Seeker D Lite is and what it

does. This chapter discusses the practical application, connections and controls of the

Seeker D Lite. Finally, this chapter discusses the battery of the Seeker D Lite and how

to update your rmware.

• Chapter 3, “Seeker D Lite Operation” describes how to congure and operate the

Seeker D Lite.

• Chapter 4, “Leakage Testing” describes the steps needed to perform leakage testing

using the Seeker D Lite.

• Chapter 5, “Appendix” shows the technical specications of the Seeker D Lite as well as

any error codes that may appear on the display screen of the Seeker D Lite.

Optional Software

Although the Seeker D Lite comes precongured and ready to use from the factory, the

following software is required for advanced conguration of the Seeker D Lite:

• Seeker Setup is used to congure the Seeker D Lite, enabling the operator to assemble

les containing channel frequencies, squelch levels, and other settings. Users can

efciently download congurations to one or more leakage detectors.

• Leakage Analysis Workshop (LAW) is software that manages the storage and

retrieval of leakage information collected by vehicle mounted Seeker GPS systems.

Installed on a server, it receives leakage data uploads via the Internet/LAN, Wi-Fi

access point, or cellular connection. Data stored in LAW server may be displayed on

maps or as text, used to generate leakage work orders, or downloaded to other Trilithic

or third-party applications.

Data acquired by the Seeker D Lite must be manually entered into LAW, as the Seeker

D Lite does not communicate directly to LAW.

Seeker D Lite User’s Guide

Document Num., Rev. 4May 2018 Page 7

Conventions Used in this Manual

This manual has several standardized conventions for presenting information:

• Connections, menus, menu options, and user-entered text and commands appear in

bold.

• Section names, web, and e-mail addresses appear in italics.

Precautions

A CAUTION alerts you to any condition that could cause a

mechanical failure or potential loss of data.

A NOTE is information that will be of assistance to you related

to the current step or procedure.

A WARNING alerts you to any condition that could cause

personal injury.

Do not use the Seeker D Lite in any manner not

recommended by the manufacturer.

A strong electromagnetic eld may affect the measurement

accuracy of the Seeker D Lite.

Use only the battery charger supplied with the Seeker D Lite.

All spent batteries should be disposed of according to local

laws and guidelines.

Seeker D Lite User's Guide

Document Num., Rev. 4 May 2018Page 8

Seeker D Lite User’s Guide

Document Num., Rev. 4May 2018 Page 9

Introduction

Chapter 2

What is the Seeker D Lite?

Overview

The new Seeker D Lite™ is a tough, convenient, and exible leakage

test tool. The Seeker D Lite works by measuring tagged RF signals in

and around a subscriber’s premises.

This leakage detector assists in installation and troubleshooting by

verifying that the leakage within the subscriber premises is not great

enough to contribute to the cable system’s cumulative leakage index

(CLI). Leaks can also be important indicators of ingress that can hinder

communication on the return band, as well as affecting downstream

QAM channels in the LTE band.

The Seeker D Lite works in conjunction with the CT-4™ Channel

Tagger in the headend or the Seeker D Lite Source Transmitter at

the ground block. Both devices provide an uncompromising tagging

solution for active analog or digital systems and can be used to identify

and locate all RF leaks in both the Aeronautical and LTE bands.

Testing with the Seeker D Lite Source Transmitter

To overcome the high design and manufacturing cost associated with improvements in

instrument sensitivity, this system uses the Seeker D Lite Source Transmitter high output

signal source to replace the cable service at the subscriber’s ground block. The higher

levels transmitted by the Seeker D Lite Source Transmitter will increase the eld strength of

the signals radiating out of the subscriber network allowing a lower cost receiver to be used

for measurement purposes.

The Seeker D Lite Source Transmitter injects two carriers into the subscriber network, one

at 135–139 MHz and another at 611–615 MHz, supporting testing in both the Aeronautical

and LTE bands. The user may set the output level to 43 dBmV for home certication, but

also has the option to reduce the level to 23 dBmV should the subscriber network prove to

be too porous for pinpointing the location of a leak at the higher transmit level.

The Seeker D Lite provides both a visual readout of the measured levels in uV/m and a

tone proportional to signal strength. To prevent false triggering this system utilizes Trilithic’s

channel tagging technique. To provide constancy with leakage levels typically found within

the subscriber’s premise in home cert mode, the levels displayed by the Seeker D Lite have

been normalized to represent the value of a leak at typical system levels. This correlation

between measured and displayed levels will assist the technician in evaluating the severity

and recording of a leak based upon established industry practices.

Seeker D Lite User's Guide

Document Num., Rev. 4 May 2018Page 10

While in monitoring mode, the Seeker D Lite can toggle

between both the low band and high band for dual-band

leakage detection.

For the sake of this manual, the term “low band” refers to the

frequencies of 135–139 MHz and “high band” refers to the

frequencies of 610.5–615 MHz.

Seeker D Lite Features

Easy Frequency Configuration

The Seeker Setup software simplies the conguration process. Instead of going to the

factory to make hardware modications, you can use the Seeker Setup software to adjust

frequencies.

Multiple Frequency Presets

Your Seeker D Lite can be setup to operate on up to 10 different frequency presets, which

makes it easier to monitor and maintain multiple cable systems. These presets dene the

leakage monitoring frequency and, if desired, the tag detection frequency as well. You have

the option of setting up only one frequency preset for simple operation, or multiple leakage

frequencies for maintaining multiple cable systems. Frequency settings range from

135–139 MHz (low band) and 610.5–615 MHz (high band) in 12.5 kHz increments.

Channel Tag Compatibility

Compatibility with the Trilithic CT-4 channel tag devices is another feature of your Seeker

D Lite. The CT-4 can act as a traditional CT-2™ or CT-3™, and can insert Trilithic’s

proprietary tagged signals in both the aeronautical range and the near LTE range at the

same time. The CT-4 eliminates the risk of affecting any adjacent digital channels by

injecting an adjustable signal from 10–30 dBmV, targeting approximately 30 dB below the

chosen digital carriers. Channel tag values in the meter are congured using the Seeker

Setup software.

Table des matières

Autres manuels Viavi Capteur de sécurité

Viavi

Viavi Seeker HL Manuel utilisateur

Manuels Capteur de sécurité populaires d'autres marques

THORLABS

THORLABS PDA10JT Manuel utilisateur

Waeco

Waeco UV-DETECT Manuel utilisateur

Intermatic

Intermatic IOS-DSIMF Manuel utilisateur

urmet domus

urmet domus 1083 Manuel utilisateur

Siemens

Siemens AZL66 Series Manuel utilisateur

BTI

BTI Profiline Multi Finder Manuel utilisateur

Challenger

Challenger SL01 Manuel utilisateur

DMP Electronics

DMP Electronics 1122INT Manuel utilisateur

Rielta

Rielta Ladoga MK-RK Manuel utilisateur

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuel utilisateur

Bosch

Bosch DS835 Manuel utilisateur

DBI SALA

DBI SALA EZ Stop Manuel de l'opérateur

Lamptime

Lamptime ST05C Manuel utilisateur

Ubiquiti

Ubiquiti MFI-MSC Manuel utilisateur

Subsite

Subsite 910R Instructions d'installation

Satel

Satel OPAL Pro Manuel utilisateur

Aleph

Aleph XC-1XTEU Manuel utilisateur

Pima

Pima LARIS QUAD Manuel utilisateur
