VHD iCast AC8170 Manuel utilisateur
AC1870 iCast Quick Guide
1
AC8170 iCast
User Manual
Version
V1.0
Release
2017-7
Content
AC1870 iCast Quick Guide
2
1.Specification ......................................................... 6
2.Application ........................................................... 9
3.Feature............................................................... 9
4.Operation ............................................................ 11
5.Function and Operation ............................................... 13
5.1 Main Interface..........................................................................................................16
5.1.1 Startup Interface............................................................................................16
5.1.2 Main Interface..................................................................................................16
5.2 Guick Guide................................................................................................................17
5.2.1 Recording............................................................................................................17
5.2.2 Live Streaming..................................................................................................17
5.2.3 Division..............................................................................................................18
5.2.4 Effect..................................................................................................................19
5.2.5 Switch..................................................................................................................20
5.2.6 Quick Settings..................................................................................................21
5.2.7 Channels..............................................................................................................22
5.2.8 Quick Start........................................................................................................24
5.2.9 PTZ control........................................................................................................24
5.2.10 PGM & PGM2 Channel switch .........................................................................26
5.3 System Function........................................................................................................26
5.3.1 Channel Mode......................................................................................................27
5.3.2 Meeting Setting................................................................................................28
5.3.3 File Operation..................................................................................................29
5.3.4 Smart Classroom................................................................................................29
5.3.5 User Operation..................................................................................................30
5.3.6 System Setting..................................................................................................31
5.3.6.1 Recording Setting........................................................................................32
5.3.6.1.1 Encoding Setting......................................................................................32
5.3.6.1.2 Audio Encoding..........................................................................................33
5.3.6.1.3 Time Recording..........................................................................................34
AC1870 iCast Quick Guide
3
5.3.6.1.4 Stock Position..........................................................................................34
5.3.6.1.5 Recording Stratigy..................................................................................35
5.3.6.2 Casting Setup................................................................................................36
5.3.6.2.1 Class Content Info..................................................................................37
5.3.6.2.2 Superscript/On-screen graphic............................................................38
5.3.6.2.3 Prologue/Epilogue....................................................................................39
5.3.6.2.4 Casting Mode..............................................................................................40
5.3.6.2.5 Subtitle Setting......................................................................................41
5.3.6.2.6 Mouse Setting............................................................................................42
5.3.6.3 Live Streaming Setting..............................................................................43
5.3.6.3.1 RTMP Setting..............................................................................................43
5.3.6.3.2 TS Setting..................................................................................................44
5.3.6.4 FTP Setting....................................................................................................45
5.3.6.4.1 FTP Upload..................................................................................................46
5.3.6.4.2 FTP Download..............................................................................................46
5.3.6.5 System Setting..............................................................................................47
5.3.6.5.1 WIFI Setting..............................................................................................48
5.3.6.5.2 HDD ..............................................................................................................48
5.3.6.5.3 Network Setting........................................................................................49
5.3.6.5.4 System Info................................................................................................49
5.3.6.5.5 System Time................................................................................................50
5.3.6.6 Project Setting............................................................................................51
5.3.6.6.1 R&D ..............................................................................................................51
5.3.6.6.2 Factory Setting........................................................................................52
5.3.6.6.2.1 logo Setting..........................................................................................52
5.3.6.6.2.2 Power Setting........................................................................................53
5.3.6.6.2.3 Advanced Setting..................................................................................53
5.3.6.6.2.4 Dual Graphics Card Setting..............................................................54
5.3.6.6.2.5 Quick Start Setting............................................................................55
5.3.6.7 On-site Setting............................................................................................56
AC1870 iCast Quick Guide
4
5.3.6.7.1 Display Setting........................................................................................56
5.3.6.7.2 Import/Export............................................................................................57
5.3.6.7.3 Network Test..............................................................................................57
5.3.6.7.4 Tracking......................................................................................................58
5.3.6.7.5 Integrated Setting..................................................................................62
5.3.6.7.6 Serial Setting..........................................................................................63
5.3.6.7.7 Switch Stratigy........................................................................................64
5.3.6.7.8 Tracking Network......................................................................................66
1.Specification
Item
Sub-Item
Spec.
AC1870 iCast Quick Guide
5
System
Language
Chinese/English
Interface
Graphic operation interface
Structure
Linux
Video
Video Input
7 channel video signal inputs:4 SDI input+2 HDMI
+1 HDMI/VGA input
Video Output
4 video outputs：
VGA-OUT：recording and casting output；
HDMI-OUT：Recording video output；
SDI-OUT-1/2：Video output
Video Display
Touch Screen
Video Signal
HD video signal
Format
1080P@60
Resolution
HDMI/VGA：1024*768p@60fps、1280*720p@50/60fps、
1920*1080i@60/50fps、1920*1080p@30/25fps、
1920*1080p@60/50fps
3G/HD-SDI：1920*1080p@60/50/30/25fps、
1920*1080i@60/50fps、1280*720p@60/50/30/25fps
Audio
Audio Input
3 audio in
Audio Output
3 audio out
Audio
Encoding
AAC
Recording
Method
Audio & Video synchronous recording
Video Process
and Storage
Video Output
Format
MP4
AC1870 iCast Quick Guide
6
Video Frame
1～30fps
Video Frame
Rate
50kbps~40Mbps
Audio Rate
8~420KB
Data Storage
SATA hard disk (optional,max 4TB)
Combined
parts
Touch Screen
11.6 inch touch screen
Joystick
Joystick controlling
Communication
Connector
RS485
connector
4 RS485
RS232
connector
4 RS232
RJ45
1 802.3ab 1000Base-T
USB
1 USB3.0
Function
Casting
Function
Preview / Broadcast screen monitoring / video
switching / pre-live screen monitoring / live
screen multi-split screen display / dual movie
guide mode / audio adjustment / screen segmentation
/ title / PTZ operation / special effects /
subtitles, OSD information, angular logo logo /
support IE Lead / Support Client Guide / Support
Network Trace Receive Send Code
Recording
Function
Real-time streaming / synchronous recording /
movie mode recording / resource mode recording /
resource mode and movie mode at the same time work
/ manual and fully automatic guide / a key to open
the flow and video / local channel playback /
AC1870 iCast Quick Guide
7
built-in player / dual mode A movie mode works at
the same time
Updating
Support network upgrade, RS232 serial port upgrade
Storage mode
Support internal hard disk, external USB storage,
NAS disk mapping; support USB video export; support
SAMBA shared download; support FTP download video,
FTP upload video
Live
streaming
protocol
Standard RTMP protocol, support RTSP real-time
protocol flow, UDP multicast flow, TCP unicast
stream
Network
protocol
TCP、UDP、RTMP、RTSP、RTP、NFS、FTP、DHCP
Working
Environment
Working
Voltage
12V
Working
Temperature
（℃）
-10℃-85℃
Working
humidity
85%RH
Weight（KG）
3.41KG
Size（mm）
390mm*205mm*121mm
AC1870 iCast Quick Guide
8
2.Application
Figure 1 Topology
Figure 2 Classroom Application
AC1870 iCast Quick Guide
9
3.Exterior Feature
1）
2）Size
3）Connection
AC1870 iCast Quick Guide
10
No.
Connection
No.
Connection
1
Power：DC 12V
13
MIC-IN：Audio input, standard
3-pin 6.5 XLR header
