VEVOR FLO500 Manuel utilisateur
Technical Support and E-Warranty Certificate www.vevor.com/support
SEWAGE PUMP
INSTALLATION INSTRUCTIONS
MODEL: FLO500
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: FLO500
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
SEWAGE PUMP
- 2 -
Kindly Reminder
The FLO500 has been developed with the utmost care and it is tested in the
factory. Therefore, it is possible that the test water remains in the appliance.
ACCESSORIES
- 3 -
S/N
Name
Number
A-B
Check valve with plastic elbow
1
C
Hose Clamp (32-50mm)
4
D
Rubber ring to connected the Intelflo toilet and Intelflo
pump
1
E
Plastic hose
3
F
Activated Carbon
1
G
Hose Clamp (90-110mm)
1
H
Hose Clamp (110-120mm)
1
J
Lid
1
K
Plug(It Mounted On The Pump)
2
- 4 -
SPECIFICATIONS
The water temperature should be a minimum of 1℃for it is important that
the unit does not freeze, and a maximum water temperature is 90℃.
Input Power Rating:
500W
Max Vertical Lift:
8M
Input Voltage:
220-240V, 50HZ
Max Temperature:
90℃
Flow Rated:
110L/MIN
Noise Level:
45 dBA
Max Horizontal Lift:
80M
Degree of Protection:
IPX4
- 5 -
HOW THE UNIT FUNCTIONS
The macerator is simply a tank that is gravity fed from your toilet, washing
machine, shower, etc. with a built-in pressure switch that detects the
incoming waste and starts a pump combined with cutting blades. This
reduces the effluent to an easy-to-pump fluid which is then pumped along
small-diameter pipes into the drains. A non-return valve is fitted as
standard so enabling the unit to pump up to 8 m vertically.
INSTALLATION
ELECTRICS
The unit must be installed to current electrical regulations with a
fused spur mounted outside the room fused at 3 amps. We advise that this
is done by a registered electrician.
Connection
The unit is designed for a horizontal toilet with an outlet of the standard
European 18 cm to the outlet centre from the floor. All other inlets must
gravity fed into the unit. The outlet comes as standard with a 32 mm
connection, however, 22 mm can be used with a reducer. What is very
important is that the pipe run uses radius bends and is forbidden to use
90-degree (right-angle elbows) bends as blockages can occur.
If the water outlet is discharged horizontally, the water pipe must have a
1% inclination.
- 6 -
If the sewage is discharged upwards, the horizontal pipe should not
exceed 1 ft (30 cm).
Inlet
The unit can be used just for one input such as a toilet or shower or sink or
all at once and blanking covers are provided to allow for this.
WARNINGS
(1) Electrical Installation:
·The connection shall be carried out by a qualified technician and the rules
for electrical installations (NEN 1010) shall be met.
·If the power cord of the appliance is damaged, it shall be replaced by the
manufacturer or supplier of the appliance. This will avoid creating dangers.
·The connection of your appliance is Class 1.
Connect the appliance to a socket with a protective conductor connection.
(2) Thermal Protection:
·This appliance is equipped with thermal protection which switches off the
power supply of the appliance for 2 hours after overheating for safety
reasons.
·Power on the electrical connection only when the appliance is fully
installed.
·In case of prolonged absence (e.g. vacation), the water supply to the
appliance shall be closed.
·Do not expose the appliance to temperatures below 0℃or above 50℃.
(3) If the indications are not followed, it could cause personal
security risks.
(4) Wrong Use
Use only for human excrement+soluble toilet paper. Equipment damage
due to improper use is not covered by the warranty. Some examples of
damage caused by improper use include grinding cotton wool, tampons,
sanitary napkins, panty liners, food, condoms, towels hair and rinsing
liquids, and solvents or oils.
- 7 -
TROUBLE SHOOTINGS
Some malfunctions of the grinder are not practically serious. You can
correct it by yourself. To diagnose and find a solution to the Trouble, refer
to the diagram below. For other malfunctions, get contact the supplier or a
qualified professional.
MALFUNCTIONS
POSSIBLE CAUSES
SOLUTIONS
The appliance occasionally
starts to work
The connected pipelines are
leaking
Check the installation in front
of the appliance
The check valve is leaking
Clean or replace the check valve
The motor is running properly,
but the water runs slowly
away.
The aerator in the lid is blocked
Clean the aerator
The engine is running
properly but non-stop or runs
for a long time
The height or length of the drain
is too large,or too many bends
are used(power failure)
Check the installation
The pump is blocked
Turn off the power,
disassemble the pump and
unblock
The motor is not switched on
The power supply is not
switched on
Switch the on power supply
(repeat)
The plug is defective
Repair the plug
The trouble with the motor or
sensor
Remove the lid,flush clean,and
dry the sensor up(hair dryer)
The motor rattles with a noise
There's a strange object in the
motor
Remove the lid,clean it and
remove the object
The motor is buzzing and
does not rotate
The condensator is broken or has
trouble with the motor
Get in contact with a qualified
specialist or the supplier
There's a strange object in the
Remove the lid,clean it and
motor
Remove the lid,clean it and
remove the object
- 8 -
Importer: WAITCHX
Address: 250 bis boulevard Saint-Germain 75007 Paris
Importer: FREE MOOD LTD
Address: 2 Holywell Lane, London, England, EC2A 3ET
Manufacturer: Ningbo YUNSUN Electromechanical Co., Ltd
Address：Building 3 No.7 Hongshen Road Hongtang Industrial Zone A,
Jiangbei District 315033 Zhejiang P.R. China
Made In China
REP
UK
EUREP UK LTD
UNIT 2264, 100 OCK STREET, ABINGDON
OXFORDSHIRE ENGLAND OX14 5DH
REP
EC
EUREP GmbH
Unterlettenweg 1a, 85051
Ingolstadt, Germany
