Verve™ Living Systems

Installation Guide

Model: VOSC

Occupancy Sensor – Ceiling Mounted

Product Description

The Verve ceiling-mounted Occupancy Sensor saves energy and

adds convenience by accurately detecting when an area is

occupied or vacant.

It is a wireless, solar-powered sensor that detects occupancy

using passive infrared (PIR) heat and motion sensing. The sensor

transmits RF messages to Verve lighting, HVAC, and outlets to

use energy more efficiently.

Features Include:

• Sends wireless messages to other devices whenever motion

is detected

• Harvests ambient solar energy to power the sensor and

wireless communication

• Mounts easily on any ceiling material

• Works with other sensors for enhanced occupancy tracking

• Built-in tests to confirm operation at installed location

• Supplemental battery option for extreme low-light failover

Specifications

Planning

Take a moment to plan for the sensor’s successful operation and

optimal communication with other system components.

Remove the sensor from its packaging and place it in a strong

light to provide the required startup charge.

Tip: To quickly ensure the sensor energy storage is fully charged,

insert a CR2032 battery for 30 seconds.

• Ensure the location provides consistent and adequate light

• Locate the sensor in the center of the room with an

unobstructed view of the space

• Avoid installed near ceiling fan or hanging fixtures

• Consider the area’s traffic patterns and principal use, for

example, walking, lounging or sleeping

• Confirm a location is suitable by temporarily mounting the

sensor and testing it, see Walk Test and Light Test sections

• Consider the construction materials in the space and

obstacles that may interfere with RF signals

Sensor Range

A single occupancy sensor provides sufficient coverage for most

applications.

Note: For some applications, multiple sensors may be required

to provide complete coverage.

For detailed information, see the Verve System Planning Guide

at www.vervelivingsystems.com.

Package Contents

•OccupancySensor

• 2 screws, 2 wall anchors

•Wirebracket

Tools Required

• Power drill, 3/16” bit

•Screwdriver

•Lightmeter

• Battery (CR2032) for

testing

6.3”

159.96mm

2.35”

59.57mm

1.47”

37.45mm

Occupancy Sensor – Ceiling Mounted • Installation Guide page 2 of 4

Verve™ Living Systems

Coverage Diagrams

Tip: To provide coverage for very high ceilings, a wall sensor can

be incorporating in the plan for complete coverage.

Installing estimated time: 20 minutes

The occupancy sensor can be mounted on most ceilings with the

provided screws, or mounted on dropped ceilings, using the

provided wire bracket.

1. Decide where you want to install the occupancy sensor.

Tip: For visual alignment, orient the sensor parallel to one of

the walls.

2. Remove the mounting plate from the sensor.

3. Decide which of the two installation options is appropriate.

Screw Mounting Plate to the Ceiling

a. Hold the mounting plate in place on the ceiling and use a

pencil to lightly mark two small dots for the screw drill

points.

b. Drill two holes with a 3/16” drill bit and insert the wall

anchors.

c. Insert the first screw

loosely and level the

mounting plate.

d. Insert the second screw

and then hand-tighten the

first screw.

Mount Using the Wire Bracket

a. Remove the ceiling tile where you want to mount the

sensor.

b. Place the mounting plate squarely on the ceiling tile and

use the wire to mark two points for the holes.

c. Punch two small holes through the ceiling tile at the

marked points.

d. Insert the wire bracket

through the two holes in

the mounting plate.

Make sure the ends are

roughly even.

e. Feed the wires through the

holes in the ceiling tile.

f. On the front of the ceiling

tile, flatten the wire bracket

so it is snug against the

mounting plate.

g. On the back of the ceiling

tile, twist the wires

together to hold the

mounting plate securely.

h. Replace the ceiling tile.

4.5m

1.5m

5’

10’

15’

Top View

Side View

1’ 3.1’ 4.6’ 7.5’ 9.3’ 10.9’ 13.0’ 14.2’ 16.8’

10’

0-1’ 3.1’ 4.6’ 7.5’ 9. 3’ 16.8’14.2’13.’10.9’

10’

Occupancy Sensor – Ceiling Mounted • Installation Guide page 3 of 4

Verve™ Living Systems

4. Attach the sensor to the mounting plate.

With the 2-button interface facing you, slide the sensor to

the left on the mounting plate until it snaps into place.

Note: It may be easier to link the sensor before it is mounted

on the ceiling. See the Linking section.

Occupancy Sensor – Ceiling Mounted • Installation Guide page 4 of 4

140 Business Park Drive, Winston-Salem, NC 27107 XOSC01IS01A

vervelivingsystems.com

Installing Supplemental Battery (optional)

If light levels are very low where the sensor is installed, auxiliary

battery power (CR2032) can be used to supplement the solar

energy harvester.

1. Remove the sensor from the mounting plate.

With the 2-button interface facing you, slide the sensor to

the right.

2. Turn the sensor over and identify the battery holder on the

circuit board.

3. Insert the battery under the clip with the positive pole (+)

up and press it in place.

4. Remount the sensor on the mounting plate.

Troubleshooting

FCC SZV-STM300C

I.C. 5713A-STM300C

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Limited Warranty

Verve™ Products Limited Warranty. Subject to the other terms of this warranty, Liberty

Hardware Mfg. Corp. (“Liberty Hardware”) warrants you the original purchaser that

this Verve™ product will be free from defects in material and workmanship for five

years from the date of your purchase of the product. During that period, if the product

does not comply with this limited warranty, Liberty Hardware will, at its discretion,

repair or replace the product. Repair or replacement is your sole remedy under this or

any other warranty of the product, whether express or implied.

Coverage Limitations. This limited warranty extends only to the original purchaser and

is not transferable. This limited warranty expressly excludes any defects or damages

resulting from any product installed improperly or in an improper environment,

overloaded, misused, opened, abused, or altered in any manner.

Instructions for Warranty Service. To obtain warranty service return the Verve™

product, a description of the problem, together with your proof of purchase, securely

packaged and with postage prepaid, to:

Liberty Hardware Mfg. Corp.

Attn: Customer Service - Verve Living Systems

140 Business Park Drive

Winston Salem NC 27107

You may be required to provide other information or evidence of the defect. Any

returned product that is replaced becomes the property of Liberty Hardware.

Implied Warranties. TO THE EXTENT PERMITTED BY LAW, ANY IMPLIED

WARRANTIES, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE SAME DURATION AS THIS

EXPRESS WARRANTY. Some states do not allow limitations on how long an implied

warranty lasts, so the above limitation may not apply to you. NO OTHER EXPRESS

WARRANTY HAS BEEN MADE OR WILL BE MADE BY LIBERTY HARDWARE MFG.

CORP. WITH RESPECT TO THIS PRODUCT.

Limitation of Liability. LIBERTY HARDWARE SHALL NOT BE RESPONSIBLE FOR

SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES SUCH AS THE COST OF

LABOR FOR REMOVAL OR REINSTALLATION OF THE PRODUCT, WHETHER ARISING

OUT OF BREACH OF WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.

Some states do not allow the exclusion of incidental or consequential damages, so the

above exclusion and limitation may not apply to you.

If you have any questions about this warranty, contact us at 1-877-874-8774.

This limited warranty gives you specific legal rights, and you also may have other

rights which vary from state to state. In Canada, the above provisions are not intended

to operate where prohibited by law and do not preclude the operation of any

applicable provisional consumer protection statute which in certain circumstances

may extend the express warranties herein.

Problem Solution Checklist

The sensor does not

generate a wireless

message

• Verify the LED blinks when motion is

detected

• Verify the solar cell is charged

properly

The sensor is activated

when there is nothing to

detect

• Verify there is 4 ft. (1.2m) clearance

from heat sources that may disturb

sensing

• Reduce the sensitivity setting by

moving the switch on the back of

the sensor to the left-hand position

The linked device does

not respond to wireless

messages

• Check for environment or range

issues

• Verify the device is linked

• Check the transceiver connection

and the wiring for errors

• Check if appropriate devices are

linked according to good system

planning

Battery

clip

Sensitivity

switch
