Raptor-i Wireless Helmet Intercom
User Manual
Raptor-i Wireless Helmet Intercom
User Manual
TAME THE NOISE, NOT YOUR SPIRIT!
Congratulations for purchasing this fine piece of riding gear to complement the spirit of your ride, regardless of
whether you are riding for pleasure or daily commute. It is always exciting to ride and feel the freedom on your
coveted machine and with friends!
All of us at VERTIX™ thank you (and your friends too!) for choosing this product which we believe delivers the
best performance and value to augment your riding pleasure. ENJOY!
TABLES of CONTENTS
IMPORTANT NOTICE 2
CONFORMITY NOTICE 2
INTRODUCTION 3
WHAT YOU SHOULD HAVE 4
FUNCTIONS 4
INSTALLATION 6
OPERATION AND USE 7
MODE PRIORITY 10
USING MOBILE PHONE 10
USING INTERCOM 11
USING MUSIC PLAYER 12
FM RADIO 13
SPECIFICATIONS 13
CARE FOR YOUR RAPTOR-I 13
TROUBLE-SHOOTING FAQS 14
TERMS AND CONDITIONS
OF LIMITED WARRANTY 16
REFUND OPTION 19
WARRANTY INFORMATION 20
EN
2
EN IMPORTANT NOTICE
Please comply with your local traffic laws when using this product and where required, you can detach one speaker. Safety must
always be your top priority. You are advised not to use this product under conditions which may put yourself or others at risk of
injury. Pull over to the road shoulder or a safe location to communicate when required. Adjust the volume prior to riding for each
available mode to your desired level bearing in mind that long exposure to loud sounds can cause hearing impairments. Users are
advised to test and acquaint themselves with the Raptor's Automatic Volume Control feature (only for mobile phone calls) which
automatically increases the volume when wind-noise is detected. The use of earplugs is highly recommended for riding speeds
in excess of 100kph (62mph) as wind-noise at high speeds is deafening. By opening and using this product, you explicitly accept the terms and
conditions for its use and should this product be given or loaned to another user, it is your responsibility to inform the user of the above terms and
conditions of use which shall also be applicable to him/her.
CONFORMITY NOTICE
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B Digital Device pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate
this equipment.
EUROPEAN CE NOTICE
This device is in conformity with the following directives:
EU Low Voltage, Directive 2006/95/EC; EU Electromagnetic Compatibility, Directive 2004/108/EC; R&TTE, Directive 1999/5/EC
3
EN
INTRODUCTION
The VERTIX™ Raptor series is a wireless 2.4GHz system designed for easy retrofit on helmets. It allows you to conveniently access audio
entertainment, navigation information and communications when wearing your helmet. The Raptor-i works with most mobile phones, GPS
navigation devices and music players equipped with Bluetooth® technology.
Your Raptor-i is designed with a high quality rubberized double injection molded outer membrane capable of withstanding weather conditions
you are accustomed to while riding or may encounter on longer journeys; such as heavy rain, hot and cold temperatures. The Raptor-i is
aerodynamically designed and when properly installed will minimize turbulence and drag at high speeds, reducing disturbances and discomfort to
the rider.
The Raptor-i comes with your choice of a boom or wired microphone headset with specially tuned speakers to deliver high quality audio for your
music and communications experience. With the Raptor-i's Cut-the-Noise™ Digital Signal Processing (DSP) and Automatic Volume Control (AVC)
technologies, you are assured of communications quality which allows you to be heard clearly by the other party. Your Raptor-i will work through
20dB NRR earplugs to ensure you can hear clearly while protecting your ears against very loud wind-noise levels at high speeds. As the wind-
noise level depends on the helmet design, type and brand, the maximum speed which you can comfortably communicate will vary. As there are 4
different independent volume settings for the Raptor-i, the volume settings will default to the 50% level everytime you Power ON the unit after a
FULL Power OFF.
The Raptor-i's controls are carefully researched, designed and tested for easy feel and operation with riding gloves. To further improve ease of use,
a handle mounted, ergonomically-designed remote control unit will soon be available to complement your Remote-Ready Raptor-i.
4
EN WHAT YOU SHOULD HAVE
Main Unit + Boom Mic Headset or Wired Mic Head
1) 1 x Raptor-i
2) 1 x USB charger
3) 1 x USB charging cable
4) 1 x Quick user guide
5) 1 x User manual
1) 1x2 Speakers + Boom Mic
2) 1 x EZ-Mount™
3) 1 x User Guide
1) 1 x 2 Speakers + Wired Mic
2) 1 x EZ-Mount™
3) 1 x User Guide
Note: Your Boom or Wired headset may be included with this package or provided separately.
FUNCTIONS
Mobile phone functions
Voice dialing (dependent on your mobile phone)
Auto call answer (after approx. 8secs or 3 rings)
Call reject
Call redial
Last number redial
Call Transfer (between your Raptor-i and mobile phone)
Independent mobile phone volume control
Intercom functions
Supports 3 riders
Easy intercom operation
Full duplex conversations
Maximum intercom range up to 800m or 2,620 ft
(for Line-of-Sight conditions)
Independent intercom volume control
Auto switch to mobile phone for incoming calls
Automatic Volume Control (increase audio output when wind or environment noise increases)
Note: The volume increase is proportional to the amount of noise detected ONLY in the PHONE and INTERCOM modes. Be sure to wear earplugs
when you plan to use these functions when riding at high speeds to avoid harmful ear damage due to automatic audio level increase.
5
EN
GPS Sat-Nav functions
Receive audio information from your Bluetooth® GPS Sat-Nav unit
Connects with your mobile phone via your GPS Sat-Nav unit (GPS dependent, please consult your GPS Sat-Nav user manual)
Independent GPS Sat-Nav volume control (please consult your GPS Sat-Nav user manual)
Auto switch to mobile phone for incoming calls
Music player functions
Compatible with Bluetooth® A2DP music players for High Fidelity Stereo music
Compatible with Bluetooth® AVRCP for music control functions (Next Track, Previous Track, Volume control)
Independent Music volume control
Auto switch to phone for incoming calls
NOTE: For Next Track, Previous Track and volume control to work, your mobile phone or media player MUST support AVRCP (Audio Video Remote
Control Protocol).
FM radio functions
Frequency Range: 76 - 108 MHz (This may vary by country)
Independent FM Radio volume control
Auto switch to mobile phone for incoming calls
Memory for 8 favourite stations
6
EN INSTALLATION
The Raptor-i can be installed on any helmet without affecting structure or finish. The EZ-Mount™ system provides for a simple and secure means
of mounting and removing your Raptor-i unit. You can also perform aerodynamic adjustments of the Raptor-i's attack angle to suit your riding
posture on the motorcycle you are riding.
**The Quick Start Guide will help you get started on using your Raptor-i in no time. Do also try to acquaint yourself with this user guide to explore
other functions which may be useful.
Adjusting Optimum Angle of Attack
Note: You can adjust the angle of attack for your Raptor-i with no limitation on your desired angle of tilt. What you need is to ensure the EZ-
Mount™ contact for your Raptor-i and helmet is maximized. You can do this by aligning the EZ-Mount™ on your helmet with your Raptor-i for
maximum contact with each other (75% or more would be good). To check, simply feel the force of trying to snap the Raptor-i off from your
helmet and if you cannot push if off easily (like the wind pushing against your Raptor-i from the front edge), you are good. The EZ-Mount™ has
been tested to securely hold your Raptor-i for speeds up to 210kph (130mph) when properly mounted.
7
EN
OPERATION AND USE
Always prioritise your riding or activity above phone calls or entertainment. It is recommended to pull over and stop current activity before
answering or having a conversation. Always ride carefully and abide with the laws in your area.
WHEN YOU SEE IT MEANS
No lights The Power is OFF
Red/Blue lights flashing alternately You are in Pairing mode
Blue light with short flash every 3 seconds The set is in Standby mode
Blue light with longer flash every 3 seconds The set is connected with your mobile phone and is
ready for use
Red light flashing every 3 seconds The Battery is low
Flashing Red light (when charger is connected)
When it turns SOLID Red
Your Raptor-i is being charged
Your Raptor-i is fully charged
What the Sounds Generally Mean
POSITIVE: Short high pitched tones (single or double "TEE" sounding tones) means connection OK, intercom connected, pairing OK, etc.
NEGATIVE: Longer low-pitched tones (single or double "TOO" sounding tones)means connection failure, connection terminated, unsuccessful
pairing, etc.
8
EN Turning On
Press and hold the ON-OFF/INT button. Release the button when you see the Blue light starting to flash or when you hear 6 ascending (low to
high) tones to signal that the set is now in service. If you have a paired mobile phone, you will also hear 2 high-pitched tones if it is connected.
Turning Off
Press and hold the ON-OFF/INT button until you hear a "DU DU" signal followed by 3 descending (high to low) tones.
BLUETOOTH® Pairing
The Raptor-i is compatible with Bluetooth® technology used for pairing mobile phones, music players and between Raptor-i headsets.
Pairing Mode
Make sure your Raptor-i is OFF.
Press and do not release the ON-OFF/INT button until you see both Blue and Red lights flashing alternately.
You should hear a "DU DU". Your Raptor-i is now in Pairing Mode.
Note that the unit will automatically exit the Pairing Mode in about 60 seconds if pairing is not completed or unsuccessful. Repeat again if this
happens.
Mobile Phone Pairing
With the Raptor-i in Pairing Mode, turn ON your mobile phone's Bluetooth® and search for devices. Please refer to your mobile phone's user
manual if necessary.
Your mobile phone should detect "VTX-RAPTOR i_vx.xx.x."
Select this and enter the code 0000 (zero zero zero zero).
Note: To use the Raptor-i with a mobile phone and GPS Sat-Nav device at the same time, you will need to utilize the GPS Sat-Nav unit's phone
function. Please refer to your GPS Sat-Nav user manual for more information.
9
EN
Intercom Pairing
Switch OFF all Raptors-i near you if possible.
Bring the 2 sets you would like to begin pairing close to each other.
Put them into Pairing Mode. You will see Red and Blue flashing lights on BOTH sets.
Press the ON-OFF/INT button briefly on ONE of the Raptor-i to initiate pairing.
When both Raptor-i show only a Blue flashing light, the pairing is completed and INTERCOM is established between the 2 sets. Test by talking to
confirm.
If you want to include a 3rd set in the group, turn off ALL the sets first and repeat the intercom pairing process for the 1st set and the NEW (3rd)
set.
NOTE: Each Raptor-i unit can only pair with 2 other Raptor-i units. The last 2 sets to pair will have a higher priority and a single INT button press on
either of these 2 units will connect them together. The 3rd or last set to pair will require 2 INT presses to communicate with either of the 2 earlier
sets.
Music Player Pairing
Refer to Mobile Phone Pairing
GPS Sat-Nav Pairing
Models such as the Garmin® Zumo 500 and 600 series supports pairing with your mobile phone and offers an easy and convenient way for you
to enjoy both mobile phone and GPS Sat-Nav functions on your Raptor. Please see your GPS Sat-Nav user manual on setting up and if the phone
function is supported.
For GPS Sat-Nav devices without the integrated mobile phone feature, you will have to decide which one takes higher priority as Raptor-i can only
support ONE High Priority device, you may wish to note that most older or entry level GPS Sat-Nav devices does not support phone pairing.
Garmir® is a registered trademark of Garmin Ltd or its subsidiaries.
Clearing All Paired Devices
With the Raptor turned ON, you can clear all devices paired on your Raptor by pressing the CALL CONTROL and VOL DOWN button together until
you see 2 RED flashes.
