Verizon CE1000A Manuel utilisateur

Verizon

Wi-Fi

Extender

USER

GUIDE

CONTENTS

01 /

INTRODUCTION

 Package Contents 

 System Requirements 

 Features 

 Getting to Know Your

Verizon Wi-Fi Extender 

02 /

CONNECTING YOUR VERIZON

WIFI EXTENDER

 Setting up Your Verizon

Wi-Fi Extender 

 Main Screen 

 System Settings 

03 /

WIFI SETTINGS

 Overview 

 Primary Network 

 Guest Network 

 IoT Network 

 Wi-Fi Protected

Setup 

 Radio Management 

04 /

DIAGNOSTICS & MONITORING

 System Logging 

 Backhaul Logging 

TABLE OF CONTENTS

05 /

TROUBLESHOOTING

 Troubleshooting

Tips 

 Frequently Asked

Questions 

06 /

SPECIFICATIONS

 General

Speciﬁcations 

 LED Indicators 

 Environmental

Parameters 

07 /

NOTICES

 Regulatory Compliance

Notices 

01 /

INTRODUCTION

1.0 Package Contents

1.1 System Requirements

1.2 Features

1.3 Getting to Know Your

Verizon Wi-Fi Extender

 / INTRODUCTION

Verizon Wi-Fi Extender lets you transmit

and distribute digital entertainment and

information to multiple devices in your

home/ofﬁce.

Your Extender supports networking

using coaxial cables, Ethernet, or Wi-Fi,

making it one of the most versatile and

powerful Wi-Fi extenders available.

GETTING TO KNOW YOUR

VERIZON WIFI EXTENDER

./ PACKAGE CONTENTS

Your package contains:

• Verizon Wi-Fi Extender

• Power adapter

• Ethernet cable

./ SYSTEM REQUIREMENTS

System and software requirements are:

• A computer or other network device supporting Wi-Fi or wired

Ethernet

• A web browser, such as Chrome™, Firefox®, Internet Explorer 8®

or higher, or Safari® 5.1 or higher

./ FEATURES

Your Verizon Wi-Fi Extender features include:

• Support for multiple networking standards:

– LAN: 802.11 a/b/g/n/ac/ax, Gigabit Ethernet and MoCA 2.5

interfaces

• Integrated wired networking with 2-port Ethernet switch and

Coax (MoCA LAN)

– Ethernet supports speeds up to 2.5 Gbps.

– MoCA 2.5 LAN enabled to support speeds up to 2.5 Gbps

over coaxial cable

PACKAGE CONTENTS, SYSTEM

REQUIREMENTS AND FEATURES

 / INTRODUCTION

• Self-organizing Network (SON) oers seamless roaming, band

steering, and AP steering to improve the performance of your

Wi-Fi network

• Integrated Wi-Fi networking with 802.11a/b/g/n/ac/ax access

point featuring:

– Backward compatible to 802.11a/b/g/n/ac

– 2.4 GHz 11ax 4x4

– 5 GHz 11ax 4x4

– 6 GHz 11ax 4x4

• Enterprise-level security, including:

– Advanced Wi-Fi protection featuring WPA2 & WPA3 Modes

and MAC address ﬁltering

– Wi-Fi Multimedia (WMM) for Wi-Fi QoS (quality-of-service)

• Secure remote management using HTTPS

./ GETTING TO KNOW YOUR VERIZON WIFI EXTENDER

1.3a/ FRONT PANEL

The Status LED will be solid white

when your Verizon Wi-Fi Extender is

turned on, connected to the internet,

and functioning normally.

GETTING TO KNOW YOUR

VERIZON WIFI EXTENDER

Status LED

Condition Status LED Color Verizon Wi-Fi Extender

Normal WHITE Normal operation (50% solid)

Setup complete (solid)

Extender is booting (soft blink)

System restart (fast blink)

BLUE Pairing mode (hard blink)

WPS pairing successful (fast blink)

GREEN Wi-Fi has been turned o (solid)

Issue(s) YELLOW No internet connection (solid)

Extender is too far from the Router. Poor

backhaul signal (hard blink)

Extender is too close to the Router. Poor

Wi-Fi coverage (fast blink)

RED Hardware/System failure detected (hard

blink)

Overheating (fast blink)

WPS pairing failure (fast blink)

Power OFF Power o

1.3b/ REAR PANEL

The rear panel of your Verizon Wi-Fi Extender has a label that

contains important information about your device, including the

default settings for the Verizon Wi-Fi Extender’s Wi-Fi network

name (SSID), Wi-Fi password (WPA2 key), local URL for accessing

 / INTRODUCTION

the Verizon Wi-Fi Extender’s administrative pages, and administrator

password. The label also contains a QR code that you can scan

with your smartphone, tablet, or other camera-equipped Wi-Fi

device to allow you to automatically connect your device to your

Wi-Fi network without typing in a password (requires a QR code

reading app with support for Wi-Fi QR codes).

The rear panel has three ports; F-type coax and Ethernet LAN

[two]. The rear panel also includes WPS and reset buttons, and a

DC power jack.

GETTING TO KNOW YOUR

VERIZON WIFI EXTENDER

• WPS ButtonWPS Button - allows quick access to the Wi-Fi Protected Setup

(WPS) feature and pairing mode. This is an easy way to add your

Extender to your Wi-Fi network.

• Ethernet LANEthernet LAN - connects devices to your Verizon Wi-Fi Extender

using Ethernet cables to join the local area network (LAN).

The two Ethernet LAN ports are 10/100/1000/2500 Mbps

auto-sensing and can be used with either straight-through or

crossover Ethernet cables.

• Coax LANCoax LAN - connects your Verizon Wi-Fi Extender to the LAN

and/or to other MoCA devices using a coaxial cable.

• Reset ButtonReset Button - allows you to reset your Verizon Wi-Fi Extender

to the factory default settings. To perform a soft reboot, press

and hold the button for at least three seconds. To reset your

Verizon Wi-Fi Extender to the factory default settings, press and

hold the button for at least ten seconds.

• PowerPower - connects your Verizon Wi-Fi Extender to an electrical

wall outlet using the supplied power adapter.

Warning: The included power adapter is for home use only,

supporting voltages from 105-125 voltage in AC. Do not use in

environments with greater than 125 voltage in AC.

1.3c/ REAR LIGHTED INDICATORS

LAN Ethernet

• Unlit – Indicates no Ethernet link or dims after 5minutes idle
