Venturo HT40KX Manuel utilisateur

20993

1-19-04

TABLE OF CONTENTS

HT40KX (HRAAAA-P0**)

SUPERCEDES

TITLE DATE SECTION

TABLE OF CONTENTS

HT40KX / Prop Ctrl / No Eng Ctrls (HRAAAA-P0**)

SECTION 100 DESCRIPTION & SPECIFICATIONS

22343 INSTALLATIONDIMENSIONS

18353 MOUNTING DIMENSIONS - BASE PLATE

22341 CAPACITY CHART - HT40KX

SECTION 150 SAFETY

15394 VEHICLE & CRANE ELECTRICAL HAZARD INFORMATION

920612 SAFETY & HAZARDS - GENERAL

19217 WINCH SAFETY WARNINGS

22489 DECAL PLACEMENT

SECTION 200 INSTALLATION

20697 CRANE INSTALLATION (PAGE 1 OF 2)

22344B CRANE INSTALLATION (PAGE 2 OF 2)

22345A CRANE OPERATION & MAINTENANCE INSTRUCTIONS (PAGE 1 OF 3)

22345B CRANE OPERATION & MAINTENANCE INSTRUCTIONS (PAGE 2 OF 3)

22345C CRANE OPERATION & MAINTENANCE INSTRUCTIONS (PAGE 3 OF 3)

22328 SAFETY SHUTOFF INSTRUCTIONS

22335 PTOINSTALLATION

20698 COMPARTMENT DRAWING

17831 INSTALLATION & MOUNTING DIMENSIONS - 17350 PEDESTAL

22245 WIRE ROPE INSTALLATION

SECTION 300 MAINTENANCE & SERVICE

14544 ADJUSTMENT OF WORM HEIGHT AND BACKLASH

14553 ADJUSTMENT OF ROTATION WORM END PLAY

SECTION 400 REPLACEMENTPARTS

22346 HT40/50KX CRANE REPLACEMENT PARTS DRAWING

22517 HT40/50KX CRANE REPLACEMENT PARTS LIST

22518 HT40/50KX CRANE FASTENER LIST

24571 24550 BOOM (FULL POWER EXTENSION) REPLACEMENT PARTS DRAWING

24572 24550 BOOM (FULL POWER EXTENSION) REPLACEMENT PARTS LIST

20699 HYDRAULIC SYSTEM COMPONENTS REPLACEMENT PARTS DRAWING

20930 HYDRAULIC SYSTEM COMPONENTS REPLACEMENT PARTS LIST

22657 ELECTRICAL SCHEMATIC - PROPORTIONAL WITHOUT ENGINE CONTROLS

20353 ELECTRICAL SCHEMATIC - PROP W/ IN-COMP CONTROLS (NO ENGINE CONTROLS)

22488 HYDRAULIC SYSTEM SCHEMATIC - PROPORTIONAL CONTROL HT40/50KX

22655 PROPORTIONALPENDANT CONTROL

22449 22450 ANTI-TWO-BLOCK SYSTEM

22684 22685 ANTI-TWO-BLOCK SYSTEM (IN BOARD - LH)

22448 19294 PTO PACKAGE

CINCINNATI, OHIO

MFG., INC.

SECTION 100

DESCRIPTION

SPECIFICATIONS

7607100A

3/8"DIA.WIREROPE

100FTLONG

SNATCHBLOCKFORSINGLEAND

TWO-PARTLINEOPERATION

16"SWING

RADIUS

C.G.(APPROX)

WARNING:THESEPRODUCTS

ARENOTPASSENGERLIFTS.

THEYARENOTDESIGNEDOR

INTENDEDTOBEUSEDTO

LIFT,SUPPORT,OROTHERWISE

TRANSPORTPERSONNEL.

BOOMANGLEANDCAPACITY

INDICATORONBOTHSIDES

OFBOOM

BASEMOUNTING

DIMENSIONS

391/4"

16"

16"14"

4FT

103/4"

22FT

18FT

12FT

23"

20FT

16FT

31"

10FT

6FT

103/4"POWER

C100

INSTALLATIONDWG

HT40KX,HT50KX

22343

SECTION

TITLEDATE

SUPERSEDES

81/2"

10-21-97A

3-3-03B

MANUAL/

POWER

REF

33/4"

16"

15"

81/2"

1"14"

33/4"

15"

14"

121/4"

16"

81/2"

11/16"DIAHOLE

-8PLC

3"DIA

HOLE

TITLEDATESECTION

SUPERSEDES

18353

C100

HT40/50KX

121/4"

10-11-02D

5-20-03E

BASEMOUNTINGDIM

HT40/50KXBASEMOUNTINGDIMENSIONS

SECTION 150

SAFETY

8604150

15394

C150

5-13-97G

5-15-02H

INSTALLATION DWG

ET & HT CRANE SERIES SUPERCEDES

TITLE DATE SECTION

VEHICLE & CRANE MOUNTED ELECTRICAL HAZARD SIGN

APPLICATION & INFORMATION

ET & HT CRANE SERIES

SIGN NO. 15393A DISPLAYS THE INTERNATIONAL SYMBOL FOR

ELECTRICITY AND WARNS OF DANGER FROM AN

ELECTRICALLY CHARGED VEHICLE, CRANE, OR LOAD. FOUR

ARE RECOMMENDED (ONE FOR EACH SIDE AND ONE FOR

EACH END OF VEHICLE) TO BE APPLIED IN LOCATIONS WHICH

ARE READILY VISIBLE TO GROUND PERSONNEL.

SIGN NO. 15401 PROVIDES ADDITIONAL WARNING OF LEGAL

REQUIREMENTS WHEN OPERATING NEAR HIGH VOLTAGE

LINES. THIS SIGN IS PLACED ON THE CONTROL PENDANT

SIDE OF BOOM.

REQUIRED MINIMUM CLEARANCES REFERRED TO ON SIGN NO. 15401

REQUIRED CLEARANCES FROM OVERHEAD HIGH-VOLTAGE LINES

NOMINAL VOLTAGE (kV) MINIMUM REQUIRED

(PHASE TO PHASE) CLEARANCE (FEET) *

0 - 50 10

over 50 - 200 15

over 200 - 350 20

over 350 - 500 25

over 500 - 750 35

over 750 - 1000 45

REQUIRED CLEARANCES FROM ENERGIZED HIGH-VOLTAGE CONDUCTORS

(WHILE IN TRANSIT)

NOMINAL VOLTAGE (kV) MINIMUM REQUIRED

(PHASE TO PHASE) CLEARANCE (FEET) *

0 - 0.75 4

over 0.75 - 50 6

over 50 - 345 10

over 345 - 750 16

over 750 - 1000 20

* NOTE: ENVIRONMENTAL CONDITIONS SUCH AS FOG, SMOKE, OR PRECIPITATION MAY REQUIRE

INCREASED CLEARANCES

CINCINNATI, OHIO

MFG., INC.

CRANE SAFETY AND HAZARDS

HT25KX, HT40KX, HT50KX

CAUTIONS

1. INSPECT VEHICLE AND CRANE, INCLUDING OPERATION, PRIOR TO USE DAILY.

2. DO NOT USE THIS EQUIPMENT EXCEPT ON SOLID, LEVEL SURFACE WITH CRANE MOUNTED ON

FACTORY-RECOMMENDED TRUCK.

3. BEFORE OPERATING THE CRANE, REFER TO MAXIMUM LOAD (CAPACITY) CHART ON CRANE FOR

OPERATING (LOAD) LIMITATIONS.

4. DO NOT OPERATE, WALK, OR STAND BENEATH BOOM OR A SUSPENDED LOAD.

5. ATTACH PENDANT CORD SUPPORT SNAP TO ATTACHMENT POINT BEFORE PLUGGING IN

PENDANT.

6. UNPLUG PENDANT AND DISENGAGE PTO SYSTEM WHEN CRANE NOT IN USE.

7. FOR TRAVEL, BOOM MUST BE IN STOWED POSITION.

DANGER

• THIS CRANE IS NOT A PASSENGER LIFT

• IT IS NOT DESIGNED OR INTENDED TO BE USED TO LIFT, SUPPORT, OR OTHERWISE TRANSPORT

PERSONNEL.

YOU MUST NOT OPERATE THIS CRANE UNLESS

1. YOU HAVE BEEN TRAINED IN THE SAFE OPERATION OF THIS CRANE

AND

2. YOU KNOW AND FOLLOW THE SAFETY AND OPERATING RECOMMENDATIONS CONTAINED IN THE

MANUFACTURER'S MANUALS, YOUR EMPLOYER'S WORK RULES, AND APPLICABLE GOVERNMENT

REGULATIONS. AN UNTRAINED OPERATOR SUBJECTS HIMSELF AND OTHERS TO DEATH OR

SERIOUS INJURY.

ELECTROCUTION HAZARD

• THIS MACHINE IS NOT INSULATED.

• MAINTAIN SAFE CLEARANCES FROM ELECTRICAL LINES AND APPARATUS.

• YOU MUST ALLOW FOR BOOM SWAY, ROCK OR SAG, AND ELECTRICAL LINE AND LOADLINE

SWAYING.

• THIS LIFTING DEVICE DOES NOT PROVIDE PROTECTION FROM CONTACT WITH OR PROXIMITY TO

AN ELECTRICALLY CHARGED CONDUCTOR.

• YOU MUST MAINTAIN A CLEARANCE OF AT LEAST 10 FEET BETWEEN ANY PART OF THE CRANE,

LOADLINE, OR LOAD, AND ANY ELECTRICAL LINE OR APPARATUS CARRYING UP TO 50,000 VOLTS.

ADDITIONAL CLEARANCE IS REQUIRED FOR VOLTAGES IN EXCESS OF 50,000 VOLTS. REFER TO

DRAWING 15394 FOR ADDITIONAL INFORMATION.

•DEATH OR SERIOUS INJURY WILL RESULT FROM CONTACT OR INADEQUATE CLEARANCE.

920612

C150

6-12-92

5-13-97A

INSTALLATION DWG

HYDRAULIC CRANES SUPERCEDES

TITLE DATE SECTION

CINCINNATI,OHIO

MFG., INC.

19314-2

MANUAL

OVERRIDE 15401

UNLAWFUL

TO OPERATE

RIGHT

14473-2

GREASE

15398

UNPLUG

REMOTE

15581

ATTACHMENT

14473-2

GREASE

FRONT

14473-1

OIL

19314-1

MANUAL

OVERRIDE

LEFT

MODEL NO.

19746 - HT40

19747 - HT50

CAPACITY

DECAL MODEL PART NO.

RIGHT HT40 22342-1

HT40

RIGHT

LEFT

HT50

22342-2

22352-1

22352-2

19788

PROPORTIONAL CONTROL

* PROPORTIONAL ONLY

22496

LARGE

VENTURO

BOOM

SERIAL NO. 84030 & UP

SERIAL NO. 85030 & UP

15392

DANGER

ELEC.

HAZARD

15391

DANGER

(NOT

PASSENGER

LIFT)

14473-2

GREASE

22499

KNOW

YOUR

SIGNALS

15390

CAUTION

BACK

19315-1

19315-2

MANUAL

PROPORTIONAL

SHUT OFF DECAL

HT40/50KX

DECAL PLACEMENT

5-25-99A

8-2-99B

SECTIONTITLE DATE

SUPERSEDES
