Vendo V-MAX Series Guide de démarrage rapide

TCT-1

PARTS AND SERVICE

MANUAL

P/N: 1122181

REV B: 5/2002

TCT-2

V-MAX TRADE TABLE OF CONTENTS

SAFETY SECTION.................................................................................... Pages S-1 -S-18

A COMMITMENT TO SAFETY.................................................................. Page S-2

VENDOR INSTALLATION......................................................................... Pages S-3 -S-6

ELECTRICAL HAZARDS .......................................................................... Pages S-7 -S-8

MECHANICAL HAZARDS......................................................................... Page S-9

REFRIGERATION HAZARDS................................................................... Page S-10

SUBSTITUTIONS AND MODIFICATIONS................................................. Pages S-11 -S-12

CONSUMER SAFETY WARNING............................................................. Page S-13

GAS ISLAND VENDOR INSTALLATION PROTOCOL.............................. Page S-14

MOUNTING TO PEDESTAL...................................................................... Page S-15

PARTS, SALES, AND SERVICE CENTERS OF VENDO/SANDEN CO... Pages S-16 -S-17

GENERAL INFORMATION........................................................................ Pages G1 -G12

GENERAL INFORMATION........................................................................ Page G-2

INITIAL SET-UP ....................................................................................... Pages G-3 -G-4

LABEL INSTALLATION............................................................................. Page G-5

ALIGNMENT CHECKS.............................................................................. Page G-6

LOADING INSTRUCTIONS....................................................................... Page G-7

VEND MECHANISM PARTS DESCRIPTION............................................ Pages G-8 -G-9

VEND CYCLE............................................................................................ Pages G-10 -G-11

PROGRAMMING SECTION...................................................................... Pages PC-1 -PC-22

9.1 PROGRAMMING................................................................................. Pages PC-2 -PC-4

SET-UP AND CODE DESCRIPTION ........................................................ Pages PC-5 -PC-18

9.1 WIRING DIAGRAMS........................................................................... Pages PC-19 -PC-22

TRADE CABINET SECTION..................................................................... Pages C-1 -C-18

READING A PARTS LIST ......................................................................... Page C-2

HARDWARE LIST..................................................................................... Pages C-3 -C-4

INNER DOOR ASSEMBLY........................................................................ Pages C-6 –C-7

CABINET ASSEMBLY............................................................................... Pages C-8 -C-9

STACK ASSEMBLY.................................................................................. Pages C-10 -C-13

REFRIGERATION ASSEMBLY................................................................. Pages C-14 -C-15

AIR DAM ASSEMBLY ............................................................................... Pages C-16 -C-17

TRADE DOOR SECTION.......................................................................... Pages TD-1 -TD-18

OUTER DOOR.......................................................................................... Pages TD-2 -TD-13

LOCK ASSEMBLY .................................................................................... Pages TD-14 -TD-15

SELECTION PANEL ................................................................................. Pages TD-16 -TD-17

MINI V-MAX DOOR SECTION................................................................... Pages TDS-1 -TDS-10

OUTER DOOR.......................................................................................... Pages TDS-2 -TDS-5

SELECTION PANEL ................................................................................. Pages TDS-6 -TDS-7

LOCK ASSEMBLY .................................................................................... Pages TDS-8 -TDS-9

TCT-3

GAS ISLAND VENDOR PARTS................................................................ Pages GIV-1 -GIV-16

OUTER DOOR.......................................................................................... Pages GIV-2 -GIV-5

LOCK ASSEMBLY .................................................................................... Pages GIV-6 -GIV-7

COIN INSERT ........................................................................................... Pages GIV-8 -GIV-9

SELECTION PANEL ................................................................................. Pages GIV-10 -GIV-11

MOUNTING PEDESTAL ASSEMBLY ....................................................... Pages GIV-12 -GIV-13

SWITCH MOUNT ASSEMBLY.................................................................. Pages GIV-14 -GIV-15

MAINTENANCE......................................................................................... Pages M-1 -M-10

PREVENTATIVE MAINTENANCE SUGGESTIONS.................................. Page M-2

LUBRICATION GUIDE .............................................................................. Page M-2

CARE AND CLEANING............................................................................. Page M-3

REFRIGERATION OPERATION ............................................................... Pages M-4 –M-6

REFRIGERATION PARTS DESCRIPTION............................................... Pages M-7 -M-9

TROUBLESHOOTING .............................................................................. Pages T-1 -T-8

VENDO WARRANTY................................................................................ Pages T-2 -T-3

PARTS RETURN PROCEDURE............................................................... Page T-4

TROUBLESHOOTING GUIDE .................................................................. Pages T-5 -T-8

SAFETY SECTION

3/2002

S-1

A COMMITMENT TO SAFETY

The Vendo Company is committed to safety in every aspect of our product design. Vendo

is committed to alerting every user to the possible dangers involved in improper handling

or maintenance of our equipment. The servicing of any electrical or mechanical device

involves potential hazards, both to those servicing the equipment and to users of the

equipment. These hazards can arise because of improper maintenance techniques. The

purpose of this manual is to alert everyone servicing Vendo equipment of potentially

hazardous areas, and to provide basic safety guidelines for proper maintenance.

This manual contains various warnings that should be carefully read to minimize the risk

of personal injury to service personnel. This manual also contains service information to

insure that proper methods are followed to avoid damaging the vendor or making it unsafe.

It is also important to understand these warnings are not exhaustive. Vendo could not

possibly know, evaluate, or advise of all of the conceivable ways in which service might be

done. Nor can Vendo predict all of the possible hazardous results. The safety

precautions outlined in this manual provide the basis for an effective safety program. Use

these precautions, along with the service manual, when installing or servicing the vendor.

We strongly recommend a similar commitment to safety by every servicing organization.

Only properly-trained personnel should have access to the interior of the machine.

This will minimize the potential hazards that are inherent in electrical and mechanical

devices. Vendo has no control over the machine once it leaves the premises. It is the

owner or lessor’s responsibility to maintain the vendor in a safe condition. See Section I of

this manual for proper installation procedures and refer to the appropriate service manual

for recommended maintenance procedures. If you have any questions, please contact the

Technical Services Department of the Vendo office nearest you.

SAFETY RULES

•Read the Safety Manual before installation or service.

•Test for proper grounding before installing to reduce the risk of electrical shock and

fire.

•Turn off power switch or disconnect power cord from wall outlet before servicing or

clearing product jams. The vending mechanism can trap and pinch hands.

•Use only fully-trained service technicians for Power- On servicing.

•Remove any product prior to moving a vendor.

•Use adequate equipment when moving a vendor.

•Always wear eye protection, and protect your hands, face, and body when working

near the refrigeration system.

•Use only authorized replacement parts.

•Be aware of inherent dangers in rocking or tipping a vending machine.

•Always turn power off before plugging or unplugging vendor to wall outlet.

3/2002

S-2

SECTION I: VENDOR INSTALLATION

A. Vendors are large, bulky machines of significant size and weight. Improper

handling can result in injury. When moving a vendor, carefully plan the route to be

taken and the people and equipment required to accomplish the task safely.

B. Remove all tape, shipping sealant, and Styrofoam from the vendor. Loosen any

shipping devices used to secure interior parts during shipping. Remove the wooden

shipping base attached to the vendor base by the vendor leveling screws. Make

certain the leveling screws are in place and functional.

C. Position the vendor three to four inches (7.6 cm to 10.2 cm) from a well-constructed

wall (of a building or otherwise) on a flat, smooth surface.

IMPORTANT: The vendor requires three inches (7.6 cm) of air space from the wall

to ensure proper air circulation to cool the refrigeration unit.

D. Adjust the leveling screws to compensate for any irregularities on the floor surface.

Ideally, no adjustment will be necessary and the leveling legs will be flush with the

bottom of the vendor. A spirit level is a useful aid to level the vendor. When the

vendor is properly leveled the outer door, when opened, will remain stationary.

Vendors must be level to ensure proper operation and to maintain stability

characteristics. Do not add legs to the vendor.

E. Check the manufacturer’s nameplate on the left or right side of the vendor’s outer

door to verify the main power supply requirements of the vendor. Be sure the main

power supply matches the requirements of the vendor. To ensure safe operation,

plug the vendor only into a properly grounded outlet.

DO NOT USE EXTENSION CORDS.

F. Recommended voltage specs = volts required + amps of circuit.

G. Dedicated 15A service required for 1 machine.

NOTE: Any power supply variance more than +10% may cause the vendor to

malfunction.

* Power outlets must be properly grounded.

* Power outlets must be properly polarized, where applicable.

Test the outlets using the following information.

(Refer to Figure 1 on Page S-4.)

3/2002

S-3

TYPE 1

TYPE 2

TYPE 3

TYPE 4

TYPE 5

FIGURE 1

EARTH CONTACT SOCKET

(GREEN AND YELLOW)

0 VOLTS

OR LIVE

(

BROWN

)

220 VOLTS

NEUTRAL

(

BLUE

)

0-5 VOLTS

POWER CONTACT SOCKET

OR LIVE

(

BROWN

)

220 VOLTS

POWER CONTACT SOCKET

NEUTRAL

(

BLUE

)

0-5 VOLTS

OR LIVE

(

BROWN

)

220 VOLTS

NEUTRAL

(

BLUE

)

0-5 VOLTS

POWER CONTACT SOCKET

OR LIVE

(

BROWN

)

220 VOLTS

POWER CONTACT

SOCKET

NEUTRAL

(

BLUE

)

0-5 VOLTS

POWER CONTACT SOCKET

NEUTRAL

(

BLUE

)

0-5 VOLTS

OR LIVE

(

BROWN

)

220 VOLTS

EARTH CONTACT

(GREEN AND YELLOW)

0 VOLTS

(GREEN AND YELLOW)

0 VOLTS

EARTH CONTACT

STEP 1 STEP 2

STEP 1 STEP 2 STEP 3

STEP 3

SMALL SLOT-LINE 1

LIVE CONTACT (BLACK)

110 VOLTS

EARTH CONTACT

ROUND SOCKET

EARTH CONTACT SLOT

(GREEN AND YELLOW)

0 VOLTS

SLOT

LIVE CONTACT

NEUTRAL CONTACT

SLOT

(

BROWN

)

220 VOLTS

(

BLUE

)

0-5 VOLTS

LARGE SLOT-LINE 2

NEUTRAL CONTACT

(

WHITE

)

0 - 5 VOLTS

(

GREEN

)

0 VOLTS

STEP 1

STEP 2 STEP 3

STEP 1 STEP 2

STEP 3

OR LIVE

(

BROWN

)

220

POWER CONTACT

SOCKET

NEUTRAL

(

BLUE

)

0-5 VOLTS

CHECKING FOR PROPER GROUNDING AND POLARIZATION

3/2002

S-4

SECTION I: VENDOR INSTALLATION (CONTINUED)

For Type 1 and Type 2 outlets, test for Grounding and Polarization as follows:

1. With a test device (volt meter or test light), connect one probe to the receptacle’s

neutral contact and the other to the live contact. The test device should show a

reaction.

2. Connect one probe to the receptacle’s earth contact and the other to the live

contact. The test device should show a reaction.

For Type 3 through Type 5 outlets, test for Grounding as follows:

1. With a test device (volt meter or test light), determine which of the receptacle’s

power contacts is the live contact.

A. Connect one probe to the receptacle’s earth contact.

B. Connect the second probe to the left (or upper) power contact. If a reaction

occurs, this is the live power contact. If a reaction does not occur, move the

second probe to the right (or lower) contact. A reaction should occur,

indicating that this is the live power contact.

2. Connect one probe to the receptacle’s live power contact (as determined in step 1).

Connect the second probe to the other power contact (neutral). The test device

should show a reaction.

IF THE ABOVE CONDITIONS ARE NOT MET FOR THE GIVEN OUTLET

TYPE, CONTACT A LICENSED ELECTRICIAN AND HAVE THE

NECESSARY CORRECTIONS MADE.

3/2002

S-5

SECTION I: VENDOR INSTALLATION (CONTINUED)

S-6

H. Door Support (Figure 2)

The door support is to ensure that the

outer door closes squarely to the cabinet.

Raising the door can also ensure proper

alignment of the door latch.

FIGURE 2

I. Door Latch Alignment (Figure 3)

DO NOT INSERT OBJECTS

INTO LOCK CAVITY.

TO FREE OBJECTS

REMOVE

LOCK CAP AS SHOWN

After any door adjustment, the floating quicker

lock assembly should align itself automatically.

The latch assembly is adjustable. To adjust,

loosen the latch bracket mounting screws,

raise or lower the latch assembly into position,

then tighten the mounting screws.

SCREW

MOUNTING

LATCH

BRACKET

FIGURE 3

WARNING:

KEEP FINGERS AND OTHER OBJECTS OUT OF LOCK CAVITY

NOTE: Refer to the appropriate parts and service manual for detailed

instructions, operating principles, and recommended maintenance

intervals and procedures.

3/2002

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Vendo Contrôleurs

Vendo

Vendo V21 721 Guide de configuration

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
