VEKOOTO SW5-1 Mode d'emploi
VEKOOTO@outlook.com
1
®
Operating Instructions & Installation Guide
SW5-1
Portable Backup Camera with 5”Monitor
Built-in battery and solar panel
USER MANUAL
Thank You for Buying VEKOOTO Product.
Read This User Manual Before Installing and Using It.
Pls keep this instruction or write down our email VEKOOTO@OUTLOOK.COM
So you can find us once you have any question.
3
1. Monitor introduction
The user can perform the manipulation of the guest power
segment on the display parameters through the following
nuclear health operations.
®
① Up / down
② Enter setup menu / Long press 3s to return to previous level
③ Up/down, Turn on / off parking guide line
Monitor
Size
5 inch
Resolution
HD 800*480
Contrast ratio
500:1
4
Brightness
500 cd/m²
Viewing Angle
U:80, D:80, R/L:80
Power input
DC12-24v
Maximum power
Max 5W
Support channel
Support CH2/ CH1/ split screen
at the same time
Mirroring
Support
2. Product Features:
5
1、2.4G WIFI wireless transmission, 3DB antenna.
2、Support for HD 850 infrared night vision function.
3、Waterproof rating IP68.
4、Transmission bandwidth 20MHz, 50M in the open distance.
5、Horizontal and left and right viewing angles are larger than
140 degrees.
6、Type-C female connector, 5V DC charging, Solar Charging
（Max0.75W）, Short circuit, and over-voltage protection.
7、Power display indicator light, the light will flash when
charging.
8、Built-in battery(9600mAh) and solar panel, Minimum working
6
time of 12 hours with full power, maximum working time of 48
hours.
9、Support for charge while using.
10、Magnet anti-skid function.
3. Package List
5-inch Monitor
Suction cup bracket
Camera antenna ×2
Monitor antenna
Power extension cable
Cigarette lighter power cord
7
Camera ×2
Type-C charging cable ×2
4. Install Monitor Bracket
The windshield suction cup bracket to who the monitor back
hole position.
5. MENU FAQ
Q1: The screen shows a blue screen, no signal how to do?
A1: First make sure the backup camera is powered and on, click
8
the settings button to enter the settings menu and select pairing
for pairing.
Q2: How to solve the weak signal for long distance use?
A2: Contact us for a free extension antenna.
Vekooto@outlook.com
Q3: What about the camera screen delay when using it in short
distance?
A3: Check if the antenna is tightened.
If you find that the product is broken and accessories are
missing, please contact Vek[email protected].
