Veilux VVIP-2L2812 Manuel utilisateur
User’s Manual
V1.4
VVIP-2L2812 Vandal Dome
Network Camera
The Art of Surveillance
®
--Content--
CHAPTER 1 PROFILE...................................................... - 1 -
1.1FUNCTIONS AND CHARACTERISTICS ............................... - 1 -
1.2APPLICATIONS........................................................... - 2 -
CHAPTER 2 INSTALLATION............................................. - 2 -
2.1CAUTIONS................................................................ - 2 -
2.2MEASUREMENTS ....................................................... - 3 -
2.3PACKING CONTENTS ................................................... - 4 -
2.4INSTALLATION VANDAL DOME......................................... - 6 -
2.5OPTIONAL ACCESSORIES ............................................. - 8 -
2.6HARDWARE CONNECT ................................................. - 9 -
CHAPTER 3 PARAMETER SETUP.................................. - 11 -
3.1SETUP PARAMETER BY IE BROWSER............................. - 12 -
APPENDIX..................................................................... - 12 -
This manual is suitable for IP DOME-IR series
- - 1 - -
Chapter 1 Profile
This network camera is an embedded digital surveillance product. It
adopts embedded Linux as the operation system and SOC hardware platform.
Has a characteristic of high efficiency and flexibility for system adjustment,
small size, high stability and long term reliability.
1.1 Functions and Characteristics
Basic Function
Video compression tech: adopts H 264 video compression tech, high
compression ratio.
Network functions: integrate TCP/IP protocols and video, alarm, voice data
supported, built-in WEB browser, IE live view supported.
PTZ control function: control for PTZ, kinds of decoder protocols and dome
cameras supported. Can be connected via the RS485 output.
Alarm function: signal parameter alarm input, on-off parameter alarm
output, motion detective, video lost, mask alarm, alarm link output.
Voice speech: Has audio input to give remote audio / recordings.
POE power supply supported. (optionally installed)
User management: multi-level user access management.
Compression Handling Function
Multi stream hardware compression, adopts H.264 compression standard
on video compression, not only support change code ratio, but also
support change frame ratio, while setting up video image quality, it’s able
to restrict compression bit rate of video image.
1920*1080p, 1600*1200p, 1280*720p, D1(PAL:704*576, NTSC:704*480),
CIF(PAL:352*288, NTSC:352*240), QCIF(PAL:176*144, NTSC:240*160)
supported
OSD supported for date and time, full user control setup.
Remote view andtransmission function
One self-compliant 10M/100M Ethernet interface as standard accessory.
PPPoE, DHCP, DDNS protocol supported.
Available to set parameter, browse real time video, check network camera
state through applications or IE browser. Available to realize alarm link and
save compressed bit rate through network.
Available to realize remote upgrade and maintenance through network.
- - 2 - -
1.2 Applications
Suitable for circumstances required for network remote surveillance
ATM, Bank Counter, Supermarket, Factory etc
Nursing House, Kindergarten, School etc.
Intelligent door management system
Intelligent Building, intelligent community management system
Electricity station, telecom base station etc unmanned on duty system
Outdoor bridge, tunnel, crossing traffic etc surveillance system
flowing line and warehouse surveillance
24h surveillance to road traffic
Remote surveillance to forest, fountain and river etc.
Chapter 2 Installation
2.1 Cautions
Please check carefully while unpacking, be sure articles inside accordance
to the list
Please read this chapter carefully before installation
Be sure to off all concerned power while installation
Check power and voltage in case to damage facility because of
unmatched voltage
Installation circumstance: do not install in circumstances of high humidity
or high temperature, please keep good ventilation, and pay attention to
defend rain, avoid installing in high vibrating installations.
In times of malfunction, do not attempt to dismantle and service the
camera yourself. Please refer to qualified serving personnel to repair or
contact our technical department to solve the problems.
Supplied accessories are optional with all model, please refer to your local
sales for details of any additional parts required. The Packing list may
indicate Junction box plate, this would only be suitable for some parts of
the world, so may not be available for your country, please check with your
sales for details on this.
- - 3 - -
2.2 Measurements
- - 4 - -
2.3 Packing contents
2.3.1 Packing contents list
2.3.2 Junction box plate
- - 5 - -
2.3.3 Junctionbox installation types
- - 6 - -
2.4 Installation vandaldome
- - 7 - -
- - 8 - -
2.5 Optional accessories
