1 About this document
VEGASOURCE 82 • Source holder
66076-EN-220119
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,theexchangeofpartsandthesafetyofthe
user. Please read this information before putting the instrument into
operation and keep this manual accessible in the immediate vicinity
of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
ThissymbolindicatesspecialinstructionsforExapplications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.
4
2 For your safety
VEGASOURCE 82 • Source holder
66076-EN-220119
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
The handling of radioactive substances is regulated by law. The radia-
tion protection rules of the country in which the system is operated
applyrstandforemost.
In Germany the current radiation protection ordinance (StrlSchV)
based on the Atomic Energy Law (AtG) is applicable.
The following points are important for measurement with radiometric
methods:
A handling permit is required for operation of a system using gamma
rays.This permit is issued by the respective state government or
theresponsibleauthority(ocesforenvironmentalprotection,trade
supervisory boards, etc.)
We would be pleased to assist you in applying for the permit.
Whenhandlingradioactivesources,unnecessaryradiationexposure
mustbeavoided.Anunavoidableradiationexposuremustbekeptas
low as possible.Take note of the following three important measures:
1 2 3
Fig. 1: Measures for protection against radioactive radiation
1 Shielding
2 Time
3 Distance
Shielding: Provide good shielding between the source and yourself
as well as all other persons. Special source containers as well as all
materials with high density (e.g. lead, iron, concrete, etc.) provide
eectiveshielding.
Time:Stayasshortatimeaspossibleinradiationexposedareas.
Distance:Your distance to the source should be as large as possible.
The local dose rate of the radiation decreases in proportion to the
square of the distance to the radiation source.
Handling permit
General instructions for
radiation protection
5
2 For your safety
VEGASOURCE 82 • Source holder
66076-EN-220119
Theplantoperatormustappointaradiationsafetyocerwiththe
necessaryexpertknowledge.Heisresponsibleforensuringthatthe
radiation protection ordinance is complied with and for implementing
all radiation protection measures.
Youcanalsondcertiedcourseprovidersonthehomepageofthe
FederalOceforRadiationProtection:www.bfs.de.
Controlareasareareasinwhichthelocaldoserateexceedsacertain
value.Onlypersonswhoundergoocialdosemonitoringareallowed
intothesecontrolareas.Youcanndtherespectivelyvalidlimitvalues
for control areas in the radiation protection ordinance.
We are at your disposal for further information concerning radiation
protection and regulations in other countries.
2.2 Appropriate use
When in operating mode, the source container VEGASOURCE 82 de-
scribed in this document contains a radiactive source for radiometric
level, interface, switching and density measurement as well as mass
owdetection.Thesourcecontainershieldstheradiationofromthe
surroundingsandonlyallowsittoexit,practicallyunhindered,inthe
direction of measurement.
Toensuretheshieldingeectandexcludedamagetotheradioactive
source, all instructions in this operating instructions manual and the
legal radiation protection regulations must be observed during instal-
lation and operation.
Operational reliability is ensured only if the instrument is used prop-
erly. We are not liable for damages caused by improper use.
Youcannddetailedinformationabouttheareaofapplicationin
chapter " Product description".
2.3 Warning about incorrect use
Inappropriate or incorrect use of this instrument can give rise to
hazards,e.g.risktopersonsthroughexposuretogammaradiation.
Damage to property and persons or environmental contamination can
result. Also, the protective characteristics of the instrument can be
impaired.
Take note of the respective safety instructions.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives.The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument. When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
During the entire duration of use, the user is obliged to determine the
compliance of the necessary occupational safety measures with the
Radiationsafetyocer
Control area
6
2 For your safety
VEGASOURCE 82 • Source holder
66076-EN-220119
current valid rules and regulations and also take note of new regula-
tions.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed.
2.5 Application reference
• Take note of the applicable regulations and national/international
standards.
• Take note of the radiation protection ordinance when using, storing
and working with the radiometric measuring system.
• Take note of the warning instructions and safety zones.
• Install and operate the instrument according to the documentation
andtherespectiveocialregulations.
• The instrument must not be operated and stored outside the
speciedparameters.
• Protecttheinstrumentagainstextremeinuences(e.g.chemi-
cal products, weather, mechanical shock, vibration, etc.) during
operation and storage. Especially when loaded with a source, the
instrument may not be destroyed for any reason (e.g. for scrap-
ping).
• Before switching on the radiation, make sure that no persons are
in the radiation area (also not outside the vessel). The radiation
must only be switched on by trained personnel.
• Do not use a corroded or damaged instrument. Inform the respon-
sibleradiationsafetyocerassoonasdamageorcorrosion
appears and follow his instructions.
• Carry out the necessary tightness test according to the applicable
rules and instructions.
• If there are doubts about the proper condition of the measuring
system, check if there is radiation in the environment of the instru-
mentandinformtheresponsibleradiationsafetyocer.
• Always secure the switch position OFF with a lock.
The combination lock can be opened with the number combination
000 on delivery.
We recommend changing the number combination to a personal
number sequence. Make a note of the number combination and keep
it in a safe place.
7
2 For your safety
VEGASOURCE 82 • Source holder
66076-EN-220119
2.6 Installation and operation in the USA and
Canada
ThisinformationisonlyvalidforUSAandCanada.Hencethefollow-
ingtextisonlyavailableintheEnglishlanguage.
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code.
2.7 Environmental instructions
Protection of the environment is one of our most important duties.
That is why we have introduced an environment management system
with the goal of continuously improving company environmental pro-
tection.Theenvironmentmanagementsystemiscertiedaccording
to DIN EN ISO 14001.
Pleasehelpusfullthisobligationbyobservingtheenvironmental
instructions in this manual:
• Chapter " Packaging, transport and storage"
• Chapter " Disposal"
8
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-220119
3 Product description
3.1 Conguration
Thetypelabelscontainthemostimportantdataforidenticationand
use of the source holder and the source:
• Source holder
• Order code
• Serial number - Source holder
• Exitangle
• QR code
• Article number - Documentation
• Source
• Isotope contained
• Activity
• Country of origin
• Serial number - Source
• Loading date
The serial number allows you to access the delivery data of the instru-
ment via " www.vega.com", " Instrument search (serial number)".
Thereareseveralversionsavailablewithdierentoptionsforopening
orblockingthebeamexit.Apartfromthemanualversions,thereare
also a version with pneumatic switchover.
Type label
Versions
9
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-220119
X
C
B
Fig. 2: Versions VEGASOURCE 82 (Overview)
Version X: Standard version with manual changeover (lock for position: OFF)
Version C: Standard version with manual changeover (lock for position: ON/OFF)
Version B: with pneumatic switchover
Features of the versions
X
Manually
C
Manually
B
Pneumatics
Manual switching ● ● –
Cover (optional) ● ● –
Padlock - ON – ●–
Padlock - OFF ● ● ●
Pneumatic switching – – ●
With electrical ON/OFF position switch (optionally) ● ● ●
With Interlock switch (optionally) ● ● –
Tab. 1: Features of the instrument versions
10
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-220119
Version X, C
1
2
3
4
Fig. 3: Position of the type labels - e.g. version X, C - Manual switchover
1 Type label - Source holder
2 Type label - Source
3 Position indication OFF
4 Position indication ON
B
A
1
6
5
12
11
10
2
3
4
7
8
9
2
2
Fig. 4: Type label - e.g. version X, C - Manual switchover
A Type label - Source
B Type label - Source holder
1 Warning - Radioactivity
2 Source: Cs-137
3 Activity of the sources in MBq and mCi or GBq and mCi
4 Country of origin of the source
5 Loading date of the sources (MM/YYYY)
6 Serial number of the source capsule (for traceability of the source)
7 Order code - Source container
8 Serial number - Source holder
9 Beam exit angle
10 Manufacturer
11 QR code
12 Number of the corresponding operating instructions
Table des matières
Autres manuels Vega Dispositif de protection
Manuels Dispositif de protection populaires d'autres marques
nxt
nxt BIA-nXt-DPC 1-22 Manuel utilisateur
TFortis
TFortis SG-Switch Manuel utilisateur
BERNINI DESIGN
BERNINI DESIGN Be172 Manuel utilisateur
Rayleigh Instruments
Rayleigh Instruments RI-ENERGYSET-3P-ESS-50-100 Manuel utilisateur
GE
GE Multilin 3 Series Manuel utilisateur
E.K.T.
E.K.T. ke-DP01 Manuel utilisateur
