WORKING INSTRUCTIONS
AND MAINTENANCE
ACNH B.V.
http://www.wentellagers.nl
-2 -
VARVEL
IUM
WORKING INSTRUCTIONS
AND
MAINTENANCE
SPEED REDUCERS
RC - Helical Gearboxes
RD - Helical Gearboxes
RP - Helical Gearboxes
RS - Worm Gearboxes
RT - Worm Gearboxes
XA - Helical Gearboxes
VARIATORS
VR - Mechanical, dry friction
VR
D
RC
RD
RS
RT
RP
XA
ACNH B.V.
http://www.wentellagers.nl
-3 -
VARVEL
IUM
CONTENTS - GENERAL INFORMATION
CONTENTS
1 GENERAL INFORMATION 3
2 SAFETY WARNINGS 4
2.1 Product Operation 4
2.2 Prevalent Use 4
2.3 Transport 4
2.4 Long-Term Storage 4
2.5 Environmental Management 4
3 PRODUCT LAYOUT 4
3.1 Gearboxes Series RC 5
3.2 Gearboxes Series RD 6
3.3 Gearboxes Series RP/XA 7
3.4 Gearboxes Series RS 8
3.5 Gearboxes Series RT 9
3.6 Torque Limiter Option TLI 10
3.7 Variators Series VR 11
4 INSTALLATION 12
4.1 Tolerances 12
4.2 Precautions 12
4.3 Groundwork 12
4.4 Set up 12
4.5 Pinions, Couplings 12
4.6 Torque Arm 12
4.7 Painting 12
5 STARTING 13
5.1 Series RS, RT 13
5.2 Series RC, RD, RP, XA, VR 13
6 INSPECTIONS AND MAINTENANCE 14
6.1 Intervals 14
6.2 Maintenance Service 14
7 MALFUNCTIONING 15
7.1 Major Events 15
7.2 Customers Service 15
8 LUBRICANTS 16
8.1 Recommended Types 16
8.2 Quantity Series RC, RD 16
8.2 Quantity Series RP, RS, RT, XA 17
9 DIRETTIVE 94/9/CE - (ATEX) 18
DECLARATION OF CONFORMITY 23
1 GENERAL INFORMATION
Varvel speed reducers and variators are not in the field of application of the Machinery Directive, Article 1(2), and they
must be not put into service until the machinery into which they are to be incorporated, has been declared in conformity
with the provisions of Article 4(2), Annex II (B) of Machinery Directive 98/37/CE and, for Italy only, of DL 459/96.
Regular operation and the right to guarantee servicing request the observance of information contained in this manual that
must be read before the gearbox is put into service.
ACNH B.V.
http://www.wentellagers.nl
-4 -
VARVEL
IUM
SAFETY WARNINGS
PRODUCTS LAYOUT
2 SAFETY WARNINGS
2.1 Products Operation
During operation, outer surfaces of gearboxes and variators may warm up because of in motion parts and also by external
environmental conditions.
Everything referred to transport, stocking, assembling, setting up, starting and maintenance must be performed by trained
personnel and that follows this manual within specific national / regional regulations about safety and prevention of
accidents.
2.2 Prevalent Use
Gearboxes and variators referred to in this manual are destined to operate industrial applications and they correspond to
standards and regulations where applicable.
Performances and technical data are available in the unit’s nameplate and from the related documentation.
2.3 Transport
Carefully check the state of the goods at their receipt and immediately notify the possible damages to the carrier.
2.4 Long-Term Storage
Stocked units must be kept in dry warehouse and dust free.
For storage longer than 3 months, apply antioxidants on the shafts and machined surfaces paying special attention to
oilseal lips.
Storages longer than one year reduce bearing grease lifetime.
2.5 Environmental Management
In conformity with Environmental Certification ISO14001, we recommend the following to dispose of
• scrapped gearbox components: to deliver to authorised centres for metal object collection:
• drained oils and lubricants: to deliver to Exhausted Oil Centres;
• product accompanying packages (pallets, carton boxes, paper, plastic, etc.): to deliver into regeneration / recycling
circuits as far as possible, by delivering separate waste classes to authorised companies.
3 PRODUCTS LAYOUT
The following layouts supply a generic help in finding out the most significant parts of the products.
Various design executions of sizes, assembling versions, number of stages actually origin a variety of solutions and
therefore, we recommend to refer to the appropriate catalogue.
ACNH B.V.
http://www.wentellagers.nl
-5 -
VARVEL
IUM
PRODUCTS LAYOUT
3.1 Series RC
The layout shows the general structure of a two-stage foot-mounted helical gearbox type FRC.
The exact identification of spare parts is sent to the appropriate Catalogue MRC.
01 Oilseal 19 Bearing
02 Housing 20 Bearing
03 Key 21 Pinion
04 Output shaft 22 Key
05 Key 23 Gear
06 Bearing 24 Bearing
07 Spacer 26 Bearing
11 Gasket 27 Gear
13 Bearing 29 IEC input cover
15 Pinion 33 Hollow input
16 Key 35 Oilseal
17 Hollow input
ACNH B.V.
http://www.wentellagers.nl
-6 -
VARVEL
IUM
PRODUCTS LAYOUT
3.2 Series RD
The layout shows the general structure of a two-stage foot-mounted helical gearbox type FRD.
The exact identification of spare parts is sent to the appropriate Catalogue MRD.
01 Input cover 55 Spacer
02 Hollow input 65 Bearing
04 Pinion 66 Bearing
15 Bearing 67 Bearing
16 Bearing 68 Bearing
20 Oilseal 69 Oilseal
41 Gear 74 Circlip
50 Housing 81 Cover
52 Output shaft 82 Gasket
53 Pinion 85 Flange IEC
54 Gear
ACNH B.V.
http://www.wentellagers.nl
-7 -
VARVEL
IUM
PRODUCTS LAYOUT
3.3 Series RP and XA
The layout shows the general structure of a one-stage flange-mounted helical gearbox type FRP and FXA.
The exact identification of spare parts is sent to the appropriate Catalogue MRP or MXA.
01 Housing 12 Oilseal
02 Circlip 13 Pinion
03 Oilseal 15 Bearing
04 Output shaft 16 Bearing
06 Screw 18 Circlip
07 Bearing 19 Bearing
08 Gear 20 Key
10 Flange IEC 21 Adapter
11 Circlip 24 Circlip
FXA
FRP
ACNH B.V.
http://www.wentellagers.nl
-8 -
VARVEL
IUM
PRODUCTS LAYOUT
3.4 Series RS
The layout shows the general structure of a foot-mounted worm gearbox type FRS.
The exact identification of spare parts is sent to the appropriate Catalogue MRS.
01 Housing 63 Bearing
04 Side cover 80 Oilseal
07 Flange IEC 81 Oilseal
31 Worm wheel 82 Oilseal
50 Worm shaft 84 Oilseal RCA
60 Bearing 125 Circlip
61 Bearing 126 Circlip
62 Bearing
ACNH B.V.
http://www.wentellagers.nl
-9 -
VARVEL
IUM
PRODUCTS LAYOUT
3.5 Series RT
The layout shows the general structure of a foot-mounted worm gearbox type FRT.
The exact identification of spare parts is sent to the appropriate Catalogue MRT.
01 Housing 63 Bearing
04 Side cover 80 Oilseal
07 Flange IEC 81 Oilseal
31 Worm wheel 82 Oilseal
50 Worm shaft 84 Oilseal RCA
60 Bearing 125 Circlip
61 Bearing 126 Circlip
62 Bearing
ACNH B.V.
http://www.wentellagers.nl
-10 -
VARVEL
IUM
PRODUCTS LAYOUT
3.6 Torque Limiter Option TLI
The layout shows the general structure of a built-in torque limiter type TLI fitted inside a worm gearbox MRS or MRT.
The exact identification of spare parts is sent to the appropriate Catalogue TL.
01 Lock nut 08 Hollow output shaft
02 Bellville washer 10 Cover
03 Bush 60 Bearing
04 Oilseal 61 Bearing
05 Key 80 Oilseal
06 Spacer 81 Oilseal
07 Worm wheel
ACNH B.V.
http://www.wentellagers.nl
