TECHNICAL ASSISTANCE

When trouble is reported, verify there are no broken connections to the unit.

Assistance in troubleshooting is available from the factory. When calling, you should

have a VOM and a lineman's test set available and be calling from the job site. Call

(540) 427-3900 and ask for Technical Support, or call (540) 427-6000 for Valcom

24-hour Automated Support or visit our website at http://www.valcom.com.

Valcom equipment is not field repairable. Valcom, Inc. maintains service facilities in

Roanoke, VA. Should repairs be necessary, attach a tag to the unit clearly stating

your company name, address, phone number, contact person, and the nature of the

problem. Send the unit to: Valcom, Inc.

Repair and Return Dept.

5614 Hollins Road

Roanoke, VA 24019-5056

VALCOM LIMITED WARRANTY

Valcom, Inc. warrants its products to be free from defects in materials and workmanship

under conditions of normal use and service for a period of one year from the date of

shipment. The obligation under this warranty shall be limited to the replacement, repair

or refund of any such defective device within the warranty period, provided that:

1. inspection by Valcom, Inc. indicates the validity of the claim,

2. the defect is not the result of damage, misuse, or negligence after the original

shipment,

3. the product has not been altered in any way or repaired by others and that factory

sealed units are unopened (A service charge plus parts and labor will be applied to

units defaced or physically damaged),

4. freight charges for the return of products to Valcom are prepaid,

5. all units 'out of warranty' are subject to a service charge. The service charge will

cover minor repairs (Major repairs will be subject to additional charges for parts and

labor).

This warranty is in lieu of and excludes all other warranties, expressed or implied,

and in no event shall Valcom, Inc. be liable for any anticipated profits, consequential

damages, loss of time or other losses incurred by the buyer in connection with the

purchase, operation or use of the product.

This warranty specifically excludes damage incurred in shipment. In the event a product

is received in damaged condition, the carrier should be notified immediately. Claims for

such damage should be filed with the carrier involved in accordance with the F.O.B.

point. Headquarters:

Valcom, Inc.

1111 Industry Avenue

Roanoke, VA 24013

Phone: (540) 427-3900

FAX: (540) 427-3517

In Canada:

CMX Corporation

35 Van Kirk Drive #11 and 12

Brampton, Ontario L7A1A5

Phone: (905) 456-1072

FAX: (905) 456-2269

INSTALLATION INSTRUCTIONS FOR

AMPLIFIED TRACK STYLE SPEAKERS

MODEL NO. V-1013A AND V-1014A

Issue 4 947034

VALCOM ONE-WAY AMPLIFIED TRACK STYLE SPEAKERS

Valcom Track Style Speakers, V-1013A (one-watt) and V-1014A (five watt), are

weather resistant, self-amplified and provide voice paging as well as background

music. These speakers have externally accessible volume controls that are adjustable

by a screwdriver through the hole in the grille and are available in white, black, and

gray. Model V-1013A-W White Model V-1014A-W

Model V-1013A-BK Black Model V-1014A-BK

Model V-1013A-GY Gray Model V-1014A-GY

DIMENSIONS/WEIGHT

•V-1013A- 5.8”Dia x 10”H (14.73cm Dia. x 25.4cm H)

•2.5 lbs. (1.14kg)

•V-1014A- 5.8”Dia x 10”H (14.73cm Dia. x 25.4cm H)

•3.1 lbs. (1.41kg)

The V-1013A requires -24VDC, 50 mA (1 Valcom Power Unit) and the

V-1014A requires -24VDC, 300 mA (6 Power Units).

The V-1013A and V-1014A are both FCC Part 68 Registered under

BAFUSA-69358-KX-N.

Note: Do not connect this speaker directly to a 25/70/100 volt amplifier

as damage to both the amplifier and speaker may occur.

INSTALLATION

1. Mount the bracket.

2. Remove knobs and mount speaker to bracket.

3. Attach knobs and position at the desired angle. Tighten knobs. (See Figure 1).

Typical coverage of these speakers is 600 square feet with good quality paging

heard up to thirty feet in front of the speaker. Speakers should be spaced

approximately twenty feet apart. The five watt version is recommended for

higher noise level areas.

CONNECTIONS

Recommended Quantity of Speakers per Specific Power Run

Speakers per Power Run Wire Run Length (Ft.)

V-1013A V-1014A 24AWG 22AWG

250

500

1000

400

800

1600

TROUBLESHOOTING CHART

SYMPTOM ACTION

No audio from

speaker

Low volume from

speaker

Loud squeal

(feedback)

1. Verify volume control is turned up (clockwise).

2. Using a lineman's test set, check for proper audio

level at Tip and Ring leads and if necessary at the

source.

1. Verify volume control is turned up.

2. Check voltage at the speaker when in use, (-18 to

-24VDC required).

3. Using a lineman's test set, check for proper audio

level on Tip and Ring leads. It is possible that

some low level audio will be heard with only one

side of Tip and Ring connected.

1. Decrease volume of speaker (counterclockwise).

2. Increase the distance between telephone and

speaker.

3. Install confidencer on the telephone in severe

problem areas.

Knob

Mounting

Bracket

FIGURE 1

Volume

Control

(Tip/A) Green

(Ring/B) Red

(-24VDC) White

(GND) Black

One-Way

Amplified

Speaker

Page

Out

Valcom Page

Control

Valcom -24VDC

Power Supply

FIGURE 2
