Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Table of Contents

MOUNTING

Wall Mount Installation………………………………………………………………… Page 2

Double Mount Installation……………………………………………………………… Page 3

WIRING INFORMATION

Wiring Information……………………………………………………………………... Page 4

OPERATION

Operational Instructions………………………………………………………………… Pages 5 - 6

FREQUENTLYASKED QUESTIONS

Frequently Asked Questions…………………………………………………………… Page 7

TROUBLESHOOTING

Troubleshooting……………………….……………………………………………… Page 8

DIAGNOSTIC TESTING

Diagnostic Tests Procedures…………………………………………………………… Pages 9 - 11

FCC INFORMATION

FCC Information……………………………………………………………………….. Page 12

For clocks with date codes beginning December 2009

This product is UL and cUL listed

Page 2

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

1. Connect the wiring as shown on the wiring diagram (110V or 24V

ONLY).

2. Mount both plastic anchors in the wall.

3. Insert the sheet metal screws (#10) through the mounting bracket into

the plastic anchors.

4. Plug the connector into the movement (110V or 24V ONLY).

5. Hang the clock on the mounting bracket.

6. Put the screw (4mm) through the hole on the top of the clock into the

hole at the top of the mounting bracket.

INSTRUCTIONS

12” CLOCK

Wall Mount Installation

24 Volt/110 volt options shown in diagram

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Page 3

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

1. Screw the mounting bracket to the double gang box using four (4) inner

holes on mounting bracket, or mount the mounting bracket directly to

the wall or ceiling using the four (4) outer holes.

2. Insert the wires through the mounting bracket (110V or 24V ONLY).

3. Route the wires through the clock hanging rod.

4. Secure hanging rod to mounting bracket with screws supplied, and place

cover over connection.

5. Connect the wiring as shown on the wiring diagrams.

6. Plug the connectors into the movements (110V or 24V ONLY).

7. Place the clocks on the double mount housing and tighten the screws to

secure clocks as shown above.

INSTRUCTIONS

Double Mount Installation

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Page 4

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Sapling WIRELESS

“WHERE TIMING AND TECHNOLOGY MEET”

Diagnostic Switch

Diagnostic LED

Transmit/Receive

FCC ID R73AMR001

Dependent upon model number, Valcom wireless analog

clocks are powered by 2 “D” cell batteries, 24 vac or 110 vac.

Wiring Information

—————————————

Page 5

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

There are four (4) ways to install Valcom’s Analog Wireless Clock system. The user can choose

any of the combinations listed below, or any combination of the three (3).

Option #1:

There is a main high powered transceiver in the building (V-WMCA) and repeaters (V-

WMCRA) as needed to cover the entire premise. In this option, the system does not depend

on the slave clocks for transmission.

Option #2:

There is at least one (1) high powered transceiver (V-WMCA) in the building and in order to

cover the entire premise, the battery-operated clocks are used as transceivers/repeaters.

Option #3:

There is at least one (1) high powered transceiver (V-WMCA) in the building and in order to

cover the entire premise, the power (24V or 110V) operated clocks are used as transceiv-

ers/repeaters.

Option #4:

There are multiple transmitters that will cover the entire building or campus.

Operational Instructions

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

IMPORTANT: We highly recommend installing the main transceiver (V-WMCA) before the

installation of the Valcom Wireless analog clocks.

In order to install the clock, simply remove the battery cover, and install two (2) D cell batteries

(recommended battery type: Duracell®PROCELL®). After installation of the batteries, replace the

battery cover and the clock should start correcting within five (5) minutes.

Normal Mode/Economy Mode

The Valcom Wireless Analog Series clocks have two (2) different modes in which they will operate.

Normal mode allows the clock to transmit/receive every two (2) hours. This mode will allow the

clock to have a 5 year battery life (provided good reception). Economical mode allows the clock to

transmit/receive every four (4) hours. This mode will allow the clock to have a 8 year battery life

(provided good reception).

Normal mode is defaulted when shipped from the factory.

To toggle this mode, push and release the Diagnostic Switch and the Transmit/Receive switch si-

multaneously. If 5 year mode is selected, the LED will be solid RED for one minute and the second

hand will go to 5 (25 seconds). If 8 year mode is selected, the LED will be solid GREEN for one

minute and the second hand will go to 8 (40 seconds).

IMPORTANT: If a clock is being added to an existing system (existing clocks date coded

prior to December 2009), it must be in normal mode.

Page 6

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Initial Setup

1. All wireless clock systems require at least one master transmitter. This may be a V-WMCA

Wireless Master Clock, a V-GPS-TX Wireless Master Clock with GPS or a V-WMCRA Wire-

less Repeater (configured as a transmitter) that is connected to an appropriate Valcom system.

2. The master transmitter should be installed and operational prior to the installation of any wire-

less clocks. The preferred location for the master transmitter is typically in a central location

that will minimize the number of obstructions (walls, etc) between the master transmitter and

the wireless clocks.

3. Clocks should be installed concentrically from the location of the master transmitter.

4. Once a clock is installed and powered (either by installing the batteries or connection to 24V (ac

or dc) or 110V 60 Hz ac) it should correct within 5 minutes. If the clock (clock “A” for discus-

sion) does not correct within 5 minutes, press the Transmit/Receive button once on the closest

clock that has corrected within the past 12 hours (clock “B” for discussion). The second hand of

clock “B” will move to “8” indicating that it is locked in the transmit mode. Next, press the

Transmit/Receive button on clock “A” twice. The second hand of clock “B” will move to “4”

indicating that it is locked in the receive mode. If clock “A” still does not correct, there is too

much distance between clocks. Valcom recommends a maximum clocks separation of 60 feet.

Clocks that have been forced into transmit or receive will automatically resume normal opera-

tion within 10 minutes.

Operational Instructions

Notes:

Refer to the diagnostics section for useful information.

Additional master transmitters or V-WMCRA Wireless Repeaters may be added as necessary and/or to

propagate correction signal between buildings.

The coverage of the master transmitter will vary based upon building construction. This is typically not

important as each wireless clock acts as a repeater.

Upon application of power, if correction signal is received, the clock will briefly enter diagnostic 2 and

the second hand’s landing position will indicate signal strength.

Page 7

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Frequently Asked Questions

What battery size do I use for the wireless clock?

The batteries required are two (2) “D” cell batteries. The recommended battery type is “Duracell®:

Procell®[D] size”.

Will the clock cause interference with any of my other wireless devices?

No, the Valcom analog wireless clock works on 915 - 928 MHz frequency-hopping technology.

The clock switches frequencies automatically when the receiver and transceiver is open, thus inter-

ference is avoided.

Is there any advantage to a powered clock system as opposed to a battery operated system,

assuming a single transceiver is in the building (V-WMCA)?

The powered wireless clock receives and transmits every minute and in locations where the signal is

marginal, the likelihood of receiving a signal increases because of the frequent transmission rate.

What is the advantage of having multiple transceivers V-WMCA on a powered clock system?

Assuming the distances between the clocks is sufficient to receive the signal with an analog clock,

there is no advantage of multiple transceivers on a powered system.

How long does it take for the clock to receive a signal?

Upon power up of the clock, the receiver will be turned on for a half hour until the signal is ac-

quired. If the user wishes to manually look for the signal, press the Transmit/Receive switch twice

on the movement.

Can the clocks be set manually to display the correct time at installation (as a temporary measure

until the master clock is installed)?

Valcom wireless clocks can NOT be set manually.

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Page 8

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

What happens if I power up the clock and the clock is not moving?

The clock should move at normal speed upon power up. If it does not move at normal speed, check the

battery and make sure the clock receives power. Also, be sure to remove the pin prior to starting up the

clock.

What happens if the clock does not receive the signal?

Take the clock within close proximity to the transceiver and power up the clock. If the clock is battery-

operated, remove the battery and put the battery back in again.

Also, press the Transmit/Receive switch once on the clock closest to the clock that is working. The sec-

ond hand will go to the forty (40) second location notifying the user that the clock is transmitting the

signal. Then go to the clock that isn’t working and press the Transmit/Receive switch twice. The sec-

ond hand will go to the twenty (20) second location notifying the user it is looking for the signal. This

should get the signal to the clock.

If the clock does not correct, call Valcom technical support.

What happens if the clock shows the wrong time?

Move the clock to Diagnostic #1 in order to find the last time that it received the signal.

Perform a Diagnostic #3 to check the gears for the clock.

How do you know if the clock receives a good signal?

Perform Diagnostic #2. See page 10 for detailed instructions.

I have a location with a marginal signal. What should I do?

a. Try to install the transceiver in a nearby area.

b. If budget is an issue, install one (1) powered clock.

What can I do if I have a clock in a location where the distance is too far away from the last

clock?

Install a repeater, part number V-WMCRA, to give additional distance to the clock system.

Troubleshooting

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Page 9

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.comValcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

Overview

The number of times that the switch is pressed will determine the diagnostic mode. After

determining the diagnostic mode, the LED between the two (2) switches will start flash-

ing a green light. The number of flashes will display the diagnostic number.

DIAGNOSTIC #1

This diagnostic will determine how long (# of hours) since the clock last received the

communication signal.

In order to enter diagnostic one (1) mode, push the Diagnostic Switch once which is indi-

cated by the green LED flashing one (1) time with a one (1) second break.

A. While in diagnostic modes, hour and minute hands continue to run normally.

B. The second hand will display how long since the clock received time signal (please

see below table for details)

C. After three (3) minutes, the clock will resume normal operation.

Second Hand Position Time Since Clock Last Received a Communication Signal

12 Clock has received communication within the past hour

1 “ “ “ between one and two hours ago

2 “ “ “ between two and three hours ago

3 “ “ “ between three and four hours ago

4 “ “ “ between four and five hours ago

5 “ “ “ between five and six hours ago

6 “ “ “ between six and seven hours ago

7 “ “ “ between seven and eight hours ago

8 “ “ “ between eight and nine hours ago

9 “ “ “ between nine and ten hours ago

10 “ “ “ between ten and eleven hours ago

11 “ “ “ more than eleven hours ago

Diagnostic Testing

Page 10

Valcom 12” & 16” Wireless Clock Installation Manual (Rev 1.02)

Valcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.comValcom 5614 Hollins Road Roanoke, VA 24019 Phone: (540) 563-2000 Fax: (540) 362-9800 www.valcom.com

DIAGNOSTIC #3

This diagnostic will test the mechanical portion and some of the electronic components

of the clock.

In order to enter Diagnostic #3 mode, push the Diagnostic Switch three (3) times which

is indicated by the green LED flashing three (3) times with a one (1) second break.

Upon completion of Diagnostic 3, if the Diagnostic LED flashes red, the clock requires

repair. Please contact Valcom Technical Support.

DIAGNOSTIC #2

This diagnostic will determine the quality of the time signal.

In order to enter Diagnostic #2 mode, push the Diagnostic Switch twice which is indi-

cated by the green LED flashing twice with a one (1) second break.

A. While in diagnostic modes, hour and minute hands continue to run normally.

B. The second hand will display the quality of the time signal. (The signal percentage

is displayed on the dial of the clock. It goes from 1 – 10, with 1 being the best sig-

nal strength and 10 being the least signal strength.

C. After three (3) minutes, the clock will resume normal operation.

Diagnostic Testing

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Valcom Horloge

Valcom

Valcom VIP-A12 Manuel utilisateur

Valcom

Valcom V-D11025A Instructions de montage

Valcom

Valcom VIP-429A-A Manuel utilisateur

Valcom

Valcom VIP-429A-A-IC Manuel utilisateur

Valcom

Valcom VIP-D425A Manuel utilisateur

Valcom

Valcom VIP-431A-DS Manuel utilisateur

Valcom

Valcom V-AW12A Manuel utilisateur

Valcom

Valcom V-D2425 Manuel utilisateur

Valcom

Valcom V-WMCA Series Manuel utilisateur

Valcom

Valcom VIP-A12A Manuel utilisateur

Valcom

Valcom VE4171-D440 Manuel utilisateur

Valcom

Valcom VIP-429A-A-SA Manuel utilisateur

Valcom

Valcom IP Solutions VIP-A12DS Manuel utilisateur

Valcom

Valcom VIP-D625 Manuel utilisateur

Valcom

Valcom VIP-D425DS Manuel utilisateur

Valcom

Valcom VE4122-A12 Manuel utilisateur

Valcom

Valcom VIP-A12ADS Manuel utilisateur

Valcom

Valcom V-D2425B Instructions de montage

Valcom

Valcom V-D11025B Manuel utilisateur

Valcom

Valcom VIP-A12ADS Manuel utilisateur

Valcom

Valcom V-A2412 Manuel utilisateur

Valcom

Valcom InformaCast VIP-431-A-IC Manuel utilisateur

Valcom

Valcom VIP-MC Manuel utilisateur

Valcom

Valcom VIP-D425 Manuel utilisateur

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8256-AL Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

La Crosse Technology

La Crosse Technology WT-3141b Manuel

La Crosse Technology

La Crosse Technology W86531 Manuel utilisateur

Sharp

Sharp SPC900 Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-50447 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur
