Vacmaster VMVDK1538SWC-06 Manuel utilisateur

VDK1538SWC

38L 1500W

ORIGINAL INSTRUCTIONS

31 32 33 34

26 27 28 29 30

20 21 22 23 2418

TABLE OF CONTENTS

SECTION PAGE

Symbols............................................................................................................................................ 6

Safety Information ............................................................................................................................ 7

Unpacking and Checking Carton Contents .................................................................................... 10

Assembly.........................................................................................................................................11

Operation........................................................................................................................................ 12

Maintenance................................................................................................................................... 15

Troubleshooting.............................................................................................................................. 16

Technical Data ................................................................................................................................ 17

Recycling and Disposal .................................................................................................................. 17

Thank you for purchasing this Vacmaster® wet and dry vacuum cleaner. Feel condent that with

Vacmaster®you are obtaining a high quality product engineered for optimal performance. This

vacuum cleaner is suitable for use with both liquids and dry materials.

FOR YOUR SAFETY: CAREFULLY READ AND UNDERSTAND ALL INSTRUCTIONS.

SYMBOLS

Caution

Read instruction manual. Failure to follow the warnings and

instructions may result in electric shock, re and/or serious injury.

Vacuum cleaners of dust category M according to IEC/EN 60335-2-69

for dry vacuuming of hazardous dusts with an exposition limit value

≥0.1 mg/m

WARNING: The vacuum cleaner may contain materials that are

hazardous to one's health. Have the emptying and maintenance,

incl. the disposal of dust-collection container, carried out only

by a specialist. Appropriate protective equipment is required.

Do not operate the vacuum cleaner without the complete lter

system. Otherwise there is danger to your own health.

SAFETY INFORMATION

READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE

USING THIS VACUUM CLEANER.

This machine is intended for commercial use, for example in

hotels, schools, hospitals, factories, shops, ofces and rental

businesses. Any other use is considered as improper use. The

manufacturer accepts no liability for any damage resulting from

improper use. The risk for such improper use is borne solely by

the user.

When using the equipment, a few safety precautions must be

observed to avoid injuries and damage. Please read the complete

operating manual with due care. Keep this manual in a safe

place so that the information is always available. If you give

the equipment to any other person, give them these operating

instructions as well. We cannot accept any liability for damage or

accidents which arise due to a failure to follow these instructions

and the safety information.

• Never leave the appliance switched on unattended, if you leave

the work area, switch the appliance off or unplug it from the

power supply.

• Do not vacuum or use this vacuum cleaner near ammable

liquids, gases or explosive vapours like gasoline or other fuels,

lighter uids, cleaners, oil-based paints, natural gas, hydrogen,

or explosive dusts like coal dust, magnesium dust, grain dust

or gun power. Sparks inside the motor can ignite ammable

vapours or dust.

• This vacuum cleaner is not suitable for the vacuuming of

asbestos or asbestos dust.

• Do not vacuum anything that is burning or smoking, such as

cigarettes, matches, or hot ashes.

• Ensure the hose and connections are always pointed away

from the users face, hair, ears and eyes during operation and

never direct the nozzle towards persons or animals.

• Clear the working area of any items or possessions that you do

not wish to be vacuumed before operation.

• Keep cord away from heated surfaces.

• Do not expose to rain. Store indoors.

• Do not unplug by pulling on the cord. To unplug, grasp the plug,

not the cord.

• Do not use with damaged cord, plug or other parts.

• Do not pull or carry by cord, use cord as handle, close a door

on cord, or pull cord around sharp edges or corners.

• Do not handle the plug or vacuum cleaner with wet hands.

• Frequently check that the oat valve positioned underneath the

motor is able to move freely.

• Do not use this vacuum cleaner with a torn lter or without the

lter installed.

• Do not allow to be used as a toy. Close attention is necessary

when used by or near children.

• To reduce the risk of injury from accidental starting, unplug

power cord before changing or cleaning lter.

• Unplug from power supply when not in use and before carrying

out maintenance.

• Do not cover the ventilation openings. Do not vacuum with any

ventilation openings blocked; keep free of dust, lint, hair or

anything that may reduce air ow.

• Keep hair, loose clothing, ngers, all parts of body away from

openings and moving parts.

• If the supply cord is damaged, it must be replaced by the

manufacturer, a qualied service agent or similarly qualied

persons in order to avoid a hazard.

• This machine is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be made by children

without supervision.

• For additional protection: It is recommended that this vacuum

cleaner can be used in conjunction with residual current device

(RCD) with a rated residual current of 30mA or less.

• Only use the socket outlet on the machine for purposes

specied in the instructions.

• If foam or liquid escapes from the machine, switch off immediately.

• Check the oat valve regularly to ensure it is moving freely and

examine it for signs of damage.

• Precautions should be taken when changing attachments.

• For user servicing, the machine must be dismantled, cleaned

and serviced, as far as is reasonably practicable, without

causing risk to the maintenance staff and others. Suitable

precautions include decontamination before dismantling,

provision for local ltered exhaust ventilation where the

machine is dismantled, cleaning of the maintenance area and

suitable personal protection.

• Perform a technical inspection at least annually, consisting of,

for example, inspection of lters for damage, air tightness of the

machine and proper function of the control mechanism.

• Besides the operating instructions and the binding accident

prevention regulations valid in the country of use, observe

recognized regulations for safety and proper use.

• When dust removers are used, the rate at which air is

exchanged in the room must be adequate if the exhaust

air from the vacuum cleaner is blown into the room (please

observe regulations valid in your country).

• Before starting work, the operating staff must be informed on

- use of the vacuum cleaner

- risks associated with the material to be picked up

- safe disposal of the picked up material.

• Before transporting the collection tank, close all the locks. Do

not tilt the cleaner if there is liquid in the collection tank. Do not

use a crane hook to lift the cleaner.

• For class M machines, the outside of the machine should be

decontaminated and wiped clean or treated with sealant before

being taken out of a hazardous area. All the machine parts

shall be regarded as contaminated when removed from the

hazardous area and appropriate action taken to prevent dust

dispersal.

• When using an extension lead, check the minimum cross-

sections of the cable:

WARNING: When carrying out service or repair

operations, all contaminated items which cannot be

satisfactorily cleaned are to be disposed of; such items

shall be disposed of in impervious bags in accordance

with any current regulation for the disposal of such

waste.

Cable length

Cross section

< 16 A < 25 A

up to 20 m 1.5 mm22.5 mm2

20 to 50 m 2.5 mm24.0 mm2

UNPACKING AND CHECKING CARTON

CONTENTS

1Push/Pull Handle 13 Filter Cleaning Button 25 Metal Extension Wand (x3)

2Carry Handle 14 Air Flow Indicator 26 Foam Filter

3Wing Knob 15 Hose Storage Rack 27 Cartridge Filter (pre-installed)

4Power Regulator 16 Accessory Storage 28 Disposable Bag (x5)

5 Latch 17 Squeegee Inserts 29 Washer (x4)

6 Rear Wheel 18 Brush Inserts (pre-installed) 30 Hub Cap (x2)

7 Front Caster 19 Floor Nozzle 31 Wheel Retaining Pin (x2)

8 Container 20 Suction Hose 32 Wheel Axle

9Cover Gasket 21 Crevice Tool 33 Screw (x2 )

10 Suction Port 22 Dust Bag (x5) 34 Instruction Manual

11 Power Take-off Socket 23 Round Dust Brush

12 On/Off Switch 24 Power Tool Hose Adaptor
