V-tech Twinkle & Soothe Owl Projector Instructions de montage
91-003346-000
Twinkle & Soothe Owl Projector™
Parent’s Guide
506500 US IMrev.indd 1 03/10/2017 17:56:49
2
INTRODUCTION
Thank you for purchasing the Twinkle & Soothe Owl Projector™ by
VTech®! This adorable, sleepy-eyed owl projects a calming rotating
image onto the ceiling to lull your little one to sleep. Choose between two
sound modes to play sing-along songs, calming melodies or soothing
noise. The delightful 3D nature scene inside the owl’s tummy moves
and is illuminated, bringing the scene to life.
On/Off/Mode
Selector Switch
Light Control
Button
Volume
Buttons
Motor Control
Button
Music
Button
Sensor
Switch
Volume
Buttons
Play/Pause
Button
Rotatable
Receiver
Remote
Control
506500 US IMrev.indd 2 03/10/2017 17:56:50
3
INCLUDED IN THIS PACKAGE
•One Twinkle & Soothe Owl Projector™
•One remote control
• Two adjustable crib straps
• One parent’s guide
WARNING: All packing materials, such as tape, plastic
sheets, packaging locks, removable tags, cable
ties and packaging screws are not part of this toy,
and should be discarded for your child’s safety.
ATTENTION: Pour la sécurité de votre enfant, débarrassez-
vous de tous les produits d’emballage tels que
rubans adhésifs, feuilles de plastique, attaches,
étiquettes et vis d’emballage. Ils ne font pas
partie du jouet.
NOTE: Please keep this parent’s guide as it contains
important information.
Turn the packaging locks counterclockwise
several times.
Pull out and discard the packaging locks.
Unlock the packaging locks:
506500 US IMrev.indd 3 03/10/2017 17:56:50
4
GETTING STARTED
BATTERY INSTALLATION
Owl Projector
1. Make sure the unit is turned OFF.
2. Locate the battery cover on the back of the
unit. Use a screwdriver to loosen the screw.
3. Install 4 new AA (LR6/AM-3) batteries
following the diagram inside the battery
box. (The use of new alkaline batteries is
recommended for maximum performance.)
4. Replace the battery cover and tighten the
screw to secure.
Remote Control
1. Locate the battery cover on the back of the
Remote Control. Use a screwdriver to
loosen the screw.
2. Install 2 new AAA (LR03/AM-4) batteries
following the diagram inside the battery box.
3. Replace the battery cover and tighten the
screw to secure.
506500 US IMrev.indd 4 03/10/2017 17:56:51
5
BATTERY NOTICE
• Use new alkaline batteries for maximum performance.
• Use only batteries of the same or equivalent type as recommended.
• Do not mix different types of batteries: alkaline, standard (carbon-
zinc) or rechargeable, or new and used batteries.
• Do not use damaged batteries.
• Insert batteries with the correct polarity.
• Do not short-circuit the battery terminals.
• Remove exhausted batteries from the toy.
• Remove batteries during long periods of non-use.
• Do not dispose of batteries in fire.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the toy before charging (if
removable).
• Rechargeable batteries are only to be charged under adult
supervision.
ASSEMBLY INSTRUCTIONS
With the VTech®Twinkle & Soothe Owl Projector™, safety
comes first. To ensure your child’s safety, adult assembly is required.
1. Slip one strap under a slot on the back of the unit. Then slip the
other strap under the other slot.
506500 US IMrev.indd 5 03/10/2017 17:56:51
6
2. Place the unit against the bed rail bringing
both straps over the top rail. Slip the top
of the strap under the slot on the back
of the unit and secure by choosing the
appropriate hole. Repeat this procedure
for the second strap.
3. Fasten the cord on the back of the unit
to the bed rail.
4. Pull slightly on the unit to make sure both straps have been securely
fastened.The unit should be snug against the bed rail. Please check
the unit frequently to ensure it is still secure.
5. The soother can also be placed on a night stand, dresser or table.
NOTE:
Please check the unit frequently to ensure it is still secure. We
recommend removing the soother from the crib once your baby begins
sitting or pushing up on all fours. At this time we suggest placing the
soother on a night stand, dresser or table.
506500 US IMrev.indd 6 03/10/2017 17:56:51
7
PRODUCT FEATURES
1. On/Off/Mode Selector Switch
To turn the unit on slide the On/Off/
Mode Selector Switch to select either
Lullaby Mode or Sound Mode. You will
hear sing-along songs and soothing
melodies in Lullaby Mode and soothing
sounds in Sound Mode. If a light mode
is selected, the projector will light up
and the lights will twinkle to the music
while the 3D image on the owl’s tummy
rotates.
2. Timer Switch
Slide the Timer Switch to select the
desired preset time. Once the timer
has expired, the unit will enter sleep
mode. Timer options include 10, 20 or
30 minutes.
3. Light Control Button
Press the Light Control Button
to select one of four light modes.
4. Motor Control Button
Press the Motor Control Button to
select one of three motor modes.
506500 US IMrev.indd 7 03/10/2017 17:56:53
8
5. Music Button
In each mode, press the Music Button
to play the next sound, melody or sing-
along song depending on the selected
mode.
6. Sound Sensor Switch
Slide the Sound Sensor Switch on or
off. When the Sound Sensor is turned
on, it will activate the Twinkle & Soothe
Owl ProjectorTM to play soothing sounds
or music when your baby cries. The
sound sensor will only wake up the unit
when the Sound Sensor Switch is on.
Once the selected time has expired,
the unit will automatically power down.
7. Volume Buttons
Press the + Button to increase the
volume or the –Button to decrease
the volume.
NOTE:
The unit’s default volume level is level three when you first open the unit
or when the batteries are changed. Once you have selected a volume
level for your unit other than level one, the unit will remember that
volume level each time you use the unit. If you have selected volume
level one (silent mode) as your volume level, the unit will automatically
default to volume level two once the unit has gone into sleep mode
and is reactivated.
506500 US IMrev.indd 8 03/10/2017 17:56:53
9
8. Remote Control
The Remote Control can start, pause
and control the volume up to 30 feet
away from the unit so not to disturb your
baby. Be sure there are no obstructions
directly between the Remote Control
and the Rotatable Receiver. The
Remote Control is disabled after 45
minutes without input.
NOTE:
Bright sunlight or artificial light may reduce the crib toy’s sensitivity
to the remote control. To increase the reliability, reduce ambient light
near the crib toy.
9. Rotatable Receiver
The soother features a Rotatable
Receiver which can be rotated to
receive an optimal signal from the
Remote Control.
NOTE:
Rotatable Receiver can be rotated 180 degrees clockwise and 90
degrees counterclockwise from original setting.
10. Reactivating the Unit
The unit can be reactivated by pressing any button on the unit
(not including the Sound Sensor Switch), by using the Remote
Control (if used within 45 minutes of going into sleep mode) or
when the sound sensor is activated by your baby’s cry.
NOTE:
This product is in try-me mode in the packaging. After opening the
package, turn the unit off and on again to proceed with normal play.
If the unit repeatedly powers down quickly we suggest changing the
batteries.
Volume Buttons
506500 US IMrev.indd 9 03/10/2017 17:56:53
10
ACTIVITIES
1. Lullaby Mode
Select Lullaby Mode to listen to the
sing-along songs and soothing melodies.
2. Sound Mode
Select Sound Mode to listen to a
selection of soothing sounds.
3. Play & Pause Button on the
Remote Control
Press the Play & Pause Button on the
Remote Control to pause the sounds.
Press it again to restart the sounds. If
the unit is reactivated within 5 minutes
the sing-along song, melody or soothing
sounds will continue, but if the unit is
paused for more than 5 minutes when
reactivated, the next response will play.
4. Volume Buttons on the
Remote Control
Press the + Button to increase the
volume or the – Button to decrease the
volume.
NOTE:
Point the Remote Control directly at the front of the Rotatable
Receiver and within 30 feet of the unit for an optimal signal.
506500 US IMrev.indd 10 03/10/2017 17:56:54
