V-tech Prance & Rock Learning Unicorn 1923 Instructions de montage
Prance & Rock
Learning Unicorn™
91-003259-025
Parent’s Guide
CAUS
2
Two Light-Up
Buttons
Handles
Spinner
On/Off/Mode
Selector
Volume Switch
INTRODUCTION
Thank you for purchasing the Prance & Rock Learning UnicornTM.
The unicorn easily transforms from a rocker to a ride-on. The two
chunky handles are easy for toddlers to grasp when riding on the
unicorn. Press one of the two light-up buttons to learn about colors
and to hear playful songs and imaginative phrases. Rocking or riding
on the unicorn triggers the motion sensor which responds with fun
melodies and sounds.
3
INCLUDED IN THIS PACKAGE
- One sticker sheet
- One parent’s guide
Two rockers One front link bracket
Two handles One back link bracket
Two plastic screws8 small screws
One Prance & Rock
Learning UnicornTM
Four wheels
4
WARNING:
All packing materials such as tape, plastic sheets, packaging locks,
removable tags, cable ties and packaging screws are not part of this
toy, and should be discarded for your child’s safety.
NOTE:
Please keep this parent’s guide as it contains important information.
ATTENTION :
Pour la sécurité de votre enfant, débarrassez-vous de tous les produits
d’emballage tels que rubans adhésifs, feuilles de plastique, attaches,
étiquettes et vis d’emballage. Ils ne font pas partie du jouet.
NOTE :
Il est conseillé de conserver ce guide des parents car il comporte des
informations importantes.
GETTING STARTED
BATTERY INSTALLATION
1. Make sure the unit is turned OFF.
2. Locate the battery cover on the back
of the unit. Use a screwdriver to loosen
the screw.
3. Install 2 new AAA (AM-4/LR03)
batteries following the diagram inside
the battery box. (The use of new
alkaline batteries is recommended for
maximum performance.)
4. Replace the battery cover and tighten
the screw to secure.
5
BATTERY NOTICE
• Usenewalkalinebatteriesformaximumperformance.
• Useonlybatteriesofthesameorequivalenttypeasrecommended.
• Donotmixdifferenttypesofbatteries:alkaline,standard(carbon-
zinc)orrechargeable,ornewandusedbatteries.
• Donotusedamagedbatteries.
• Insertbatterieswiththecorrectpolarity.
• Donotshort-circuitthebatteryterminals.
• Removeexhaustedbatteriesfromthetoy.
• Removebatteriesduringlongperiodsofnon-use.
• Donotdisposeofbatteriesinfire.
• Donotchargenon-rechargeablebatteries.
• Removerechargeablebatteriesfromthetoybeforecharging
(ifremovable).
• Rechargeable batteries are only to be charged under adult
supervision.
WARNING!
Safety comes first with the Prance & Rock Learning Unicorn™:
Adult assembly required. The maximum weight limit is 42 pounds.
Children over this weight should not use the ride on. Not to be
used by children over 36 months. Insufficient strength. This product
includes electronics and is not waterproof.
This package contains eight small screws. For your child’s safety,
do not let your child play with the toy until it is fully assembled.
This toy should be used in a safe area, for example, indoors, on
flat level surfaces and away from any hazards such as cars, stairs,
water etc.
Not for use on sidewalks, on pavement or near traffic.
Adult supervision is advised.
Regularly check if the eight screws are securely tightened to link
the brackets and rockers.
6
Please place the stickers on the unicorn securely as
indicated below:
ASSEMBLY INSTRUCTIONS
1. Insert the four wheels into the two
rockers as shown. You will hear the
wheels click into place to indicate they
are attached securely.
2. Insert the front link bracket and the back link bracket onto the inside
of the rockers. Secure the brackets to the rockers with the small
screws provided.
7
3. Insert the Prance & Rock Learning
UnicornTM onto the support brackets
as shown.
4. Insert the two plastic screws into the
holes in the front link and back link
brackets. Turn the screws clockwise
to secure. You will hear the locks click
into place to indicate they are attached
securely.
5. Insert the two handles into the sides
of the unicorn’s head. You will hear the
handles click into place to indicate the
handles are attached securely. Once
the handles have been attached, they
cannot be removed.
TRANSFORM FROM ROCKER TO RIDE-ON MODE
1. To change the unicorn from rocker mode to ride-on mode, press
and hold the lock next to the plastic screws and turn the screws
counterclockwise. Remove the rocker panel and turn it over so
the wheels are on the ground. Reinsert the two plastic screws into
the holes in the front link and back link brackets. Turn the screws
clockwise to secure.
8
PRODUCT FEATURES
1. On/Off/Mode Selector
To turn the unit On, slide the On/
Off/Mode selector to the Learning
& Music mode or the Adventure
mode position. You will hear a
playful song and a friendly phrase.
To turn the unit Off, slide the On/Off/
Mode selector to the Off position.
2. Volume Switch
To adjust the volume, slide the Volume
switch to the Low Volume or the
High Volume position.
3. Automatic Shut Off
To preserve battery life, the Prance & Rock Learning UnicornTM will
automatically power down after approximately 45 seconds without
input. The unit can be turned on again by pressing any button, or
by turning the spinner on the unicorn’s head.
NOTE:If the unit powers down during play, we suggest changing the
batteries.
ACTIVITIES
1. Light-Up Buttons
Press the Light-Up buttons to learn
about colors and to hear fun songs and
music in Learning & Music mode. In
Adventure mode you will hear playful
phrases, sounds and songs. When a
melody is playing, press the Light-Up
buttons to play the melody one note at
a time. The lights and horn will flash with
the sounds.
9
2. Spinner
Turn the Spinner to hear fun sounds
and short tunes in both Learning &
Music mode and Adventure mode.
The lights and horn will flash with
the sounds.
3. Motion Sensor
Rock or ride the unicorn to activate the Motion Sensor. In Learning
& Music mode you will hear playful melodies. In Adventure mode
you will hear a variety of fun sounds. The lights and horn will flash
with the sounds. The faster you ride, the faster the lights will flash.
SONG LYRICS
Song 1
I’m a pretty little unicorn.
I prance and rock, dream and sing.
Hop onto my back and we will go on a fantastic adventure.
Song 2
What an amazing journey that was,
Flying through the sky and over the rainbow.
Where should we go on our next adventure?
Song 3
What an amazing journey that was,
Exploring castles and visiting a princess.
Playing pretend is so much fun!
10
MELODY LIST
1. Bicycle Built for Two
2. A-Tisket, A-Tasket
3. Little Miss Muffet
4. Roses Are Red
5. Beautiful Dreamer
6. All The Pretty Little Horses
7. Little Robin Redbreast
8. Riddle Song
9. White Coral Bells
10. Ring Around the Rosie
CARE & MAINTENANCE
1. Keep the unit clean by wiping it with a slightly damp cloth.
2. Keep the unit out of direct sunlight and away from any direct
heat sources.
3. Remove the batteries when the unit is not in use for an extended
period of time.
4. Do not drop the unit on hard surfaces and do not expose the unit
to excess moisture.
