KIDILOOKTM

INTRODUCTION

Thank you for purchasing the VTech®Kidilook™!

Kidilook™is a digital photo frame that allows kids to view and

share their favorite pictures. With Kidilook™, you can store and

view up to 100 photos, create your own picture stories with a digital

ash card feature, and even switch to a digital clock display.

With the use of a simple PC application, you can quickly download

photos and picture stories to share with friends and family on your

Kidilook™. Also, with the easy one-click download feature, you

can even download photos from a Kidizoom Camera™directly to

your Kidilook™ through PC.

PRODUCT FEATURES

Left arrow

Button

Hole for

hand strap

Right arrow

Button

Shufe Button

Clock Button

Photo Story Button

Photo Album Button

Introduction & Product Features

Power Button

Press this button to turn the Kidilook™ON or OFF.

Left /Right arrow Button

Press direction buttons to view previous/next photo.

Photo Album Button

Press this button to view the photos.

Photo Story Button

Press this button to view your stories created on the PC.

Clock Button

Press this button to show the time.

Shufe Button

Hold this button and shake the unit to see a special effect in some

modes.

Reset Button

Press this button with an object tip to reset the unit if it stops

working properly.

USB Jack

Plug the included USB cable into this USB port to connect to your

PC.

Speaker

Power Button

Reset Button

USB Jack with

cover door

Battery door

Product Features

INCLUDED IN THIS PACKAGE

• 1 VTech®Kidilook™

• 1 PC installation CD-ROM

• 1 USB cable

• 1 User’s Manual

• 1 wrist strap

WARNING:

All packing materials such as tape, plastic sheets, wire ties and

tags are not part of this toy, and should be discarded for your

child’s safety.

PRODUCT SPECIFICATION

Display: 1.8” color LCD

Memory: Stores around 100 photos in the Kidilook™.

Photo Format Supported: JPEG, BMP

Hardware Supported: USB Connection to PC

GETTING STARTED

BATTERY INSTALLATION

Note: Adult assembly is required for battery installation. Tools

required for battery installation: screwdriver (not included).

• Make sure the Kidilook™is turned OFF.

• Locate the battery cover on the

back of the Kidilook™. Loosen the

screws using a screwdriver and

remove the battery cover.

• Install 2 new “AAA” batteries

as illustrated on the right. (The

use of new, alkaline batteries

is recommended for maximum

performance.)

• Replace the battery cover and tighten the screws. Do not over-

tighten screws.

Included In This Package

• Please note: If Kidilook™is not working properly after the

batteries have been installed, press the Reset Button and then

restart the Kidilook™.

BATTERY NOTICE

• Install batteries correctly observing the polarity (+, -) signs to

avoid leakage.

• Do not mix old and new batteries.

• Do not mix batteries of different types: alkaline, standard

(carbon-zinc) or rechargeable (nickel-cadmium).

• Remove the batteries from the equipment when the unit will

not be used for an extended period of time.

• Always remove exhausted batteries from the equipment.

• Do not dispose of batteries in re.

• Do not attempt to recharge ordinary batteries.

• The supply terminals are not to be short-circuited.

• Onlybatteriesofthesameandequivalenttypeasrecommended

are to be used.

Note: Remove battery from the toy if the low voltage detected or

the toy can’t be turned on.

HAND STRAP ATTACHMENT

INSTRUCTIONS

1. Locate the thread loop on

the end of the strap. Insert

it into the groove behind

the bar and then push it

through.

2. Feed the end of the strap up through the

loop and pull it all the way through.

3. Make sure the loop is securely tightened

around the bar.

Battery Notice

INSTALLATION OF KIDILOOK™ PHOTO

MANAGER

Insert the CD-ROM that comes with the Kidilook™. It should

be able to run installation automatically. If it doesn’t run setup

automatically, open the CD-ROM disk and click Setup.exe to run

the installation.

TO BEGIN USING KIDILOOK™

• Press the ON/OFF Button to turn on the Kidilook™.

• If it is the rst time turning on the Kidilook™,

it will prompt you to choose the language

and then set the correct time. To select the

language, press the Right arrow button to

show the next selection, and press the Left

arrow button to conrm. To set the time,

press the Left arrow button to change the

time. Press the Right arrow button to go

to the next item. When nished, press the

photo album button to start viewing photos.

• After the initial setup, each time you turn on

the Kidilook™it will go directly into Photo Album mode for

photo viewing.

• If it is in the other modes, press the Photo Album button

to switch back to the Photo Album mode.

• To switch to Photo Story mode, press the Photo Story button

and use the arrows to scroll through the story. (Photo story

needs to be created and downloaded from the PC application

Kidilook™ Photo Manager)

• Press the Clock Button to show the time.

• To change settings on the Kidilook™, press and hold the Left

arrow and Right arrow buttons at the same time for 2 seconds

to enter the setup mode. For detailed setup instructions, please

refer to the setup section shown in the manual.

• Press the On/Off Button again for 2 seconds to turn the unit

off.

To Begin Using Kidlook™

AUTOMATIC SHUT-OFF

To preserve battery life, the VTech®Kidilook™will automatically

turn off after several minutes without input. Turn the unit on again

by pressing the On/Off Button. The auto shut off timer can be

changed in the setup mode.

CONNECTING TO A PC

Connect Kidilook™to a PC with the USB cable, and then you

can start downloading photos and creating photo stories with the

included PC software, the Kidilook™ Photo Manager.

1. Locate the USB port on the back of your Kidilook™and slide

the door open.

2. Insert the USB cable (smaller end) into the USB port on the

Kidilook™.

3. Insert the larger end of the USB cable into a USB port on the

computer. A USB port is usually marked with this symbol .

MINIMUM SYSTEM/ HARDWARE REQUIREMENTS FOR PC

CONNECTION & CD ROM INSTALLATION:

• Pentium 4/ Celeron1GHz or equivalent

• Windows®2000 SP3+/ XP / Vista

• 1024 x 768 24-bit Graphics Card

Note: Once the Kidilook™is connected to the PC, it will turn on

automatically. Do not disconnect the Kidilook™or the computer

while photos are being downloaded to the Kidilook™.

To Begin Using Kidlook™

Microsoft®Windows®is a registered trademark of Microsoft

Corporation in the United States and other countries. Intel®,

Pentium®are trademarks of Intel Corporation in the United States

and other countries. All other trademarks are the property of their

respective owners.

ACTIVITIES

1. Photo Album

Press the Photo Album button to enter the Photo Album,

and it will automatically show all photos.

Slide Show

Photos will display automatically as a slide show. The delay time

between photos can be set in the setup mode. Press the Left or

the Right arrow buttons to view the previous or next photo at any

time.

Manual Mode

If the delay time is set to 0 sec, it will be in a manual mode and will

not automatically move to the next photo. User has to press the

Left or Right button to show the previous or next photo.

Shufe Photos

Hold the Shufe button and shake the Kidilook™for 1-2 seconds

to change from a sequence mode to a random photo mode .

Hold the Shufe button and shake the Kidilook™again to switch

back to showing the photos in their original sequence.

Photo Index

While in Photo Album mode, press the Photo Album button

again to show the current photo index or random icon . Press

the same button again to hide this information.

Please refer to the Setup section below on how to change

settings.

Note: Please refer to the PC application’s help on how to download

the photos to Kidilook™.

Activities

2. Photo Story

Press the Photo Story button to see your Photo Story. Press the

Left or the Right arrow buttons to view the previous or next frame

of a story. Hold the Shufe button and shake it at the same time in

order to see a fun photo shaking effect.

Note: Please refer to the PC application’s help on how to create

Photo Stories and download them to the Kidilook™.

3. Clock

Press the Clock button to show the current time. Hold the Shufe

button and shake it at the same time for a surprise. To set the

time, please refer to the Setup section below.

4. Setup

Hold both the Left and Right arrow buttons for 2 seconds, and it

will enter the Setup Mode.

Sound Setting

To turn the sound on or off, press the left arrow

button to change the setting. Press the right

arrow button to go to the next item in the list.

Auto Off Setting

Set the time for automatic powering off of the unit. Press the Left

arrow button to change the time off setting. Press the Right arrow

button to go to the next item.

Delay Setting

To set the time interval for the photo slide show, press the Left

arrow button to change the time interval. Choose ‘0 sec’ for

manual mode, and it will turn off the slide show function. Press

the Right arrow button to go to the next item.

Clock Setting

Press the Left arrow button to go to the clock

setup screen.

Press the Right arrow button to select Hour,

Minute and am/pm. Press the Left arrow button

to change the setting.

Activities

Autres manuels pour KidiJamz Studio

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels V-tech Jouet

V-tech

V-tech Toot-Toot Animals ChickenCoop Manuel utilisateur

V-tech

V-tech Switch & Go Triceratops Bulldozer Instructions de montage

V-tech

V-tech Cuddle & Sing Cody Manuel utilisateur

V-tech

V-tech Innotab 3 Manuel utilisateur

V-tech

V-tech Yo Gabba Gabba Learning Laptop Manuel utilisateur

V-tech

V-tech Alphabet Picture Desk Manuel utilisateur

V-tech

V-tech Winnie the Pooh 2-in-1 Baby Activity Walker Manuel utilisateur

$V-tech Math Lab Mode d’emploi$

V-tech

V-tech Math Lab Mode d’emploi

V-tech

V-tech Toot-Toot Drivers Police Patrol Tower Instructions de montage

V-tech

V-tech Switch&Go Dinos Defender the Velociraptor Instructions de montage

V-tech

V-tech Pop & Spin Mower Manuel utilisateur

V-tech

V-tech Counting Time Measuring Tape Manuel utilisateur

V-tech

V-tech My 1st Football Friend Instructions de montage

V-tech

V-tech Swim n Shapes Manuel utilisateur

V-tech

V-tech Skate-Along Kitty Manuel utilisateur

V-tech

V-tech Go! Go! Smart Wheels Ultimate Corkscrew... Instructions de montage

V-tech

V-tech Explore & Learn Helicopter Manuel utilisateur

V-tech

V-tech Lightning McQueen Atlas Manuel utilisateur

V-tech

V-tech Baby Amaze Crawlin' Cutie Doll Manuel utilisateur

V-tech

V-tech Touch & Explore Activity Table 5408 Guide de configuration rapide

V-tech

V-tech Peppa Pig Let's Chat Learning Phone Instructions de montage

V-tech

V-tech V.Smile: Soccer Challenge Manuel utilisateur

V-tech

V-tech Touch & Imagine Block Manuel utilisateur

V-tech

V-tech Soothing Songs Lovey Manuel utilisateur

Manuels Jouet populaires d'autres marques

marklin

marklin 37321 Manuel utilisateur

Canon

Canon PAPER CRAFT Manuel utilisateur

GREAT PLANES

GREAT PLANES Pitts M-12S Manuel utilisateur

NOCH

NOCH 14261 Manuel utilisateur

Hausler

Hausler 450 SE V2 Manuel utilisateur

Dynaflite

Dynaflite Daydream Manuel utilisateur

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuel

Kenner

Kenner Batman 63651 Manuel utilisateur

LEGO

LEGO 8527 Manuel utilisateur

iKarus

iKarus ECO 8 Manuel utilisateur

Multiplex

Multiplex EasyStar II Mode d’emploi

Walkera

Walkera 38 Mode d’emploi

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuel utilisateur

MD MXION SWD Manuel utilisateur

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuel utilisateur

marklin

marklin 39671 Manuel utilisateur

Meccano

Meccano 15103 Manuel utilisateur

LEGO

LEGO TECHNIC 8735 Manuel utilisateur
