V-tech Kidi Star Music Magic Microphone Instructions de montage

91-003446-003 US

Parent’s Guide

INTRODUCTION

Thank you for purchasing the VTech®Kidi Star Music Magic

MicrophoneTM!This interactive microphone encourages your child to

sing, dance, perform and create! With the four built-in sing-along songs

and four built-in games and tools, there is plenty of singing and learning

fun! You can also plug in an external music player, such as an MP3

player or mobile device (not included), to listen to your own music! Use

Music Magic mode to reduce the main vocal track of a song, so you can

sing along to your favorite songs as the lead!

PRODUCT FEATURES

PRODUCT LAYOUT AND BUTTONS

Playback Button

OK Button

Record Button

Home Button

Selection Button Selection Button

Voice-

Changing

Effects Button

Music Magic

Button

Instant Sound

Effects Button

On/Off Button

Volume Control

Switch

On/Off Press this button to turn the unit ON and OFF.

Volume Control

Switch

Turn this switch to adjust the microphone

speaker's volume at any time.

NOTE: Kidi Star Music Magic MicrophoneTM

complies with the maximum volume output

standards set to protect your child's hearing.

Music Magic

Button

Music Magic mode works with the built-in songs

and the songs you choose on your own music

player. It reduces the main vocal track from

most songs. This allows you to perform like a

super star and sing along to the music as the

lead. Press the Music Magic button to toggle

between Music Magic mode and Normal mode.

Music Magic mode:

Reduce the main vocal track from songs*.

Normal mode:

Normal music playback, without reduced

vocals.

*NOTE: Music Magic mode may not work for

all songs. Its effectiveness varies depending

on the song. For the best results, studio

recorded songs in stereo rather than mono

are recommended. Unfortunately we cannot

guarantee Music Magic mode will work for

every song. We do not recommend using

Music Magic mode with mono recordings or live

concert performances, etc.

Record Press this button to start or stop recording.

NOTE: Kidi Star Music Magic MicrophoneTM

records up to a maximum of 2 minutes.

When recording, please do not remove the

batteries, otherwise the recording will be erased.

Playback Press this button to play or pause your recording.

Kidi Star Music Magic MicrophoneTM will

also exit the previous mode after this button is

pressed. To return to the previous mode, press

the Home button and select your desired mode

again.

Voice-

Changing

Effects

Press this button to switch between different

voice-changing effects when using the

microphone:

Squeaky Deep

Robot Echo

Normal

Instant Sound

Effects

Press this button to add applause and clapping

sound effects to your performance.

Home Press this button to enter the Home menu to

access different activities.

Selection

Buttons

Press these buttons to scroll through menus and

make selections.

OK Button Press this button to conrm your selection.

Audio-In Jack Use to plug in an MP3 player or mobile device

(not included) using the supplied 3.5mm jack

audio cable.

NOTE: Please ensure a rm connection on both

ends of the audio cable.

INCLUDED IN THIS PACKAGE

• One VTech®Kidi Star Music Magic MicrophoneTM

• One 3.5mm jack audio cable

• One parent’s guide

• Two AA batteries for demo purposes only

WARNING: All packing materials such as tape, plastic sheets,

packaging locks, removable tags, cable ties and

packaging screws are not part of this toy, and should

be discarded for your child’s safety.

NOTE: Please keep this parent's guide as it contains

important information.

ATTENTION :Pour la sécurité de votre enfant, débarrassez-vous

de tous les produits d’emballage tels que rubans

adhésifs, feuilles de plastique, attaches, étiquettes et

vis d’emballage. Ils ne font pas partie du jouet.

NOTE : Il est conseillé de conserver ce guide des parents car

il comporte des informations importantes.

This product is only to be connected to equipment of Class II (marked on

the marking plate with a symbol ).

GETTING STARTED

BATTERY INSTALLATION

1. Make sure the unit is turned OFF.

2. Locate the battery cover on the back of the unit.

3. Remove the battery cover and install 2 new AA (AM-3/LR6) batteries

as illustrated. (The use of new alkaline batteries is recommended for

maximum performance.)

4. Close the battery cover.

BATTERY NOTICE

• Use new alkaline batteries for maximum performance.

• Use only batteries of the same or equivalent type as recommended.

• Do not mix different types of batteries: alkaline, standard (carbon-

zinc) or rechargeable (Ni-Cd, Ni-MH), or new and used batteries.

• Do not use damaged batteries.

• Insert batteries with the correct polarity.

• Do not short-circuit the battery terminals.

• Remove exhausted batteries from the toy.

• Remove batteries during long periods of non-use.

• Do not dispose of batteries in re.

• Do not charge non-rechargeable batteries.

• Remove rechargeable batteries from the toy before charging (if

removable).

• Rechargeable batteries are only to be charged under adult supervision.

TO BEGIN USING KIDI STAR MUSIC

MAGIC MICROPHONETM

ACTIVATING NORMAL PLAY

Press the On/Off Button to turn ON the unit.

LOW BATTERY ICON

When the batteries are exhausted, the low battery icon will be

displayed and the unit will automatically shut off. Please replace the

batteries with a full set of new batteries before further use.

AUTOMATIC SHUT OFF

To preserve battery life, Kidi Star Music Magic MicrophoneTM will

automatically shut off if there is no operation for a short period of time in

Game mode. In Singing Fun and Free Play mode, the automatic shut off

time will occur after a longer amount of time. The automatic shut off time

can be adjusted for external music connection in Settings.

ACTIVITIES

Press the Home button to enter the home menu for different activities.

1. Free Play

Free Play mode allows for open-ended play with the

microphone. Use your imagination to create your own

concert, talk show, talent show, or to just play around and

have fun! It’s Show Time!

2. Singing Fun

Choose the Singing Fun activity to sing along with four

built-in songs. Press the selection buttons to choose a

song and press the OK Button to begin. When you are

ready, press the Music Magic Button to reduce the main

vocal track from the built-in songs and sing by yourself like

a super star!

NOTE: For the lyrics to the four built-in sing-along songs, please refer

to the Appendix.

3. Your Music

Plug in an external music player, such as an MP3 player or

mobile device (not included), via the provided 3.5mm jack

audio cable to listen to your own music! From here, you

can press the Music Magic Button to reduce the main

vocal track from the current song. Now you can sing along and be a

super star!

You can also set an auto-off timer in this mode. For details, please refer

to the Settings section of this guide.

The volume switch on the microphone cannot control the volume of

external devices. Please use the volume controls on your external music

player to increase or decrease volume.

Music Magic mode may not apply for all songs. For details, you may

refer to the Music Magic section under PRODUCT FEATURES.

NOTE: Please disconnect your external music player if it

is not in use. You can wind the 3.5mm jack audio cable

around the Kidi Star Music Magic MicrophoneTM and

hook it as illustrated.

4. GAMES & TOOLS

After entering the Games & Tools menu, press the selection buttons to

choose a game or tool, pressing the OK Button to conrm.

4.1 Music Catcher

In this game, try to catch the music note on the right

beat. When the music note is in the target area, push the

corresponding button to catch it. Try and catch them all!

4.2 Silly Beat, Silly Song

When there is a smiling face in the target area, press the

OK Button to add a silly sound effect to the song!

4.3 Beat Boxer

Beat Boxer is a tool that provides different musical beats

for your own beat box creation. You can create, sing and

beat box along to your preferred beat and record it! Play

it back to see how great your beat box creation was!

4.4 Tongue Twisters

Challenge yourself to master all of these tricky Tongue

Twisters! Press the selection buttons to select a twister

and then press the OK Button to conrm. Listen to the

instructions and repeat the Tongue Twister! Press the

OK Button when you’ve nished and select the next

Tongue Twister! Can you master them all?

NOTE: For all of the Tongue Twister sentences, please refer to the

APPENDIX.

5. Settings

Here you can make adjustments to the following settings:

• Light Brightness

• Auto-Off Timer for the External Music Connection

• Contrast

5.1 Light Brightness

Press the selection buttons to set the light brightness. Press the OK

Button to save your changes.

5.2 Auto-Off Timer for the External Music Connection

Here you can change the Auto-Off Timer for the External Music

Connection. This allows you to determine how long the microphone

will stay on without any input from the child when the device is plugged

into an MP3 player or mobile device. To do this, use the selection

buttons to choose your desired length of time and then press the OK

Button to save your changes.

5.3 Contrast

Press the selection buttons to set the contrast. Press the OK Button

to save your changes.

CARE & MAINTENANCE

1. Keep the unit clean by wiping it with a slightly damp cloth.

2. Keep the unit out of direct sunlight and away from any direct heat

sources.

3. Remove the batteries when the unit is not in use for an extended

period of time.

4. Do not drop the unit on a hard surface and do not expose the unit to

excess moisture.

TROUBLESHOOTING

Check this section if you experience difculty operating Kidi Star Music

Magic MicrophoneTM.

Problem Possible cause Solution

Kidi Star

Music Magic

MicrophoneTM

has stopped

working or

does not turn

Incorrect battery

polarities

Ensure that the batteries are

installed using the correct

polarity.

Depleted batteries

Replace the existing batteries

with a brand new set of

batteries.

Microphone

output cannot

be heard or

is not loud

enough

The microphone

volume is low

Turn up the volume on the

unit using the Volume Control

Switch.

Music Magic

mode is not

functioning

correctly

The MP3 player

or external

music player

is not properly

connected to Kidi

Star Music Magic

MicrophoneTM

Make sure that the external

music player is securely or

rmly connected to Kidi Star

Music Magic MicrophoneTM

at both ends of the provided

3.5mm jack audio cable.

Unsuitable song

source

The Music Magic feature

may not work for all songs.

Its effectiveness varies from

song to song. For best results,

studio recorded songs in

stereo rather than mono are

recommended, but we cannot

guarantee Music Magic will

work for every song. Music

Magic is not recommended for

use with mono songs or live

concert performances, etc.

Noise can be

heard when

connected to a

mobile device

to play music

Interference from

Wi-Fi or mobile

data

The Kidi Star Music Magic

MicrophoneTM is affected by

mobile device interference

when streaming music

through Wi-Fi or mobile data.

Please download the music to

an external music player for

higher quality playback.

If for some reason the program/activity stops working, please follow

these steps:

1. Turn the unit OFF.

2. Interrupt the power supply by removing the batteries.

3. Let the unit stand for a few minutes, then replace the batteries.

4. Turn the unit back ON. The unit will now be ready to play again.

5. If the unit still does not work, replace with an entire set of new batteries.

If the problem persists, please call our Consumer Services Department

at 1-800-521-2010 in the U.S. or 1-877-352-8697 in Canada, or by

going to our website at vtechkids.com and lling out our Contact Us

form located under the Customer Support link. A service representative

will be happy to help you.

Table des matières

Autres manuels V-tech Jouet

V-tech

V-tech See & Surprise Laptop Manuel utilisateur

V-tech

V-tech Toot-Toot Drivers Train Set Manuel utilisateur

V-tech

V-tech Learning Walker Manuel utilisateur

V-tech

V-tech Zombizooz Alligator Instructions de montage

V-tech

V-tech Zoo Jamz Tiger Rock Guitar Manuel utilisateur

V-tech

V-tech Kidi DJ MIX Instructions de montage

V-tech

V-tech ABC Building Block Manuel utilisateur

V-tech

V-tech Dora s TV Explorer Phone Manuel utilisateur

V-tech

V-tech 80-62000-004 - Winnie The Pooh Interactive... Manuel utilisateur

V-tech

V-tech V.Smile Baby: Learn & Discover Home Manuel utilisateur

V-tech

V-tech Turbo Force Racers Race Track Instructions de montage

V-tech

V-tech Switch & Go Dinos Chaser the Therizinosaurus Instructions de montage

V-tech

V-tech Super Hero Squad Learning Laptop Manuel utilisateur

V-tech

V-tech Toot-Toot Friends Magic Lights Castle Instructions de montage

V-tech

V-tech Kosy the Kissing Puppy Manuel utilisateur

V-tech

V-tech Safari Gym Manuel utilisateur

V-tech

V-tech Innotab Spy Adventure Scholastic Manuel utilisateur

V-tech

V-tech PAW Patrol Marshall's Read-to-Me Adventure Instructions de montage

V-tech

V-tech Happy Lights Bear Manuel utilisateur

V-tech

V-tech Touch & Chat Light-Up Phone Instructions de montage

V-tech

V-tech Nickelodeon PAW Patrol The Movie Learning... Instructions de montage

V-tech

V-tech Toot-Toot Drivers Fix and Fuel Garage Manuel utilisateur

V-tech

V-tech Twinkle & Learn Tambourine Manuel utilisateur

V-tech

V-tech Fire Command Rescue Center Manuel utilisateur

Manuels Jouet populaires d'autres marques

marklin

marklin 37321 Manuel utilisateur

Canon

Canon PAPER CRAFT Manuel utilisateur

GREAT PLANES

GREAT PLANES Pitts M-12S Manuel utilisateur

NOCH

NOCH 14261 Manuel utilisateur

Hausler

Hausler 450 SE V2 Manuel utilisateur

Dynaflite

Dynaflite Daydream Manuel utilisateur

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuel

Kenner

Kenner Batman 63651 Manuel utilisateur

LEGO

LEGO 8527 Manuel utilisateur

iKarus

iKarus ECO 8 Manuel utilisateur

Multiplex

Multiplex EasyStar II Mode d’emploi

Walkera

Walkera 38 Mode d’emploi

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuel utilisateur

MD MXION SWD Manuel utilisateur

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuel utilisateur

marklin

marklin 39671 Manuel utilisateur

Meccano

Meccano 15103 Manuel utilisateur

LEGO

LEGO TECHNIC 8735 Manuel utilisateur
