V-tech V 2651 Manuel utilisateur



Important Safety Instructions

When using your telephone equipment, basic safety precautions should always

be followed to reduce the risk of fire, electric shock and injury, including the

following:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid

cleaners or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this product near water (for example, near a bath tub, kitchen

sink, or swimming pool).

5. Do not place this product on an unstable cart, stand, or table. The product

may fall, causing serious damage to the product.

6. Slots and openings in the cabinet and the back or bottom are provided for

ventilation. To protect it from overheating, these openings must not be

blockedbyplacingtheproductonthebed,sofa,rug,orothersimilarsurface.

Thisproductshouldneverbeplacednearoroveraradiatororheatregister.

This product should not be placed in a built-in installation where proper

ventila-tion is not provided.

7. Thisproductshouldbeoperatedonlyfromthetypeofpowersourceindicated

onthemarkinglabel.Ifyouarenotsureofthetypeofpowersupplytoyour

home, consult your dealer or local power company.

8. Do not allow anything to rest on the power cord. Do not locate this product

where the cord will be abused by persons walking on it.

9. Never push objects of any kind into this product through cabinet slots as

theymaytouchdangerousvoltagepointsorshortoutpartsthatcouldresult

inariskoffireorelectricshock.Neverspillliquidofanykindontheproduct.

10. To reduce the risk of electric shock, do not disassemble this product, but

take it to an authorized service facility. Opening or removing cabinet parts

other than specified access doors may expose you to dangerous voltages

or other risks. Incorrect reassembling can cause electric shock when the

appliance is subsequently used.

11. Do not overload wall outlets and extension cords as this can result in the

risk of fire or electric shock.

12.Unplug this product from the wall outlet and refer servicing to a VTech

authorized service facility under the following conditions:

A. When the power supply cord or plug is damaged or frayed.

B. If liquid has been spilled into the product.

C. If the product has been exposed to rain or water.

D. If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the

operating instructions, because improper adjustment of other controls

mayresultindamageandwilloftenrequireextensiveworkbyaVTech

authorized technician to restore the product to normal operation.

E. If the product has been dropped and the cabinet has been damaged.

F. If the product exhibits a distinct change in performance.

13.Avoid using a telephone (other than a cordless type) during an electrical

storm. There may be a remote risk of electric shock from lighting.

14.Do not use the telephone to report a gas leak in the vicinity of the leak.

VTECH COMMUNICATIONS INC

SERVICE DEPT. at1-800-595-9511.InCanada,call VTechTelecommunications

Canada Ltd. at 1-800-267-7377.

SAVE THESE INSTRUCTIONS

The v 2651 is an advanced cordless telephone that operates in the 2.4GHz

frequency range. Your v 2651 is capable of supporting up to a maximum of 4

Handsets. Using additional Handsets, up to three people can be conferenced

on a call (2 Handsets and the Base Speakerphone), or two extensions can be

conferencedonacall,whiletwootherextensionscanbetalkinginternally,using

the Intercom feature.

This manual is designed to familiarize you with the v 2651 cordless telephone.

We strongly recommend you read the manual before using your phone.

Toorder additionalsystem Handsets(model#v2600), batterypacks,

or headsets, call VTech Communications Inc at 1-800-595-9511.

Introduction

IMPORTANT

Please record the Base ID#(BS ID) printed on the underside of the v 2651

Baseinthespacebelow. Pleasebecertaintoincludeall15digits/characters.

Base ID #

STOP!!

If you have questions about this product, or

if you're having difficulty with setup or

operation, do not return your phone to the

store. Call our Customer Support Center at

1-800-595-9511

In Canada, call

1-800-267-7377

Parts Check List

5Battery Pack

6.User'sManual

7. Wall Mounting Bracket

To purchase replacement battery packs, call VTechCommunications Inc at

1-800-595-9511.InCanada,callVTechTelecommunicationsCanadaLtd. at1-800-

267-7377.

1.Base Unit

2.Handset

3.AC Power Adapter

4.Telephone Cord

AC Power Adapter

Telephone Cord

Handset Base Unit

Wall mounting Bracket

Users Manual

Battery Pack

The Handset Layout

1. Antenna

2. Earpiece

3. Scroll Keys

4. Headset Jack (2.5mm)

5. On (Flash)

6. Dialing Keys (0-9, *, #)

7. Handsfree Speakerphone

8. LCD Display

9. Menu/Select

10. Off (Clear)

11. Battery Compartment

12. Intercom

13. Microphone

1. Intercom

2. Flash

3. Mute

4. Redial

5. Charging LED

6. Dialing Keys (0-9, *, #)

11. DC Connector

12. Telephone Jack

The Base Unit Layout

MO EL: 2651

VTECH TELECOMMUNICATIONS LT .

MANUFACTURE IN CHINA

COMPLIES WITH 47 CFR PART 68

REGISTRATION NO.: US: 6BXWI01B80-XXXXXX

RINGER EQUIVALENCE: 0.1B

USOC JACK: RJ11C/W

THIS EVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLOWING TWO CON ITIONS:

1) THIS EVICE MAY NOT CAUSE HARMFUL INTERFERENCE; AN

2) THIS EVICE MUST ACCEPT ANY INTERFERENCE RECEIVE ,

INCLU ING INTERFERENCE THAT MAY CAUSE UN ESIRE

OPERATION.

PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURE WHEN

USING THIS PHONE.

HAC FCC I : EW72230P2

VTECH TELECOMMUNICATIONS LT .

C 9V 500mA

CLASS 2 POWER SOURCE ONLY

COR LESS TELEPHONE

7. Speakphone Key

8. Charge Contacts

9. In Use

10.Volume

Setup

Plug the AC power adapter into an electrical outlet, and the

DC connector into the back of the base unit.

To AC outlet

To telephone

jack

To telephone

outlet AC adapter

VTECH TELECOMMUNICATIONS LT .

C 9V 500mA

CLASS 2 POWER SOURCE ONLY

COR LESS TELEPHONE

CAUTION:Use only the VTech power supply provided with your VTech unit.

IMPORTANT:

FORMAXIMUMPERFORMANCE OF YOUR

CORDLESS TELEPHONE SYSTEM:

1. Chooseacentral locationforyourBaseUnit.

2. Install your Base Unit and Extension

Handsets away from electronic equipment,

such as personal computers, television sets

and microwave ovens.

3. In locations where there are multiple

cordlesstelephones,separateBaseunits

as much as possible.

4. Install your telephone equipment away

from heat sources and sunlight.

5. Avoid excessive moisture,dust orextreme cold.

Connecting Power to Base Unit

Getting Started

Follow the steps below:

1.Remove the battery cover by

pressingontheindentandsliding

downward.

2.Align the two holes in the plug

with the socket pins. Insert the

plugintosocket.Placethebattery

pack into the compartment with

the wires coming out of one of

the bottom corners of the pack.

3.Replace the battery cover by

sliding it upwards.

4.If the new battery pack is not

already charged, place the

Handset in the Base unit, or a

remotechargingstand,andallow

it to charge for 12 hours. After

initial charge, a maintenance

charge of 8 hours should be

sufficient.

Setup

TheoriginalHandsetthatisshippedwithyourv2651systemwillbeautomatically

registered to the Base. This Handset is HANDSET 1.

As you register additional Handsets to the system, they will be assigned

extensionnumbersinthefollowingorder:HANDSET2,HANDSET3,andfinally

HANDSET 4.

After a Handset battery pack is installed, the Handset will automatically begin

SEARCHINGFOR BASE (ifpreviouslyregistered),oritwillpromptyoutoENTER

BASE ID to register the new Handset.

Installation of Battery Pack in Handset

Getting Started

Charging Of Handset Battery Pack

The Handset of your v 2651 cordless telephone is powered by a

rechargeable battery pack. It charges automatically whenever the Handset is

intheBaseUnit.Maximumtalktimeonafullchargeis7.5hours.Maximumstandby

time is over 5 days.

Youshouldchargethebatterypackfor12hourswhenyoufirstreceiveyour

phone. You'll know the battery pack needs charging when:

• The low battery message is displayed :

• The handset seems completely dead,

the LCD is completely clear and does

not activate when you press the keys.

IMPORTANT:

1.Do not dispose of a battery pack in a fire, the cell may explode.

2.Donotopenormutilatethebatterypack. Toxicsubstancesmaybereleased,

causing harm to eyes or skin.

3.Exercise care in handling battery packs in order to prevent an accidental

shortofthechargecontacts,potentiallycausingthebatterypacktooverheat.

4.Donotdispose ofthisbatterypackintohouseholdgarbage.Forinformation

concerning proper battery recycling or disposal, please contact your local

Recycling Center or Disposal Service.

Getting Started

Connecting to phone line

Plug one end of the telephone line cord into the jack on the back of the Base

unit. Plug the other end of this cord into the wall telephone jack.

Checking for dial tone

After the battery ischarged pressON ontheHandset. ThePhoneicon will

appear on the handset display, and you will hear dial tone. If not, see In Case

of Difficulty.



To telephone

jack

To telephone outlet

AC adapter

VTECH TELECOMMUNICATIONS LT .

C 9V 500mA

CLASS 2 POWER SOURCE ONLY

COR LESS TELEPHONE

The Wall Mount bracket is designed for use on standard Wall Mount plates only.

1.Line up the tabs on the wall mount adapter with the holes on the bottom

of the base unit. Snap the wall mount bracket firmly in place.

2.Plug the AC adapter into an electrical outlet, and the DC connector to the

bottom of the base unit. If the handset battery pack has not been charged

previously, place the handset in the base unit cradle, and allow it to charge

for 12 hours.

3.Connect the telephone line cord to the jack on the bottom of the base unit,

and the other end to the telephone jack.

4.Mountthebaseunitonthewall. Positionthebaseunitsothemountingstuds

will fit into the holes on the wall mount bracket. Slide base unit down on

the mounting studs until it locks into place.

Walling Mounting

Getting Started

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels V-tech Téléphone sans fil

V-tech

V-tech CS6328-2 Manuel utilisateur

V-tech

V-tech VT-2931 Manuel utilisateur

V-tech

V-tech t2350 Manuel utilisateur

V-tech

V-tech MI6821 - Cordless Telephone With Caller Id Guide de l'utilisateur

V-tech

V-tech VT 1932 Manuel utilisateur

V-tech

V-tech DS6401 Manuel utilisateur

V-tech

V-tech DS6472-6 Manuel utilisateur

V-tech

V-tech IP 811 Manuel utilisateur

V-tech

V-tech CS6629-4 Manuel utilisateur

V-tech

V-tech LS5145 Manuel utilisateur

V-tech

V-tech VT9011 Manuel utilisateur

V-tech

V-tech vt 1030 - V-tech Microphone Unidirectional Manuel utilisateur

V-tech

V-tech CS6719 Manuel utilisateur

V-tech

V-tech Cordless Telephone Manuel utilisateur

V-tech

V-tech vt1733 Manuel utilisateur

V-tech

V-tech LS6205 - Cordless Extension Handset Manuel utilisateur

V-tech

V-tech Cordless Phone with Digital Answering System and Caller... Manuel utilisateur

V-tech

V-tech VTV2656/2V2600 - V-tech. 2.4 GHz Phone Manuel utilisateur

V-tech

V-tech CS6909 Manuel utilisateur

V-tech

V-tech DS4121-3 Manuel utilisateur

V-tech

V-tech CS6419 Manuel utilisateur

V-tech

V-tech i 5857 Manuel utilisateur

V-tech

V-tech DS6072 Manuel utilisateur

V-tech

V-tech IP 5825 Manuel utilisateur

Manuels Téléphone sans fil populaires d'autres marques

3Com

3Com NBX Manuel utilisateur

Panasonic

Panasonic KX-TGK210HK Manuel utilisateur

Panasonic

Panasonic KX-TCA181EX Manuel utilisateur

BT FREESTYLE 3200 Manuel utilisateur

AT&T

AT&T CL84102 Manuel utilisateur

BREZZICNI

BREZZICNI CL-3622 Manuel utilisateur

Panasonic

Panasonic KX-TG1831NZ Manuel utilisateur

Panasonic

Panasonic KX-TG7301E Manuel utilisateur

Furuno

Furuno FM-4721 Manuel utilisateur

Sanyo

Sanyo CLT-J70 Manuel utilisateur

Amplicomms

Amplicomms BigTel 201 Manuel utilisateur

GE 26992 Manuel utilisateur

AT&T

AT&T E1812B Manuel utilisateur

Sanyo

Sanyo CLT-670 Manuel utilisateur

GE 15432970 Manuel utilisateur

Curtis

Curtis TC595 Manuel utilisateur

Gigaset

Gigaset Gigaset 3000 Micro Manuel utilisateur

Poly

Poly VVX D230 Guide de configuration

V-tech v 2651 Manuel utilisateur

Manuels Téléphone sans fil populaires d'autres marques
