V-tech CS5111-3 Manuel utilisateur

Congratulations

on purchasing your new VTech product.

Before using this telephone, please read the

Important safety instructions

on page 34 of this manual.

This manual has all the feature operations and troubleshooting necessary to install and operate

your new VTech telephone. Please review this manual thoroughly to ensure proper installation

and operation of this innovative and feature rich VTech product. For support, shopping, and

everything new at VTech, visit our website at www.vtechphones.com.

In Canada, please visit www.vtechcanada.com.

The ENERGY STAR®program (www.energystar.gov) recognizes and encourages

the use of products that save energy and help protect our environment. We are

proud to mark this product with the ENERGY STAR®label indicating it meets the

latest energy efficiency guidelines.

Compatible with

Hearing Aid T-Coil

TIA-1083

Telephones identified with this logo have reduced noise and interference when

used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083

Compliant Logo is a trademark of the Telecommunications Industry Association.

Used under license.

www.vtechphones.com

Table of contents

Getting started . . . . . . . . . . . . . . . 1

Parts checklist . . . . . . . . . . . . . . . . 1

Telephone base and charger installation . . .2

Battery installation and charging . . . . . . . 3

Mounting bracket installation . . . . . . . . . 4

Handset layout . . . . . . . . . . . . . . . . 6

Telephone base layout . . . . . . . . . . . . 7

Telephone settings . . . . . . . . . . . . . 8

Date and time . . . . . . . . . . . . . . . . . 8

Ringer. . . . . . . . . . . . . . . . . . . . . 9

Ringer volume . . . . . . . . . . . . . . . . 9

Dial mode . . . . . . . . . . . . . . . . . . 10

Home area code . . . . . . . . . . . . . . 10

Language . . . . . . . . . . . . . . . . . . 11

Clear voicemail . . . . . . . . . . . . . . . 11

Telephone operation . . . . . . . . . . . 12

Make calls . . . . . . . . . . . . . . . . . 12

Answer calls . . . . . . . . . . . . . . . . 12

End calls . . . . . . . . . . . . . . . . . . 12

Volume . . . . . . . . . . . . . . . . . . . 12

Channel . . . . . . . . . . . . . . . . . . . 12

Call waiting . . . . . . . . . . . . . . . . . 13

Temporary tone dialing . . . . . . . . . . . 13

Redial . . . . . . . . . . . . . . . . . . . . 14

Find handset . . . . . . . . . . . . . . . . 14

Transfer an external call . . . . . . . . . . 15

Directory . . . . . . . . . . . . . . . . . . 16

Store a directory entry . . . . . . . . . . . 16

Character chart . . . . . . . . . . . . . . . 17

Review the directory . . . . . . . . . . . . 17

Edit a directory entry . . . . . . . . . . . . 18

Delete a directory entry . . . . . . . . . . . 19

Copy a directory entry into speed dial . . . 20

Dial a number from the directory . . . . . . 20

Speed dial . . . . . . . . . . . . . . . . . 21

Store a speed dial entry . . . . . . . . . . 21

Edit a speed dial entry . . . . . . . . . . . 22

Delete a speed dial entry . . . . . . . . . . 23

www.vtechphones.com iii

Table of contents

Dial a speed dial number . . . . . . . . . . 23

Reassign speed dial locations . . . . . . . 24

About caller ID . . . . . . . . . . . . . . . 25

Call log . . . . . . . . . . . . . . . . . . . 26

Review the call log . . . . . . . . . . . . . 27

Make call log entries ready to dial . . . . . 27

Dial a call log number. . . . . . . . . . . . 28

Save a call log entry to the directory . . . . 29

Delete from the call log . . . . . . . . . . . 30

Call log display screen messages . . . . . 31

Appendix. . . . . . . . . . . . . . . . . . 32

Handset display screen messages . . . . . 32

Battery . . . . . . . . . . . . . . . . . . . 33

Important safety instructions . . . . . . . . 34

Troubleshooting. . . . . . . . . . . . . . . 35

Operating range . . . . . . . . . . . . . . 44

Maintenance . . . . . . . . . . . . . . . . 44

About cordless telephones . . . . . . . . . 45

Warranty . . . . . . . . . . . . . . . . . . 45

FCC, ACTA and IC regulations . . . . . . . 47

The RBRC®seal . . . . . . . . . . . . . . 48

Technical specications . . . . . . . . . . 49

Index . . . . . . . . . . . . . . . . . . . . 50

www.vtechphones.com 1

Getting started Basic operation

Getting started

To purchase

replacement

batteries or power

adapters, visit our

website at www.

vtechphones.

com or call

1 (800) 595-9511.

In Canada, go to

www.vtechcanada.

com or call 1 (800)

267-7377.

•

8. User’s manual

1. Handsets

(2 for CS5111-2,

3 for CS5111-3)

7. Telephone base with

mounting bracket

3. Telephone base

power adapter

2. Telephone line cord

6. Batteries

(2 for CS5111-2,

3 for CS5111-3)

5. Battery compartment

covers

(2 for CS5111-2,

3 for CS5111-3)

Parts checklist

Your telephone contains the following items. Save your sales receipt and original

packaging in case your telephone needs warranty service.

4. Chargers and charger adapters

(1 for CS5111-2,

2 for CS5111-3)

www.vtechphones.com

Getting started

Use only the

power adapters

supplied with this

product. To order

a replacement,

visit our website at

www.vtechphones.

com or call

1 (800) 595-9511.

In Canada, go to

www.vtechcanada.

com or call 1 (800)

267-7377.

The power

adapters are

intended to be

correctly oriented

in a vertical

or oor mount

position. The

prongs are not

designed to hold

the plug in place

if it is plugged into

a ceiling or an

under-the-table/

cabinet outlet.

•

Telephone base

Telephone line cord

Electrical outlet

(not controlled by

a wall switch)

Telephone base

power adapter

Telephone

wall jack

DSL lter (not included)

required if you have

DSL high-speed

Internet service

Telephone base and charger installation

Install the telephone base and charger as shown below. Make sure that the

electrical outlet is not controlled by a wall switch. If you subscribe to high-speed

Internet service (Digital Subscriber Line - DSL) through your telephone lines,

you must install a DSL lter between the telephone base and the telephone

wall jack. The lter will prevent noise and caller ID problems caused by DSL

interference. Please contact your DSL service provider for more information

about DSL lters.

Charger

adapter

Charger

www.vtechphones.com 3

Getting started Basic operation

Getting started

If the handset will

not be used for

a long period of

time, remove the

battery to prevent

possible leakage.

To purchase a

replacement

battery, visit our

website at www.

vtechphones.

com or call

1 (800) 595-9511.

In Canada, go to

www.vtechcanada.

com or call 1 (800)

267-7377.

•

Battery installation and charging

Install the battery as shown below. The battery may have enough charge for

short calls. For best performance, charge the battery for at least 16 hours before

use. When the battery power is low, LOW BATTERY will be displayed and will

ash on the handset screen. When fully charged, the handset battery provides

approximately ve hours of talk time or six days of standby time.

Insert the plug of the battery as indicated. Make sure it is plugged securely

and matches the color-coded label inside the battery compartment.

Place the battery with the label THIS SIDE UP facing up and the wires inside

the battery compartment.

Align the battery compartment cover at against the battery compartment,

then slide it upwards until it clicks into place.

Charge the handset by placing it in the telephone base or charger. The handset

charge light will be on when charging.

1234

www.vtechphones.com

Getting started

Mounting bracket installation

Your telephone base comes with the mounting

bracket installed, ready for desktop use. You may

also mount your telephone onto a standard telephone

wall plate.

Wall mounting bracket installation:

To prepare the telephone base for wall mounting,

you will need to remove the bracket if it is currently

attached for desktop use. Press on the tabs located

on the legs of the bracket to loosen, then lift the

bracket up and away from the telephone base.

First, insert the lower portion tabs of the mounting

bracket into the lower grooves in the telephone

base, then snap the upper portion tabs of the

mounting bracket into place.

Mount the telephone base on the wall by positioning

it so the mounting studs will t into the holes on the

telephone base and mounting bracket. Slide the

telephone base down on the mounting studs until

it locks into place.

To remove the bracket, press both upper portion

tabs rmly inward and pull the bracket downward

until it releases from the grooves.

AC7.5V

Mounting bracket in wall

mount orientation

upper grooves

upper portion tabs

lower

portion

tabs

Mounting bracket

lower groove

www.vtechphones.com 5

Getting started Basic operation

Getting started

Mounting bracket installation (continued)

Desktop/tabletop bracket installation:

Your telephone comes ready for table or desktop use. If you have repositioned

the bracket for wall mounting and now want to return to desktop use, follow these

steps:

Insert the lower portion tabs of the mounting bracket into the upper grooves

of the telephone base.

Snap the upper portion tabs of the bracket into place.

To remove the bracket, press both upper portion tabs rmly inward and pull

the bracket upward until it is released from the grooves.

AC 7.5V

www.vtechphones.com

Handset layout

Getting started

/VOL-/CID

• When the phone is not in use, press to review

the call log.

• Press and hold to adjust the ringer volume when

in idle mode.

• During a call, press to decrease the listening

volume. A double beep will sound at the lowest

setting.

• Press to scroll down while in programming

mode or reviewing the redial list.

PROG

• Press to enter programming mode while

the phone is not in use.

/FLASH

• Press to make or answer a call.

• During a call, press to receive an incoming

call when you receive a call waiting alert.

CHAN/REMOVE

• Switch to a clearer channel while on a call.

• Press and hold to delete all records in the

call log when the phone is not in use.

When reviewing the call log or redial list,

press to delete the desired record.

•

/VOL+/

• Press to display the directory when the phone

is not in use.

• Press and hold to adjust the ringer volume

when the telephone is not in use.

• During a call, press to increase the listening

volume. A double beep will sound when the

highest setting is reached.

Press to scroll up while in programming mode

or reviewing the redial list.

•

SELECT/X-FER

• Press to store a programming option or a

directory entry.

• During a call, press to transfer a call to

another handset.

OFF

• During a call, press to hang up.

• While the handset is ringing, press to silence

the ringer.

• Press and hold for two seconds when the

telephone is not in use to erase the MISSED

CALLS display.

• During programming, press to exit without

making changes.

REDIAL/PAUSE

• Press repeatedly to review the redial list .

• While dialing or entering numbers into the

directory, press to insert a dialing pause.

CHARGE light

• On when the handset is charging in the

telephone base or charger.

TONE*

• Press to switch to tone dialing temporarily

when using the pulse service (page 13).

•

Press repeatedly to display other dialing options

when reviewing the call log (page 27).

•

Press to use the CLR VOICEMAIL feature

from the main menu.

www.vtechphones.com 7

Getting started Basic operation

Getting started

Telephone base layout

FIND HANDSET

Press to page all handsets.•

IN USE light

Flashes when there is an incoming call.

On when the handset is in use.

•

VOICEMAIL light

Flashes when you have new voicemail from your

telephone company.

•

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels V-tech Téléphone sans fil

V-tech

V-tech DS6511 Manuel utilisateur

V-tech

V-tech t2429 - 2.4 GHz Analog Cordless Phone Manuel utilisateur

V-tech

V-tech LS6191 Manuel utilisateur

V-tech

V-tech VT 1721 Manuel utilisateur

V-tech

V-tech sbc20-2432 Manuel utilisateur

V-tech

V-tech I5808 - Cordless Extension Handset Manuel utilisateur

V-tech

V-tech DS6401 Manuel utilisateur

V-tech

V-tech CORDLESS TELEPHONE VT 9152 Manuel utilisateur

V-tech

V-tech Cordless Telephone Manuel utilisateur

V-tech

V-tech VTECH LS6426-3 Manuel utilisateur

V-tech

V-tech CS6859 Manuel utilisateur

V-tech

V-tech 6043 - DECT 6.0 Cordless Phone Manuel utilisateur

V-tech

V-tech 20-2432 Manuel utilisateur

V-tech

V-tech FS6220-2 Manuel utilisateur

V-tech

V-tech Cordless Telephone Manuel utilisateur

V-tech

V-tech CS6629-3 Manuel utilisateur

V-tech

V-tech CS5119-17 Manuel utilisateur

V-tech

V-tech CS6629 Manuel utilisateur

V-tech

V-tech CS6228-5 Manuel utilisateur

V-tech

V-tech CS5121-3 Manuel utilisateur

V-tech

V-tech VTECH LS6426-4 Manuel d'installation et d'exploitation

V-tech

V-tech CareLine SN6166 Manuel utilisateur

V-tech

V-tech qw2652 Mode d’emploi

V-tech

V-tech VT 1932 Manuel utilisateur

Manuels Téléphone sans fil populaires d'autres marques

3Com

3Com NBX Manuel utilisateur

Panasonic

Panasonic KX-TGK210HK Manuel utilisateur

Panasonic

Panasonic KX-TCA181EX Manuel utilisateur

BT FREESTYLE 3200 Manuel utilisateur

AT&T

AT&T CL84102 Manuel utilisateur

BREZZICNI

BREZZICNI CL-3622 Manuel utilisateur

Panasonic

Panasonic KX-TG1831NZ Manuel utilisateur

Panasonic

Panasonic KX-TG7301E Manuel utilisateur

Furuno

Furuno FM-4721 Manuel utilisateur

Sanyo

Sanyo CLT-J70 Manuel utilisateur

Amplicomms

Amplicomms BigTel 201 Manuel utilisateur

GE 26992 Manuel utilisateur

AT&T

AT&T E1812B Manuel utilisateur

Sanyo

Sanyo CLT-670 Manuel utilisateur

GE 15432970 Manuel utilisateur

Curtis

Curtis TC595 Manuel utilisateur

Gigaset

Gigaset Gigaset 3000 Micro Manuel utilisateur

Poly

Poly VVX D230 Guide de configuration
