Concord 4 Installation Manual

P/N 466-2182 • REV J • NOV12

Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies

This document may not be copied in whole or in part or otherwise reproduced without prior

written consent from UTC Fire & Security, Inc., except where specifically permitted under US

and international copyright law.

Disclaimer

The information in this document is subject to change without notice. UTC Fire & Security

assumes no responsibility for inaccuracies or omissions and specifically disclaims any

liabilities, losses, or risks, personal or otherwise, incurred as a consequence, directly or

indirectly, of the use or application of any of the contents of this document. For the latest

documentation, contact your local supplier or visit us online at www.utcfireandsecurity.com.

This publication may contain examples of screen captures and reports used in daily

operations. Examples may include fictitious names of individuals and companies. Any

similarity to names and addresses of actual businesses or persons is entirely coincidental.

Trademarks and

patents

Other trade names used in this document may be trademarks or registered trademarks of the

manufacturers or vendors of the respective products.

Intended use

Use this product only for the purpose it was designed for; refer to the data sheet and user

documentation for details. For the latest product information, contact your local supplier or

visit us online at www.utcfireandsecurity.com.

Contact information

www.utcfireandsecurity.com. or www.interlogix.com

Technical support

www.interlogix.com/customer-support.

Concord 4 Installation Manual i

Content

Important information iii

Chapter 1 Introduction 1

Planning the installation 2

SuperBus 2000 bus devices 3

Chapter 2 Installation 5

Installation overview 6

Mounting the panel 10

Intrusion detection devices 15

Smoke detectors 15

Speakers and sirens 18

SuperBus 2000 touchpads 22

SuperBus 2000 modules 22

Phones 28

Power 30

Chapter 3 Programming 33

Overview 34

Quick programming mode 36

Tier 1 programming menus 37

Tier 2 programming menus 40

Security menu 45

Phones menu 50

Phone options menu 54

Timers menu 57

Light control menu 59

Touchpad options menu 60

Reporting menu 61

Siren options menu 66

Sensors menu 67

Audio verification menu 71

Accessory modules menu 73

Onboard options menu 78

Macro keys menu 81

User programming mode 82

Downloader programming 93

Chapter 4 Testing and troubleshooting 95

Testing the system 96

ii Concord4 Installation Manual

Troubleshooting 106

Appendix A System planning sheets 117

Customer information 118

Wireless devices 118

Hardware devices 119

Zone and sensor assignments 121

System settings index and record 124

Appendix B Reference tables 129

Sensor group characteristics 130

Sensor text 134

System event triggers 136

Sensor group event triggers 137

Sensor number event triggers 138

System feature event triggers 141

Response characteristics 143

Response numbers 143

Specifications 145

Concord 4 Installation Manual iii

Importantinformation

Intended use

Use this product only for the purpose it was designed for; refer to the data sheet

and user documentation for details. For the latest product information, contact

your local supplier or visit us online at www.utcfireandsecurity.com.

Changes or modifications not expressly approved by UTC Fire & Security can

void the user’s authority to operate the equipment.

About this manual

This manual provides information for planning, installing, programming, and

testing this security system. Planning sheets are included for you to record

hardware layout and software programming settings.

Use this manual for the following panels:

600-1021-95R

Concord 4 RF

600-1022-95R

Concord Express V4

600-1040

Concord Commercial V4

600-1042

Concord Hybrid

When necessary, this manual refers you to other documentation with compatible

peripherals.

The Concord 4 User Manual (P/N 466-2183) contains user worksheets that you

should fill out during the installation and programming ofthe system. For

multiple-partition systems, we suggest a user manual for each partition.

Read these instructions and all related documentation entirely before installing or

operating this product.

Note: A qualified service person, complying with all applicable codes, should

perform all required hardware installation.

Concord 4 Installation Manual 1

Chapter 1

Introduction

Summary

This chapter provides information to help you plan your Concord 4 panel and

system installation.

Content

Planning the installation 2

Standard panel 2

SuperBus 2000 bus devices 3

Chapter 1: Introduction

2 Concord4 Installation Manual

Planning the installation

This section describes system capabilities to help you get familiar with the

system. Appendix A “System planning sheets” on page 117 provides planning

sheets that let you record the hardware and programming configuration of the

system. Fill in all necessary information ahead of time to help prepare for system

installation.

Standard panel

Table 1 below shows the standard panel capabilities.

Table 1: Panel capabilities

Capabilities

Concord Express v4

Concord 4/Concord Commercial

Zones

Partitions

Bus devices

User codes

230

Table 2 describes the basic panel (out-of-box) hardware capabilities for all

panels.

Table 2: Basic panel hardware capabilities

Power

Input for an AC step-down, plug-in style transformer.

Auxiliary power output

Output that supplies 9 to 14 VDC with up to 1 amp for bus devices

and hardwired detectors, such as smoke and motion detectors.

Bus A and B

Input and output that provides communication between bus devices

and the panel.

Siren driver

Output that can drive an 8-ohm load and provides intrusion and fire

alarm sounds for partition 1 (15 watts maximum).

Two onboard outputs

Can be used to activate other signaling devices based on system

events.

Out 1 is a 9 to 14 VDC source output, limited to 1.0 amp max.

Out 2 is an open-collector output, rated up to 14 VDC, 300 mA max

Microphone input

Input used for 2-way audio when used in conjunction with the

Interrogator 200 audio verification module.

Eight supervised hardwired

zones

Inputs for various hardwired detectors. Zone 8 can be set up in

programming to accept two-wire smoke detectors. It sources 9 to 14

VDC, 90mA max.

Chapter 1: Introduction

Concord 4 Installation Manual 3

Built-in RF receiver

Allows use of up to 96 (Concord 4) or 32 (Concord Express v4)

319.5 MHz. crystal and/or SAW learn mode wireless sensors and

touchpads.

Phone line connection

Allows panel to communicate with central monitoring station and/or

pagers.

SuperBus2000 bus devices

The following components can be used with the Concord 4 panel:

Table 3: SuperBus devices

Touchpads

Use the following touchpads for installer/user programming

and system operation.

•SuperBus 2000 2x16 LCD touchpad

•SuperBus 2000 2x20 LCD touchpad

•SuperBus 2000 2x20 VFD touchpad

•SuperBus 2000 ATP 1000 touchpad

•SuperBus 2000 ATP 2100 touchpad

•SuperBus 2000 ATP 2600 touchpad

Use the following touchpads for installer quick programming,

system operation and user programming:

•SuperBus 2000 fixed display touchpad

•SuperBus 2000 FTP 1000 touchpad

SuperBus 2000 RF transceiver

Use the transceiver toreceive signals from sensors and

touchpad that may be on the fringe of panel reception. The

transceiver is compatible with all 319.5 MHz crystal and SAW

learn mode wireless sensors and touchpads.

Power line carrier transformer

Allows the use of X10 powerhouse lamp modules for light

control and light activation during alarms.

SuperBus 2000 voice only

module

Provides an output for a speaker that sounds system status

and alarm voice messages.

SuperBus 2000 phone

interface/voice module

Allows system access and control using touchtone

telephones, onsite or offsite. The module includes an output

for a speaker that sounds system status and alarm voice

messages

Chapter 1: Introduction

4 Concord4 Installation Manual

SnapCards

The following SnapCards expand the system as described:

8Z input Snapcard: Provides eight additional hardwired zone

inputs, of which two are dedicated for using two-wire smoke

detectors.

4 output SnapCard: Provides four form C relay outputs that

can be set up to activate other signaling devices, based on

system events, schedules, or direct control.

4Z input/output combo SnapCard: Provides three hardwired

zone inputs, one two-wire smoke detector loop, and two

outputs that can be set up to activate other signaling devices,

based on system events, schedules, or direct control.

SuperBus 2000 8Z input

module (HIM)

Provides eight additional hardwire zone inputs.

SuperBus 2000 four-relay

output module (HOM)

Provides four form C relay outputs that can be set up to

activate other signaling devices, based on system events.

Interrogator 200 audio

verification module

Allows central station operators to listen in and talk to

occupants on the premises to verify the emergency when an

alarm report is received.

SuperBus 2000 energy saver

module (ESM)

Provides a money-saving and convenient way to monitor and

control temperatures. The ESM uses low- and high-

temperature limits to save energy by overriding the existing

HVAC thermostat.

SuperBus 2000 automation

module

Provides a connection to a compatible home automation

device.

SuperBus 2000 wireless

cellular gateway

Allows users to control and monitor the status of their system

from the alarm.com internet website.

SuperBus 2000 2-amp power

supply

Provides an additional 12 VDC, 2 amps for powering system

devices and is supervised via the panel data bus.
