Usha OFR 3209 Manuel utilisateur

Oil Filled RadiatOR

Model No.: OFR 3209

instRuctiOn Manual

Dear Customer,

Congratulations!

You are now the proud owner of Usha Oil Filled Radiator (Model No.: OFR

3209)

Innovatively designed, using only the highest quality material and

components, your Usha Oil Filled Radiator (Model No.: OFR 3209) is

designed for years of trouble free performance.

Please read this Instruction Manual carefully before using and keep it

cautiously after reading for future reference.

Best Wishes

1. Read the instructions carefully before use and save them for future

reference.

2. Always disconnect the heater from the main supply when not in use and

when cleaning.

3. Do not leave the heater“ON”unattended.

4. Never cover the heater as this may lead to risk of fire.

5. Keep the heater a distance of at least 90cm from any combustible

material, such as furniture, curtains, bedding clothes or papers.

6. Do not attempt to open any part of the oil fins.

7. Keep the heater clean. Do rot allow objects to enter the ventilation, as

this may cause electric shock, fire or damage the heater.

8. Close supervision is required when any appliance is used near or by

children.

9. Never allow the cord to touch wet or hot surfaces, become twisted or be

within the reach of children.

10. Do not use outdoors.

11. Do not place on or near a hot gas or electric burner.

12. Never use the appliance with a damaged cord or plug or after the

appliance has malfunctioned or been damaged in any way.

13. Never attempt to open any part or dismantle the controls. Responsibility

for failure cannot be accepted if these instructions have been ignored.

14. Do not use the appliance for anything other than its intended use.

15. This appliance is intended for household use only.

16. Regulations concerning the disposal of the oil when scraping the

appliance have to be followed.

17. Any repairs that need to be done to the heater must be referred to an

Usha authorized service centre.

18. The appliance is not intended for use by young children or infirm persons

without supervision.

19. Young children should be supervised to ensure that they do not play

with the appliance.

20. If the supply cord is damaged, it must be replaced by the Usha authorised

service centre.

iMpORtant pRecautiOns

21. The heater must not be located immediately below a socket-outlet.

22. Do not use this heater in the immediate surroundings of a bath, a shower

or a swimming pool.

23. This heater is filled with a precise quantity of special oil. Repairs requiring

opening of the oil container are only to be made by the Usha authorised

service centre, if there is an oil leakage. Regulations concerning the

disposal of the oil when scrapping the appliance has to be followed.

24. This appliance is not intended for use by persons (including children) with

reduced physical,sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

25. Children should be supervised to ensure that they do not play with the

appliance.

asseMBlY

Remove the heater and all the accessories from the carton.

1. Turn the heater upside down.

2. Position the wheel base assembles between the end fins.

3. Attach them to the heater using the U-bolls and wing nuts supplied.

4. Tighten the wing nuts.

5. Turn the heater the right way up.

paRts descRiptiOn

1. Power setting switch

2. Thermostat control

3. Handle

4. Oil filled fins

5. Castors

6. Cord storage

OpeRatinG YOuR Oil Filled RadiatOR

Place the heater on the floor at least 90cm away from the wall and any other

objects such as furniture, Curtains or plants.

(Make sure the power supply used corresponds to the one on the rating

label)

With the thermostat control switch in the“O” position and the power setting

switches in the “OFF” Position; plug the heater into the main power supply.

OpeRatiOn

1. Room temperature can be adjusted using the thermostat. Simply turn

the thermostat knob clockwise, to increase the heat, and anti-clockwise

to decrease the temperature, until you reach the desired temperature.

2. Switch the heater to one of the following power settings.

09 fins: Push switch one (I) for 800W

Push switch two (II) for 1200W

Push switch one & two (I&II) for 2000W

3. The power switch lights up when activated.

4. Turning the thermostat control clockwise will increase the “set”

temperature.

5. Turning the thermostat anti-clockwise will decrease the “set” temperature.

6. Do not cover the heater at any time during operation. There is a risk of

fire if the heater is covered.

7. Once you have finished using your heater.,turn the power switches off,

and the thermostat control switch to the “0”positions.,and unplug from

the mains supply.

cleaninG YOuR Oil Filled RadiatOR

1. Always disconnect the heater from the mains supply before cleaning.

2. Clean the outside of the heater by wiping with a damp cloth and buff with

a dry cloth.

3. DO NOT use waxes or polishes as these may react with the heater and

cause discoloration.

stORinG YOuR Oil Filled RadiatOR

1. Save the box for off season storage.

2. Clean the heater following the cleaning instructions above.

3. Remove the wheel base assemblies.

4. Place the heater, and wheel assemblies in the original box, and store in

a cool and dry place.

5. If you choose to store your heater fully assembled be sure to cover it to

protect it from dust.

This Oil Filled Radiator is warranted for one year against all manufacturing

defects from the date of sale. In the event of any complaint, please contact your

nearest Company Service Centre or call at our Toll Free no: 1800-1033-111.

This Warranty is valid only when…

1. The Oil Filled Radiator has not been opened or tempered with, by any

unauthorized person.

2. The warranty card or cash memo duly signed by the authorized dealer

are presented with the complaint.

3. The Oil Filled Radiator has been installed, used and maintained in

accordance with the instructional manual.

This Warranty does not apply for…

1. Damages due to chipping, peeling, plating and denting.

2. Breakage or damage to components made out of Bakelite, Urea, ABS,

SAN and such plastic, materials, rubber parts and cord.

3. Normal wear and tear of parts.

4. Damage resulting from accidents, mishandling or negligence on part of

the customer.

Liability for consequential loss or damage is neither accepted nor implied.

S.NO: ______________________________________________________

CASH MEMO _______________________DATE: ___________________

DEALER'S NAME AND ADDRESS: _______________________________

___________________________________________________________

OWNER'S NAME & ADDRESS: __________________________________

___________________________________________________________

WaRRantY caRd
