Uponor MLC Riser system Manuel utilisateur

UPONOR RISER SYSTEM MLC

Uponor Riser System MLC 63 Ð 110 mm

MOUNTING-INSTRUCTIONS

click click press

Uponor Riser sistem MLC 63 - 110 mm

UPUTE ZA MONTAŽU

Umetci Osnovni elementi Umetci MLC cijevi

RS 2 / RS 3

Uponor Riser sistem

Osnovni elementi RS 2

Osnovni elementi RS 3

40, 50, 63, 75 2Ò, 2Ò 1Ò2Ò, 2Ò 25, 32

90, 110 3Ò 3Ò

Umetci RS 2

Umetci RS 3

UPONOR RISER SYSTEM MLC

1. Rezanje · Cutting

UPONOR RISER SYSTEM MLC

min.

4 mm

da5

2. Zakošenje · Bevelling

UPONOR RISER SYSTEM MLC

UP 75UP 75 EL

3. Umetnuti cijev u pres adapter i stisnuti ·

Insert pipe into press adapter and press

UPONOR RISER SYSTEM MLC

4. Pres adapter umetnuti u osnovni element i zabraviti sa spojnim

klinom · Insert press adapter into base part and lock with lock-pin

Spojni klin ·

Lock-pin

UPONOR RISER SYSTEM MLC

Type Art.-No. Z [mm] L [mm] St./pce.

[g]

RS 2 1029144 18 51 356

RS 3 1029145 18 51 561

Type Art.-No. Z [mm] L [mm] St./pce.

[g]

RS 2 1029142 31 51 738

RS 3 1029143 48 68 1566

Uponor Riser sistem - osnovni elementi

Uponor RS spojnica/Coupling Uponor RS T-komad/Tee

Mesing presvučen

kositrom. Osnovni

element, uključivo

2 spojna klina.

Made of tin-plated

brass. As RS base

part, including 2 lock

pins.

Made of tin-plated

brass. As RS base

part, including 3 lock

pins.

Mesing presvučen

kositrom. Osnovni

element, uključivo

3 spojna klina.

UPONOR RISER SYSTEM MLC

Type Art.-No. Z [mm] L [mm] St./pce.

[g]

RS 2 1029138 31 51 544

RS 3 1029139 48 68 1174

Type Art.-No. Z [mm] L [mm] St./pce.

[g]

RS 2 1029140 31 51 682

RS 3 1029141 48 68 1509

Uponor Riser sistem - osnovni elementi

Uponor RS koljeno/Elbow 90° Uponor RS koljeno/Elbow 45°

Mesing presvučen

kositrom. Osnovni

element, uključivo

2 spojna klina.

Made of tin-plated

brass. As RS base

part, including 2 lock

pins.

Made of tin-plated

brass. As RS base

part, including 2 lock

pins.

Mesing presvučen

kositrom. Osnovni

element, uključivo

2 spojna klina.

UPONOR RISER SYSTEM MLC

Type Art.-No. Z Z1 L L1 St./pce. [g]

RS 3 / RS 2 1029146 27 20 47 27 691

Uponor Riser sistem - osnovni elementi

Uponor RS spojnica-redukcija/ Coupling reducer

Mesing presvučen

kositrom. Osnovni

element, uključivo

1 spojni klin.

Made of tin-plated

brass as reducer from

RS 3 to RS 2 including

1 lock pin.
