Universal Remote Control MXW-920I Manuel utilisateur
Order Number
: GETEC-C1-12-048
FCC Part 15 subpart C
Test Report Number
: GETEC-E3-12-022
Page 1 / 1
EUT Type: RF REMOTE CONTROLLER
FCC ID.: OZ5URCMXW920I
APPENDIX H
: USER’S MANUAL
MXW-920i
Splash Proof Controller
Owner's Manual
MXW-920i Owner’s Manual ©2011 URC, Inc.
The information in this manual is copyright protected. No part of this man-
ual may be copied or reproduced in any form without prior written consent
from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPER-
ATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN
THIS MANUAL.
The information in this manual may be subject to change without prior
notice.
Complete Control is a registered trademark of Universal Remote Control, Inc.
Entertainment Made Simple is a trademark of Universal Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks of
their respective companies or organizations.
Universal Remote Control, Inc.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TABLE OFCONTENTS
Congratulations! 1
Using the MXW-920i 2
Displaying the Settings Screen 3
Selecting from the Setup Screen 3
Setting the LCD 4
Light Settings 6
Sound Volume 6
System Settings 7
Version Information Displays 7
Selecting from the Edit Screen 8
Adjusting the Text 8
Learn commands 9
Erasing learned data 9
Performing a Factory Default 9
Battery Installation 10
USA Limited Warranty Statement 11
Federal Communication Commission
Interference Statement 13
Regulatory Information to the user 14
Declaration of Conformity 15
Page 1
MXW-920i OWNER’SMANUAL
Congratulations!
Thank you for purchasing the Complete Control MXW-920i splash
proof wand-style controller. This unit can directly control every
IR device in your home. You can also control devices located in
different rooms by integrating an MRF base station. Controlling your
home is simple with the MXW-920i remote.
Splash Proof IR/RF wand-style controller
The Splash Proof MXW-920i wand-style controller can be used
outside as well as indoors. It’s the perfect controller for kitchen, bath
and poolside use. It is not intended for underwater use or exposure
to sugar-based substances (e.g., soda or lemonade). Make sure the
MXW-920i is dry when changing batteries. IP Code 54, JIS Class 4.
Ideally suited for poolside control
Entertain your guests by controlling your sound system or more
while poolside. Use the MXW-920i by the pool without the worry
of damaging your remote.
Controls up to 40 devices
The MXW-920i has the capacity to control up to 40 devices
throughout your home. Turn off devices that are not in use when
walking by a room. It’s like having a master key for your electronic
devices.
Ultra-reliable narrow band RF - compatible with URC
433 MHz RF Base Stations
The MXW-920i can communicate directly to RF base stations, such
as the MRF-350i and the MRF-260i. It also natively communicates
with URC Lighting via 433.92 MHz RF. This gives the MXW-920i the
ability to control your system without being in direct line-of-sight.
Fast setup of complex systems via Complete Control PC editor
To fully automate an audio/video system, and integrate two-way
automation of servers etc., the programmer must have detailed
knowledge of each component, LAN configuration, WiFi
optimization and how the system is connected and operated. Only
a trained and certified professional audio/video installer can install
an MXW-920i remote control in a timely and efficient manner.
MXW-920i OWNER’SMANUAL
Using the MXW-920i
The MXW-920i displays the Main or Device page at the top of the
screen. Below the title, the LCD displays the device or command names.
All the hard buttons of the MXW-920i are changed to control the functions
of the selected device.
The Title displays
the Main or Device
pages you can
control.
Press either of the
Page buttons to see
any other available
choices.
The LCD button
labels describes
the functions
available for the
current activity or
device.
The Channel and
Previous Channel
buttons adjust
channels for devices
with channel functions
(i.e. cable boxes)
The 5-way cursor
buttons enable you
to navigate on
screen guides and
menus with ease.
The Number keypad
enters numbers for
the devices you’ve
selected. When
watching Cable TV,
use the number
keypad to enter
channel numbers.
When listening to a
CD, the number
keypad enters track
numbers.
The Volume and
Mute buttons always
control the sound
regardless of what
screen is displayed.
The Transport buttons
(Play, Stop, Skip-,
Skip+, FF, REW and
Pause) operate when
the selected device
requires them. When
watching Cable
TV, use the number
keypad to enter
channel numbers.
When listening to a
CD, the number
keypad enters track
numbers.
The Light button
backlights all the
buttons and activates
the LCD screen
Page 2
MXW-920i OWNER’SMANUAL
Displaying the Setup Screen
You can adjust the settings of the MXW-920i
controller whenever you like. Simply press and
hold both the Main and the Enter buttons at the
same time for three seconds. The screen displays
the Setup and the Edit screens. Press the Page +
and - buttons to toggle between both screens.
If you do not press any button on the Setup screen
within 30 seconds, the MXW-920i times out and
automatically returns to normal operation. You can
return to normal operation before that by pressing
the Main button.
Selecting from the Setup Screen
Simply touch the button for the setting you’d like to adjust:
At the same time, press and
hold both the Main and the
Enter buttons. When the Setup
screen appears, release the two
buttons.
Page 3
LCD - Adjustments for the LCD screen
(brightness, contrast, light)
Light - Adjustments for backlight of the
buttons.
Sound - The volume of the beeps.
System - Set the threshold for the low
battery warning
Version - Displays factory info.
Page 4
Setting the LCD
With these settings, you can set the MXW-920i to constantly display
the LCD or have it turn off when not in use. Additionally, you can control
the contrast of the screen and the color of the backlighting.
MXW-920i OWNER’SMANUAL
To activate the LCD On/Off setting, press
this button. See below.
To activate the Contrast setting, press this
button. See the next page.
To activate the Brightness setting, press
this button. See the next page.
To exit without saving any changes you
have made, press Exit.
LCD Timer Setting:
If you set the LCD to OFF, the timer settings
appear. The LCD turns off after the set
amount of time set by adjusting the Left
and Right arrow keys.
The timer can be set to turn off the LCD
between 10 seconds and 20 minutes.
The Timer Interval is displayed here.
To save any changes you have made,
press Save.
To exit without saving any changes you
have made, press Exit.
To change the timer interval, press the
Left or Right arrow keys.
Page 5
MXW-920i OWNER’SMANUAL
Setting LCD Contrast
You can adjust the contrast of the LCD screen using the Left and
Right arrow keys once the LCD Contrast screen has been selected
(shown on the previous page).
Setting LCD Brightness
You can adjust the brightness of the LCD screen using the Left and
Right arrow keys once the LCD Brightness screen has been selected
(shown on the previous page).
The current contrast is displayed here
via a bar graph.
To save any changes you have made,
press Save.
To exit without saving any changes you
have made, press Exit.
Adjust the Contrast setting with the Left
and Right keys as shown in the previous
pages.
The current brightness is displayed here
as a bar graph.
To save any changes you have made,
press Save.
To exit without saving any changes you
have made, press Exit.
Adjust the LCD brightness with the Left
and Right keys as shown in the previous
pages.
MXW-920i OWNER’SMANUAL
Page 6
Light Settings
You can adjust the backlighting of the remote in two additional ways:
1. You can turn on/off the LCD and the hard button backlighting.
2. You can select the length of time the lighting stays on after the
last button press from a range of values between 10 seconds
and 90 seconds.
Sound Volume
Your MXW-920i beeps whenever a button is pressed. However, you
can adjust the volume of the beep to one of four levels as shown here.
Change whether the backlighting is on or
off by pressing this button.
If you want the backlighting always off,
set it to OFF.
If you would like the backlighting on,
select ON.
The current timer setting is displayed
here in seconds.
Adjust the backlighting timer setting with
the Left and Right keys as shown in the
previous pages.
The current Beep volume is displayed
here as a “bar.”
Adjust the volume of the beep by
tapping the Left and Right (use capitals)
arrow keys as shown in the previous
pages.
