URC2068BC2

REMOTE CONTROL USER’SGUIDE

Guía del usuario

www.urcsupport.com

Remove battery cover.

Retire la tapa del compartimiento de pilas.

Insert 2 AA batteries. Match the + and – marks.

Coloque 2 pilas AA. Haga coincidir las marcas "+" y "-".

Replace battery cover.

Vuelva a colocar la tapa del compartimiento de pilas.

Getting Started

Primeros pasos

Tip/Consejo:

3The LED will blink 5 times with

each key-press when batteries

need replacement.

El LED parpadeará 5 veces con

cada presión de tecla cuando

sea necesario reemplazar las

pilas.

Make sure TV is ON before

starting remote control

setup.

Asegúrese de que la TV

esté prendida antes de

comenzar la conguración

del control remoto.

Note/Nota:

1 2 3

456

789

GUIDE

INFO

EXIT

PAG E

MUTE

TV CABLE

POWER

LAST

Setup Method A:

Configuración del Método A:

Popular Brands

Marcas famosas

WWW.URCSUPPORT.COM © Copyright Universal Electronics 2012

DIGIT

DÍGITO

TVs

Insignia / Dynex

LG / Zenith

Mitsubishi

Panasonic

Philips / Magnavox

Samsung

Sharp

Sony

Toshiba

Vizio

Press and hold SETUP

until LED blinks twice.

Mantenga presionada la

tecla SETUP (Congurar)

hasta que el LED

parpadee dos veces.

1Press the TV POWER key,

LED remains ON.

Presione la tecla TV

POWER (Encendido del

Televisor).

2Press and hold down the

DIGIT key for your TV

brand.

Mantenga presionada la

tecla del digito que

corresponde a la marca

de su TV.

2 PARPADEOS = CORRECTA

1 PARPADEO LARGO = INCORRECTA

Let go of the key when

your TV turns o. Setup is

complete.

Suelte la tecla cuando su

TV se apague. La congu-

ración está completa.

Tip/Consejo:

If your brand does not appear on popular TV brand chart, try either

Method B or Method C to setup the remote to control your TV.

Si la marca que utiliza no aparece en el cuadro de marcas, intente

ya sea con la Opción B o la Opción C para congurar el control

remoto de su TV.

1 2 3

456

Turns TV ON / OFF

Displays main cable MENU

Displays program GUIDE

Controls and MUTEs TV VOLUME Used in the program guide

for PAGE navigation

Turns cable box ON / OFF

Enciende/apaga la caja de cable

Muestra información sobre el

programa actualmente seleccionado Sale del menú actual y vuelve

al programa actual

Vuelve al último canal que estaba mirando

Enciende/apaga la TV

Muestra el menu principal de cable

Muestra la guía de programación

Controla y silencia el volumen del televisor

Se utiliza en la guía de programación

para navegar

Displays INFO for currently

selected program EXITs current menu and

returns to current program

Returns to LAST channel you were watching

Mantenga presionado 3 segundos

para ingresar a la conguración

HOLD for 3 seconds to enter SETUP

Functional Key Chart

Cuadro de teclas de funciones

1 2 3

456

7 8 9

GUIDE

INFO

EXIT

PAG E

MUTE

TV CABLE

POWER

LAST

MUG2068S-GP-03

COFETEL certicate number:

FCC NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and if not used in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interfer ence will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, the user is encouraged

or try to correct the interference by one or more of the following measures:

La operación de este equipo está sujeta a las siguientes dos condiciones:

(1) es posible que este equipo o dispositivo no cause interferencia perjudicial y

(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar

su operación no deseada.

•Reorient or relocate the receiving antenna.

•Increase or decrease the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected

•Consult the dealer or an experienced remote control/ TV technician for help.

•It is strongly recommended that the TV be plugged into a seperate wall outlet.

This equipment has been veried to comply with the limits for a Class B computing device, pursuant to

FCC Rules. The user is cautioned that changes and modications made to the equipment without the

approval of manufacturer could void the user's authority to operate this equipment.

TROUBLESHOOTING

RESOLUCIÓN DE PROBLEMAS

Problem:

Solution:

Problem:

Solution:

Problem:

Solution:

LED does not blink when a key is pressed.

Replace batteries.

TV does not respond when TV POWER or VOLUME keys are

pressed.

Program remote control for your TV brand using instructions

in Setup Method A, B, or C.

Tried all codes for my TV brand and none work.

Try CODE SEARCH (Setup Method B) method or go to

www.urcsupport.com for additional support and for CODE

FINDER search tool.

Problema:

Solución:

Problema:

Solución:

Problema:

Solución:

El LED no parpadea al pulsar una tecla.

Reemplace las pilas.

El televisor no responde al presionar las teclas POWER (Encendido) o

VOLUME (Volúmen).

Programe el control remoto para su marca deTV utilizando las instruc-

ciones en Conguración Método A, B o C.

Probé con todos los códigos que corresponden a mi marca de

aparato y ninguno funciona.

Pruebe con el método de BÚSQUEDA DE CÓDIGO (Conguración

Método B) o visite www.urcsupport.com para recibir ayuda adicional

y para la herramienta de búsqueda LOCALIZADOR DE CÓDIGOS.

GUIDE

INFO

EXIT

Make sure TV is ON

before starting remote

control setup.

Asegúrese de que la TV

esté prendida antes de

comenzar la congura-

ción del control remoto.

Note/Nota:

Setup Method B:

Configuración del Método B:

Code Search

Búsqueda de código

Press and hold SETUP until

LED blinks twice.

Mantenga presionada la

tecla SETUP (Congurar)

hasta que el LED parpadee

dos veces.

Press and hold down the

OK/SELECT key.

Mantenga presionada la

tecla OK/SELECT

(Aceptar/Seleccionar).

Let go of the OK/SELECT key

when the TV turns o.

Suelte la tecla OK/SELECT

(Aceptar/Seleccionar) cuando

el dispositivo se apague o se

encienda.

SELECT

1 2 3

789

1 2 3

456

789

GUIDE

INFO

EXIT

PAGE

MUTE

TV CABLE

POWER

LAST

GUIDE

INFO

EXIT

Press the TV POWER key to

test TV control. If the TV

turns o, setup is complete.

Presione el botón de

encendido para probar

el control para TV. Si la TV se

apaga, la conguración está

completa.

If TV does not turn o,

repeat this process using

the next code for your

TV brand.

Si el TV no se apaga, repita

este proceso utilizando el

siguiente código para su

marca de TV.

Press and hold SETUP until

LED blinks twice.

Mantenga presionada la

tecla SETUP (Congurar)

hasta que el LED parpadee

dos veces.

Enter the 1st TV code for

your brand from the code

list to the right. LED

blinks twice.

Ingrese el 1er código de

TV para su marca de la

lista de códigos.

TV code

Write the working TV code here for future use.

Escriba aquí el código de TV que funciona, para uso futuro.

Código de TV

Tip/Consejo:

To nd the exact code for your TV, use our CODE FINDER feature at WWW.URCSUPPORT.COM

Para encontrar el código exacto para su TV, utilice nuestra función de LOCALIZADOR DE

CÓDIGOS en WWW.URCSUPPORT.COM

2 3 4

Make sure TV is ON before starting remote control setup.

Asegúrese de que el televisor esté en la posición ON de encendido antes de

comenzar la conguración del control remoto.

Note/Nota:

Setup Method C:

Configuración del Método C:

Direct Code Entry

Entrada Directa de Código

789

1 2 3

456

1 2 3

456

789

GUIDE

INFO

EXIT

PAGE

MUTE

TV CABLE

POWER

LAST

GUIDE

INFO

EXIT

Set volume control for the TV:

Ajustar el control de volumen de la TV:

Set volume control for the STB:

Ajustar el control de volumen para el STB:

789

Press and hold SETUP until LED

blinks twice.

Mantenga presiondada la tecla

SETUP (Congurar) hasta que el

LED parpadee dos veces.

1Press and hold SETUP until LED

blinks twice.

Mantenga presiondada la tecla

SETUP (Congurar) hasta que

el LED parpadee dos veces.

1Press MUTE. The LED will

blink 4 times.

Presione MUTE. El LED

parpadeará 4 veces.

1 2 3

INFO EXIT

PAG E

MUTE

LAST

Press VOL +. The LED will

blink twice.

Presione VOL +. El LED

parpadeará dos veces.

1 2 3

INFO EXIT

PAG E

MUTE

LAST

WWW.URCSUPPORT.COM © Copyright Universal Electronics 2013

Codes: TV

Códigos: TVs

Accurian 1803

Action 0873

1675, 1207, 1676, 1688,

1689, 1692, 1935, 2232

America Action 0180

0180

1365, 1590, 2014, 2087,

2402, 2621

Aomni 1623

Apex Digital 0890, 1217, 2397

1531, 1738

Audinac 0180

Audiovox 1564, 0180, 0802, 0846,

0875, 1766, 1803, 1937,

1951, 2121, 2513, 3065

Aventura 0171

1937

Baysonic 0180

1032, 1315

0876

Blue Sky 2153

Bradford 0180

Broksonic 1935

Byd:sign 1309

Candle 0186

Carver 0170

1205

Citizen 0186, 1935

Clarion 0180

1538, 1634, 2017, 2306,

2314, 2315, 2326, 2338,

2340, 2344, 2345, 2348,

3202

Commercial Solutions 1447

Contec 0180

Continental 2357

Coradir 2844

0180

Crown 0180

1200, 2352, 2397, 2855,

2859

Curtis Mathes 0145, 1661

0180

Daewoo 1661, 0661

1264, 1080

1369

Denon 0145

Denstar 0628

Digital Lifestyles 1765, 1822

Disney 1665, 1892

Durabrand 0180, 0178, 0171, 1665

Dynex 1463, 1785, 2049

Electrograph 1755, 1623

Electrohome 1670

Elektra 1661

Element 1687, 1886, 2183

Emerson 1864, 0180, 0178, 0171,

1661, 1394, 1665, 1886,

1963

Emprex 1422, 1765

Encross 0876, 1474

Envision 0813, 1365, 2014, 2087

0171, 1963

Fujitsu 0809, 0186, 0683

0180, 0171, 1963

Futuretech 0180

Gateway 1755, 1756

1447, 0178

1864, 0171, 1665, 1886,

1963

Go Video 0886, 1823, 1831

GoldStar 0178

2693

Gradiente 0170

Grundig 0683

Grunpy 0180

1753, 2293, 2494, 2690,

3204

Hallmark 0178

Hanns.G 1783

Hannspree 1348, 1745, 1783

Harvard 0180

0865

Hewlett Packard 1494, 1088

Hikato 0628

Himitsu 0180, 0628

Hisense 1314, 1660, 2098

Hitachi 1643, 0145, 0797, 2215,

2433, 2679, 2879

Hitech 1814

HP 1494, 1088

Hyundai 0849, 1219, 1294, 1814

I-Inc 1746

iLo 1463, 1286, 1394, 1603,

1665, 1684, 1990

Initial 1603, 1990

Insignia 1423, 1564, 0171, 1204,

1517, 1660, 1710, 1785,

1892, 1963, 2049, 2417

iRIS 2189

IRT 1661, 0628

IX 0877

JCM 2189, 2256

Jensen 1299

JVC 1601

KDS 1498, 1687

KEC 0180

Kioto 0706, 0628

Konka 0628, 1831

Kost 1483

Kreisen 0876, 1474

KTV 0180

Lasonic 3198

LG 1423, 1447, 0178, 0856,

1530

LiteOn 1088

LodgingStar 3147

LXI 0156, 0178

MAG 1498, 1687

Magnavox 1454, 1866, 1755, 0171,

0706, 0186, 0802, 1198,

1365, 1525, 1867, 1963,

1990, 2655

Marantz 1454, 0704, 1398

Maxent 1755, 1211, 1757

Megatron 0178, 0145

Memorex 0150, 0178, 0877, 1665,

1670, 1785, 1892, 2739

MGA 0150, 0178

Mintek 1603, 1990

Miray 3309

Mitsubishi 1250, 0150, 0178, 1797

Multitech 0180

NAD 0156, 0178

Naxa 2104, 2735

NEC 0170, 0704, 0876, 1398,

1797, 2026

NetTV 1755, 2753

NEX 1814

Nexus Electronics 2183

Nikko 0178

Niko 1581

Nimbro 2104

Norcent 0824, 1365, 1590, 1591,

1745

Norwood Micro 1286, 1303

NuVision 1657, 2158

Olevia 1610, 1144, 1240

Onwa 0180

Optoma 1348

Orion 1463

Panasonic 1480

PARK 2104

PDI 1474

Penney 0156, 0178

Philco 0145, 0171, 1661, 1394,

1665, 1963

Philips 1454, 1866, 0171, 0899,

1394, 1483, 1867

Pioneer 1457, 1398

Planar 1496

Polaroid 0865, 1286, 1314, 1328,

1341, 1498, 1538, 1687,

1766, 1767, 2063, 2121

Portland 1661

Prima 1753, 1785

Proscan 1447, 2147, 2183, 2256

Proton 0178

Protron 1320

Proview 1498, 1687

Punktal 2687

Pyle 1200, 2196

RadioShack 0180, 0178

RCA 1447, 1661, 0899,

1781, 2434, 2746, 2932

Realistic 0180, 0178

Recco 0706

RevolutionHD 1623

Runco 1398

Sampo 1755

Samsung 0178, 0766, 0814,

1060, 2051

Sansui 0171, 1463, 1409,

1670, 1892, 1935

Sanyo 1142

Sceptre 0878, 1217, 1360,

1599, 2337

Scotch 0178

Scott 0180, 0178, 1711

Sears 0156, 0178, 0171

Semivox 0180

Semp 0156, 1743

Sharp 0818, 2402

Sherwood 1399

Simpson 0186

Skyworth 1799

Solarism 1220

Sole 1377, 1483, 1530, 1623

Sony 0810, 1685

Soundesign 0180, 0178, 0186

Sova 1320

Soyo 1520, 1746, 1826,

1828, 1830, 1831

Spectroniq 1498, 1687

Squareview 0171

SSS 0180

Starlite 0180

SunBriteTV 1610, 1420, 1435, 2337

Superscan 0864

Supersonic 1753, 2104, 2784,

3154, 3204

SVA 0865, 0871, 1963

Sylvania 1864, 0171, 1314,

1394, 1665, 1886, 1963

Symphonic 0180, 0171, 1394

Syntax 1610, 1144, 1240

Tatung 1286, 1756, 2496

TCL 2434

Teknika 0180, 0150, 0186

TMK 0178

Tophouse 0180

Toshiba 1524, 0156, 1343,

1369, 1743, 1935

TruTech 1665, 1723

US Logic 1286, 1303

Vidikron 1398

Vidtech 0178

Viewsonic 1755, 1564, 0797,

0864, 0885, 1330,

1365, 1578, 1627,

1742, 2014, 2049,

2087, 2277

Viore 1207, 1684, 2104,

2352, 3094, 3118

Visart 1336

Vito 1320

Vizio 1758, 0864, 0885,

1756, 2707

Wards 0156, 0180, 0178, 0186

Waycon 0156

Westinghouse 0885, 0890, 1217,

1282, 2195, 2293, 2499

White Westinghouse 1661

Wyse 1365

Yamaha 0797

Zenith 1423, 0178, 0145,

1661, 1365

MUG2068S-GP-03

Pulse Pairing Options

RF PAIRING

This remote control is capable of

controlling a set-top box(STB) that is

hidden from sight when it has been paired

with an RF STB or an RF Adapter.

Tip: The STB or RF Adapter that you are

using must be compatible with this remote

control and the proper pairing method must

be used. For the latest list of compatible RF

devices, go to www.urcsupport.com/rf

RF Pairing to Set-Top Box

NOTE: Certain set-top boxes (such as

EVOLUTION branded boxes) may require the

user to put the box into RF PAIRING mode

before RF pairing can occur. To do so, locate

REMOTE CONTROL in the on-screen MENU

and select REMOTE CONTROL PAIRING

before following the steps shown below.

1. Press and hold the SETUP key on the

remote until the LED blinks twice.

2. Press the MENU key on the remote and

the remote will begin blinking as it

attempts to pair.

3. If a PIN number appears on your

TV screen, enter that number using the

remote numeric keys.

4. LED on the remote will blink twice to

verify success.

RF Pairing to an RF Adapter

To perform RF pairing with an RF adapter, please

refer to the instructions provided with the adapter

or go to www.urcsupport.com/rf and locate the

support page for the RF adapter for more information.

Autres manuels pour URC2068BC2

Table des matières

Autres manuels Universal Electronics Télécommande

Universal Electronics

Universal Electronics C4000 Manuel utilisateur

Universal Electronics

Universal Electronics COGECO ATLAS DVR 5-DEVICE Manuel utilisateur

Universal Electronics

Universal Electronics ATLAS OCAP 5 Manuel utilisateur

Universal Electronics

Universal Electronics Nebula Catalyst 34 Manuel utilisateur

Universal Electronics

Universal Electronics Potenza ST Manuel utilisateur

Universal Electronics

Universal Electronics Potenza ST Mode d'emploi

Universal Electronics

Universal Electronics ATLAS OCAP 5 Manuel utilisateur

Universal Electronics

Universal Electronics ATLAS Manuel utilisateur

Universal Electronics

Universal Electronics Potenza ST Manuel utilisateur

Universal Electronics

Universal Electronics URC-2054 Manuel utilisateur

Universal Electronics

Universal Electronics Nevo C3 Manuel utilisateur

Universal Electronics

Universal Electronics Potenza ST Manuel utilisateur

Universal Electronics

Universal Electronics Potenza ST URC66950BA1 Manuel utilisateur

Universal Electronics

Universal Electronics NEVO PORTAL Manuel utilisateur

Universal Electronics

Universal Electronics Contour Manuel utilisateur

Universal Electronics

Universal Electronics CERVINO Manuel utilisateur

Universal Electronics

Universal Electronics URC1090 Manuel utilisateur

Universal Electronics

Universal Electronics ATLAS XL Manuel utilisateur

Universal Electronics

Universal Electronics Atlas CABLE 4 Manuel utilisateur

Universal Electronics

Universal Electronics Polaris Manuel utilisateur

Universal Electronics

Universal Electronics MediaRemote Manuel utilisateur

Universal Electronics

Universal Electronics ATLAS DVR 5, PVR 5 Manuel utilisateur

Universal Electronics

Universal Electronics Millenium 4 Manuel utilisateur

Universal Electronics

Universal Electronics Millennium 4 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
