Unitron UTV 2 Manuel utilisateur

uTV 2 guide

2 3

(b)(c)

(f) (g)

(d) (e)

(a)

The Unitron uTV 2 connects your A2DP Headset

wirelessly to your TV or other audio devices.

uTV 2 description

hearing

aid

headset

up to 30 meters (100 ft)

uTV 2 cable

The uTV 2 is connected to your TV (or any other audio

source) and wirelessly sends audio signals from your

TV to your headset within a range of up to 30 meters

(100 ft).

Legend

Buttons

(a) ON/OFF button

(b) TV signal volume (up)

Inputs

(d) Power input (mini-USB)

(e) Audio input (3.5 mm jack)

(f) Charging slot

(g) Status light

uTV 2

(d)

(h)

(i)

(e)

Installation

Step 1: Connecting the uTV 2

To connect the power supply (h):

Place the uTV 2 next to your TV. Connect the mini-USB

plug (d) of the power suppply to the power input (Power)

of the uTV 2. Plug the power supply into the wall socket.

uTV 2

Use the RCA/Cinch cable (i) to connect the uTV 2 to

the TV:

Connect the stereo (e) plug to the audio input

(Audio IN) of the uTV 2. Connect the red and white

plugs (i) to the matching red and white output sockets

on your TV.

(k) (e)

You can also connect your uTV 2 to the headset socket

of your TV, using the audio cable:

Connect the stereo plug (e) to the audio input of the

uTV 2 (Audio IN).

Plug the other end into the headset output socket of

your TV.

When connecting the uTV 2 to the headset socket

of your TV, you are able to adjust the volume via your

TV remote control.

Some TVs will switch off their loudspeakers when

plugging the jack into the headset socket - the TV

will not be audible for other people. In this case use

the Cinch/RCA or SCART output socket as described

above. For further information on volume adjustment,

refer to step 5. The uTV 2 can also be connected to

any other audio source such as an MP3 player, PC or

home sound system using the stereo plug cable (k).

fig. 2

(a) (g)

Step 2: Switching on

1. Switch on the uTV 2 by a short press of the ON/

OFF button (a) as shown in fig. 2. The status light

(g) will illuminate green iniatially and may later switch

to blue.

Step 3: Pairing Headset and uTV 2

Before starting to use the uTV 2 and headset, they

need to be paired. The pairing procedure controls

which Bluetooth® devices are permitted to commu-

nicate with each other.

Pairing needs to be completed only once for

each device you wish to use with your headset.

● Initiate the pairing process on your headset as

stated in its manual.

● If the uTV 2 status light (g) is not rapidly blinking

blue already, press the ON/OFF button (a) for5

seconds until the Bluetooth indicator (g) is rapidly

blinking blue as shown in ﬁg 2.

● Wait until the Bluetooth indicator lightd (g) turns

solid blue. This can take up to 2 minutes but

typically is done within a few seconds.

Step 4: Listening to your TV

You will hear the sound of your TV directly in your

headset.

If you cannot hear the sound of your TV through

uTV 2, repeat steps 1 to 4.

The uTV 2 supports Bluetooth operation up to a

range of 30 m (100 ft). Line-of-sight between your

headset and the uTV 2 is not required. However,

interference in the environment by walls or furniture

may reduce the operating range.

uTV 2

1110

Step 5: Adjusting the volume of the TV signal

First, set the volume of the TV speakers at the level

to suit other viewers.

● If the uTV 2 is connected to your TV with the

RCA/Cinch cable (i) or the SCART adaptor (k),

adjust the volume via the uTV 2 volume control

(b) and (c) until the sound is comfortable.

● If your uTV 2 is connected to the headphone socket

of your TV, you may also use your TV remote control

to adjust volume via the TV directly. Refer to the TV

user guide for more details on setting the TV volume.

If your TV is connected to a satellite receiver or a

set-top box, make sure the volumes of these

additional devices are set to a medium level for

best audio quality results.

If the headset moves out of range of the uTV 2,

the wireless audio transmission will be terminated.

If the headset is then moved back into range of

the uTV 2, it will automatically resume streaming

to your headset.

It may take up to 10 seconds until the streaming

resumes. Both streaming light indicators (g)

should be solid blue during streaming.

If the uTV 2 status light (g):

● is green, make sure TV sound and headset

are switched on.

● blinks blue, you are in paused mode. Press

the headset main button ( ) to resume

streaming.

1312

Compliance information

Declaration of Conformity

Hereby Unitron declares that this Unitron product is in

compliance with the essential requirements of the Radio

and Telecommunications Terminal Equipment Directive

1999/5/EC. The full text of the Declaration of Conformity

can be obtained from the manufacturer or the local

Unitron representative whose address canbe taken from

the list on www.unitron.com (worldwide locations).

(a)

fig. 7

Step 6: Switching off uTV 2

To switch off the devices:

● To end the transmission of the TV audio signal,

switch off the uTV 2 by pressing the ON/OFF button

(a) as shown in fig. 7.

If no audio input is available, the uTV 2

automatically stops the Bluetooth audio

transmission to headset after 5 minutes.

Its status light will blink green.

1514

- Reorient or relocate the receiving antenna.

- Increase the separation betweenthe device and

receiver.

- Connect the device into anoutlet on a circuit

different from that to which the receiver is connected.

- Consult the dealeroranexperienced radio/TV

technician for help.

Notice 4:

FCC/IC RF Radiation Exposure Statement

This equipment complies with FCC/IC radiation

exposure limits set forth for an uncontrolled

environment. End users must follow the specific

operating instructions for satisfying RF exposure

compliance. This transmitter must not be co-located

or operating in conjunction with any other antenna or

transmitter.

More details can be found in the data sheet which can

be downloaded from www.unitron.com.

Notice 1:

This device complies with Part 15 of the FCC Rules and

with RSS-210 of Industry Canada. Operation is subject to

the following two conditions:

1.)

this device may not cause harmful interference,and

2.)

this device must accept any interference received,

including interference that maycause undesired

operation.

Notice 2:

Changes or modiﬁcations made tothis device not expressly

approved by Unitron may void the FCC authorization to

operate this device.

Notice 3:

This device has beentestedand found tocomply with the

limits for a Class B digital device,pursuant to Part 15 of the

FCC Rules and ICES-003 of Industry Canada.

These limits are designed toprovide reasonable protection

against harmful interference in a residential installation. This

device generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

device does cause harmful interference to radio or television

reception, which can be determined by turning the equipment

off and on, the user is encouragedtotry tocorrect the

interference by one or more of the following measures:

1514

The symbol with the crossed-out garbage

bin is to make you aware that this device

may not be thrown away as normal household

waste.

Please dispose of old or unused device, at waste

disposal sites intended for electronic waste, or

give your device to your hearing care professional

for disposal. Proper disposal protects the

environment and health.

The Bluetooth®word mark and logos are registered

trademarks owned by Bluetooth SIG, Inc. and any

use of such marks by Unitron is underlicense. Other

trademarks and trade names are those of their

respective owners.

Australian EMC and Radiocommunications

compliance label

The CE symbol is conﬁrmation by Unitron that this

Unitron product meets the requirements of the

R&TTE Directive 1999/5/EC on Radio and

Telecommunication Terminal Equipment. The numbers

afterthe CE symbol are the numbers of consulted certiﬁed

bodies under the above mentioned directives. The alert sign

means that potential restrictions on its use are applicable in

one or more EU Member States.

This device is a class 2 device and can be operated in the

EU member states without restrictions for indoor use, but

must not operated outdoors in France.

Operating conditions:

This device is designed such that it functions without

problems or restrictions if usedas intended, unless

otherwise noted in these userguides.

0°to 55° Celsius and relative humidity of <95% (non

condensing).

Transport andstorage conditions:

During transport or storage, the temperature should

not exceedthe limit values of –20°/60° Celsius and

relative humidity of 90%for a long period of time.

The air pressure between 500 and 1100 hPa is

appropriate.

0678

www.unitron.com

10-035 029-5836-02

DISTRIBUTOR

Unitron Hearing Ltd.

20 Beasley Drive, P.O. Box 9017,

Kitchener, ON N2G 4X1Canada

European Representative

Max-Eyth-Straße 20,70736

Fellbach-Oefﬁngen, Germany
