Unitech TB80 Manuel utilisateur
TB80 Quick Start Guide
EN
FR
DE
P. 2
P.25
P. 46
EN P. 70 Additional Information
Rugged Ta blet
As we are often updating and improving our products, your device’s software may have
a slightly different appearance or modified functionality than presented in this Quick
Start Guide.
EN
Table of contents
Package Contents
4
Description of the tablet
5
Inserting mini SIM & Micro-SDcards
8
Windows
Getting started
10
Connecting to aWiFi
12
Getting familiar with Windows 10
13
The Windows 10interface
14
Windows notificationcenter
16
Android
Getting started
18
4G &WiFi connections
20
Google &Contacts
22
Hints &tips 24
EN
Package Contents
Check your product box for the following items:
-Fieldbook K80 withhand strap
-Active Stylus pen
-Battery for stylus pen
-Micro USBcable
-USB host cable
-AC adapter with EU, UK and US plug
The items supplied with your device and available accessories may vary depending on
your region or service provider.
The supplied items are designed only for your device and may not be compatible with
other devices.
Unapproved accessories may cause your device to malfunction.
3
4
Description of the tablet
1 2 3 4 5
6
7
8
1Function buttonF
2Power On/Off
3Volume +
4Volume -
5
6
7
8
Barcode scanner (option)
Front camera
Touchscreen
Pogo connector
5
EN
Description of the tablet
9
10
11
12
13
14
15
16
9 Kensington Lock
10 Audiojack
11HDMIport
12 USB port
13 USB port
14 DC-In
15SIM card slot
16 SD card slot
6
17 Rear camera
18Hand strap fixationpoints Cord fixation point
19 RFIDarea
20
17
19
18
20
7
EN
Inserting mini SIM & Micro-SD cards
WARNING: Make sure to turn off your device before inserting aSIM or memory card.
Opening
Pull to open the rubber cover.
Inserting the mini SIMcard
The slot accepts only mini SIM cards. Insert them with the contact side down into the
SIM slots like shown in the picture on the right.
Inserting a SDcard
Insert the micro SD card like show in the picture on the right.
Closing
Push the rubber cover back into place to ensure the IP rating of the unit.
Tip:
For the SIM card, aPin number may be requested. Enter the SIM card pin number and
tapOK.
8
9
EN
TurnON
1. Press and hold the ON/OFF button to turn on the device.
TurnOFF
1. Click on theWindows symbol on the lower left corner of the screen.
2. Select the Power button ,then select Shut down.
Initialsetup
The first time you start up your device, the Windows Startup Screen will be the first
screen displayed. Follow the on-screen instructions on each screen in order to properly
install the operating system. We strongly recommend that you create a Microsoft
account, so you can enjoy more features.
Windows // Getting started
Tip:
If the Fieldbook is used by more than one person, it is recommended to create an user
account for each person. Every user can set its default parameters to his needs.
10
Microsoft account
A Microsoft account is an email address and password that you use to sign in to
Windows. It’s free and easy to set up, and you can do so with any email address you
choose, or get anew email address (for example, you can use an Outlook.com, Gmail, or
Yahoo! address for your Microsoft account.). With aMicrosoft account, you can:
-get apps from the Windows Store
-back up all your important data and files using free cloud storage
-link your social networking accounts to the People app, and you’ll see
your friends’ contact info and status updates in one place
For detailed information about how to use Windows 10, please visit:
http://windows.microsoft.com/en-us/windows-10/getstarted-get-to-know-windows-10
