Unit UVC-5220 Manuel utilisateur
СОДЕРЖАНИЕ / CONTENTS
Safety precaution............................................................................... 4
Contents of delivery .......................................................................... 4
Device description............................................................................. 5
Charging the battery.......................................................................... 6
Battery replacement.......................................................................... 6
Preparation for work ..........................................................................7
Operation of the device....................................................................8
Cleaning and maintenance...............................................................8
Cleaning the turbo brush..................................................................8
Specifications..................................................................................... 9
Меры предосторожности......................................................................10
Комплект поставки..................................................................................10
Устройство пылесоса......................................................................11
дка аккумулятора ............................................................................12
Замена аккумулятора .....................................................................12
Подготовка к работе.......................................................................13
Эксплуатация устройства .....................................................................14
Чистка и уход................................................................................... 14
Чистка турбощётки......................................................................... 14
Технические характеристики........................................................15
4
Rechargeable vacuum cleaner | UVC-5220
ENGLISH
Thank You for choosing appliance UNIT
SAFETY PRECAUTION
Please before operating the device, carefully read this manual. Save manual
during the entire operating time of the device.
1. Use a vacuum cleaner in accordance with the instructions contained in this manual.
2. The device is intended for household use only.
3. Before connecting the cleaner to the mains to charge the battery, make sure the
electrical parameters indicated on the sticker of the charger correspond to the pa-
rameters of the power supply in your house.
4. Do not immerse the cleaner in water or other liquids and do not spill liquids inside
the vacuum cleaner.
5. To avoid electric shock, do not use the charger with a damaged power cord. Upon de-
tection of damage to the power cord, you must contact the authorized service center.
6. Do not disassemble the device yourself, it may cause damage to the device.
7. Avoid using the device with children and persons with reduced physical, sensory and
mental abilities.
8. Do not allow children to play with the vacuum cleaner.
9. Do not leave the vacuum cleaner running unattended near children.
10. After charging battery, always disconnect the charger from the mains.
11. Avoid bumps and falls of vacuum cleaner, it can cause damage and breakage.
CONTENTS OF DELIVERY
• Vacuum cleaner
• Extension tube
• Turbo brush
• The combined nozzle for furniture/mini brush
• Crevice nozzle
• Accumulator
• Battery charger
• Instruction manual.
5
Rechargeable vacuum cleaner | UVC-5220
ENGLISH
DEVICE DESCRIPTION
1. Lock button of the dust collector
2. On/Off button
3. The vacuum cleaner’s body
4. Dust collector of cyclone type
5. The fixation button of extension tube.
6. Extension tube
7. The fixation button of brush.
8. Turbo brush
9. Cleaning area LED-light
10. Battery charger
11. Combined nozzle
12. Crevice nozzle
6
7
8
9
5
13
2
4
10 11 12
6
Rechargeable vacuum cleaner | UVC-5220
ENGLISH
CHARGING THE BATTERY
Before use, fully charge the battery.
To charge the battery, connect the vacuum cleaner to the mains using the charger.
When the battery is charging the red light is on.
When the battery is fully charged the indicator will become green.
The first charging is about 8 hours. Next time for the battery to be fully charged
4-5 hours will be enough.
BATTERY REPLACEMENT
Open the battery cover.
Remove the old battery.
Set new battery observing
the polarity
Close the battery cover.
7
Rechargeable vacuum cleaner | UVC-5220
ENGLISH
PREPARATION FOR WORK
1. Tightly connect the extension tube to the housing of the vacuum cleaner.
2. Set the turbo brush.
Removing the turbo brush, you can use the furniture nozzle or a combination nozzle. If necessary, you
can use the turbo brush without extension tube.
8
Rechargeable vacuum cleaner | UVC-5220
ENGLISH
OPERATION OF THE DEVICE
1. The battery should be fully charged.
2. To activate the vacuum cleaner, press and hold for 1 second the on/off button (2).
3. If you want to increase the suction power, press the power button (2) again.
4. After cleaning, press the button (2) to turn off the vacuum cleaner.
Cleaning area LED-light allows to clean half-light places under tables, beds and sofas better.
CLEANING AND MAINTENANCE
Control the filling of the dust collector. As soon as the amount of debris in the
container reaches the «Max» mark is required to clean the dust collector.
1. Turn off the vacuum cleaner.
2. Disconnect the extension tube and a turbo brush.
3. Press the button (1) to disconnect dust collector from the vacuum cleaner.
4. Click on the cover lock of dust collector. Open it and remove the debris.
5. Turn the lid of the filters and align the color label on the lid marked «Open» on the
housing of the dust collector.
6. Open the dust collector and remove all filters.
7. Rinse the filters and the housing of the dust collector under running water.
8. When the body of the dust collector and the filter has fully dried, assemble the dust
collector.
9. Install the lid of the filter housing of the dust collector and turn it until it stops by
aligning the color label on it labeled «Lock» on the body of the dust collector.
CLEANING THE TURBO BRUSH
1. Open the latch of the brush.
2. Remove the plastic bar, and then remove the brush.
3. Remove the tangled on the brush hair, thread and other debris.
4. Rinse the brush under running water and give it time to dry.
5. Install the brush into place and secure the latch.
9
Rechargeable vacuum cleaner | UVC-5220
ENGLISH
SPECIFICATIONS
Supply voltage .............................. 220-240 V/50 Hz
Power ................................................................... 150 W
Suction power........................................................60 W
Dust collector capacity ................................... 0,35 l
Battery ................................................................ Li-Ion
Voltage ................................................................ 22,2 V
Battery capacity ....................................... 2200 mAh
Full charge time ............................................. ~ 4-5 h
Noise level ......................................................... ≤70dB
Weight ................................................................. 2,6 kg
Size ................................................... 345х112х210 mm
The head office of the manufacturer : «UNIT Handelsgesellschaft G.m.b.H.»
131, Gersthofer Str., A-1180, Vienna, Austria
Exported by: «UNIT Electronics (H. K.) Limited»
3905 Two Exchange Square, 8 Connaught Place, Central, Hong Kong
Made in People’s Republic of China (P.R.C.)
This appliance is to be stored and used under the following conditions: temperature – not less than
+5°C; relative humidity - not higher than 80%; aggressive impurities in the air: not allowable.
As the Manufacturer is constantly working on the improvement of its products, the design and
technical specifications are subject to change without prior notice.
The product is certified.
10
Вертикальный аккумуляторный пылесос | UVC-5220
RUSSIAN
Благодарим Вас за то, что выбрали технику UNIT
МЕРЫ ПРЕДОСТОРОЖНОСТИ
Пожалуйста, перед началом эксплуатации устройства, внимательно про-
читайте настоящее руководство. Сохраняйте инструкцию в течение всего
времени эксплуатации устройства.
1. Используйте пылесос в соответствии с указаниями, изложенными в данном
руководстве.
2. Устройство предназначено только для домашнего использования.
3. Перед подключением пылесоса к электросети для зарядки аккумулятор, убеди-
тесь, что электрические параметры, указанные на наклейке зарядного устрой-
ства соответствуют параметрам вашей электросети.
4. Не погружайте пылесос в воду или другие жидкости и не допускайте попадания
жидкости внутрь пылесоса.
5. Во избежание поражения электрическим током не используйте зарядное
устройство с повреждённым сетевым шнуром. При обнаружении повреждения
сетевого шнура необходимо обратится в сертифицированный сервисный центр.
6. Не разбирайте устройство самостоятельно, это может привести к его выходу из
строя.
7. Не допускайте использования устройства детьми и лицами с ограниченными
физическими, сенсорными и умственными способностями.
8. Не позволяйте детям играть с пылесосом.
9. Не оставляйте работающий пылесос без присмотра рядом с детьми.
10. При завершении заряда аккумулятора всегда отключайте зарядное устройство
от электросети.
11. Не допускайте ударов и падения пылесоса, это может привести к его поврежде-
нию и поломке.
КОМПЛЕКТ ПОСТАВКИ
• Пылесос
• Удлинительная труба
• Турбощётка
• Комбинированная насадка для мебели/мини-щётка
• Щелевая насадка
• Аккумулятор
• Зарядное устройство
• Инструкция по эксплуатации.
