UNIS TICKET DOME Manuel utilisateur

Operation Manual

IMPORTANT

Treasure Dome RFID Prototype Manual

11/15/2019

WE ARE HERE TO ASSIST

For parts and service

Have Questions? Contact us!

UNIS SERVICE CENTER

Tel: 972-241-4263

Email: service@unispartsandservice.com

Treasure Dome RFID Prototype Manual

11/15/2019

CONTENT

IMPORTANT SAFETY INSTRUCTIONS.......................................................................3

1. SPECIFICATIONS....................................................................................................5

2. CONTENTS OF THE ACCESSORY KIT................................................................... 6

3. PART NAME............................................................................................................7

4. SET UP & INSTALLATION...................................................................................... 8

5. HOW TO PLAY......................................................................................................16

6. GAME OPTION..................................................................................................... 17

7. TROUBLESHOOTING............................................................................................25

8. MAINTENANCE & INSPECTION..........................................................................25

9. OVERALL CONSTRUCTION................................................................................. 26

10. WIRING DIAGRAM............................................................................................37

Treasure Dome RFID Prototype Manual

11/15/2019

Thank you for purchasing Ticket Dome RFID. We hope you enjoy the product.

This manual contains valuable information about how to operate and maintain your game

machine properly and safely. It is intended for the owner and/or personnel in charge of

product operation. Carefully read and understand the instructions.

If you need any help during installation and setup please utilize this manual and

troubleshooting guide. If the product fails to function properly, non-technical personnel

should under no circumstance attempt to service the machine. Contact your distributor or

manufacturer for help.

Before use, please read IMPORTANT SAFETY INSTRUCTIONS.

IMPORTANT SAFETY INSTRUCTIONS

To ensure the safe usage of this product, carefully read and

understand these instructions before operating your game.

Save these instructions for future reference.

Use this product only as described in this manual. Other uses not recommended may

cause fire, electric shock or personal injury. Unplug the game from the outlet when not in

use, when moving from one location to another, and before cleaning/servicing.

Explanations which require special attention are indicated by signs of warning. Depending

on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.

NOTE: A NOTE indicates useful hints or information about product usage.

NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.

WARNING: A WARNING indicates a potential for product damage or serious personal Injury.

It is important to understand the meaning of the following HAZARD SIGNS before

continuing:

High Voltage and Shock Hazard:

High voltage can cause electric shock.

Turn off/unplug power before servicing.

High Temperature Hazard:

This part may cause scalding.

Do not touch. Surface may be hot.

No Touching Hazard:

This part may be hot or can cause electric shock.

Do not touch.

Treasure Dome RFID Prototype Manual

11/15/2019

Use the following safety guidelines to help ensure your own personal safety and to help

protect your equipment and surrounding environment from potential damage.

This product is an indoor game machine. Do not install outdoors.

Avoid installing in the following places to prevent fire, electric shock, injury

and/or machine malfunctioning:

Places subject to rain/moisture, or places subject to high humidity.

Places subject to direct sunlight, or places subject to extremely hot or cold

temperatures to ensure that it is used within the specified operating range.

Places where inflammable gas may be present or in the vicinity of highly

inflammable/volatile chemicals or items that can easily catch fire.

On unstable or sloped surfaces. The machine may topple or cause unforeseen

accidents.

Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.

IMPORTANT NOTE:

ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.

FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL

RISKS.

Note: The contents of this manual may be updated without notice.

Treasure Dome RFID Prototype Manual

11/15/2019

1. SPECIFICATIONS

Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz

Min. Power consumption: 240W

Max. Power consumption: 350W

Dimension:Width: 58.66’’ (1490mm)

Depth: 58.66’’ (1490mm)

Height: 56.92’’(1446mm)

Weight：Approximately 380.37 lb (345kg)

Model No: T-351

NOTICE: After turning off the game, please wait at least 1 minute

before restarting again.

Note: Game specifications are subject to change without notice.

Treasure Dome RFID Prototype Manual

11/15/2019

2. CONTENTS OF THE ACCESSORY KIT

Open the package and make sure all the items are included:

Following accessories

NOTE: Part models are subject to change without notice.

No.

Name

Spec.

Qty


Manual

English

Key

171A

Key

171B

Power cord

1.8M

Fuse

6.3A

Micro Switch

D3V-6G-1C24

Optical coupler

Extended line

1.2M (Maintenance and use)

Treasure Dome RFID Prototype Manual

11/15/2019

3. PART NAME

Key Components

Button

Speaker

Coin mechanism

Ticket dispenser

Marquee

Scoop

Treasure Dome RFID Prototype Manual

11/15/2019

leveler

4. SET UP & INSTALLATION

This product is an indoor game machine. Do not install outdoors.

Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid

Place the unit on a dry level surface

Ventilation openings in the back of the unit must not be obstructed by objects or by

wall.

4.1 Transporting the Game

If you need to move the game, adjust the levelers back to an “up” position.

NOTICE

Be careful not to damage the machine during transport.

Always unplug the game before moving.

For longer distance transport, package the game properly to prevent damages.

Please keep the machine in upright position during transport.

We do not recommend using power tools as they may cause damage.

NOTICE

Treasure Dome RFID Prototype Manual

11/15/2019

leveler

This procedure requires 4 people assistance.

4.2 Level Adjustment

Install this game on a flat surface. If the game is installed on an unsuitable floor, it could

cause game malfunction.

To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it

touches the floor, lifting the casters off the ground by 0.2 in. Repeat the same for all

levelers.

NOTICE

Make sure the machine is level.
