Uniden NVR - 8 Manuel utilisateur

App Cam 4K

NVR - 8/16

Quick Start Guide

What’s in the Box

HDMI Cable

1m Ethernet CableApp Cam 4K NVR

NVR Power Adaptor

Quick Start Guide

USB Mouse

General Introduction

USB Port

HDD LED

Control Panel

USB Port

Audio Out

Power Input

HDMI Port

VGA Port

PoE Ports*

DC48V

AUDIO

OUT USB HDMIVGALAN

3 5 7

4 6 8

11 13 15

12 14 16

ONOFF

PWR HDD

QUAD MENU SELECT

Power LED

Power Switch

LAN Port

Note: App Cam 4K NVR-8 has only 8 x PoE Port while App Cam 4K NVR-16 has 16x PoE Port.

The actual appearance and components may vary.

Connection Diagram

Connect the NVR (LAN port) to

your router with an Ethernet cable.

Next, connect the mouse to the

USB port of the NVR.

DC48V

AUDIO

OUTUSB HDMI VGA LAN

357

468

11 13 15

12 14 16

ONOFF

5 7

6 8

11 13 15

12 14 16

DC48V

AUDIO

OUTUSB HDMI VGA LAN

ONOFF

3 5 7

4 6 8

DC48V

AUDIO

OUTUSB HDMI VGA LAN

ONOFF

HMDI VGA

Note:

There is no router and VGA cable

included in the package.

Connect the NVR to the monitor

with a VGA or HDMI cable.

Connect cameras to PoE ports on

the NVR.

DC48V

AUDIO

OUTUSBHDMI VGA LA N

eSATA

3 5 7

4 6 8

11 13 15

12 14 16

ONOFFReset Button

DC Power

Network (LAN)

DC48V

AUDIO

OUTUSBHDMI VGA LAN

3 5 7

4 6 8

11 13 15

12 14 16

ONOFF

Note: Cameras are not included in the package. App Cam 4K Bullet and App Cam 4K Dome

cameras are compatible with Uniden App Cam 4K NVR.

Connect the NVR to a power outlet

and turn on power switch.

A setup wizard will guide you through the NVR system conguration process. Please set a password

for your NVR (for the initial access) and follow the wizard to congure the system. The password

should be at least 6 characters. It is recommended that you note down the password and keep it in a

secure place. If you lost the password, please contact Undien customer for support.

Access the NVR via App

Before accessing the NVR via app, please set up the system password before adding the NVR to the

app to ensure smooth set up.

Search “Uniden Solo” in App Store (for iOS) or Google Play (for Android), download and install the app.

Launch the Uniden App, add the system and follow the instructions on the app to access the NVR.

Set up PoE NVR System

No Video Output on the Monitor

If there’s no video output on the monitor from Uniden, please try the following solutions:

• TV/monitor resolution should be at least 720p or above.

• Double check the HDMI/VGA connection, or swap another cable or monitor to test.

• Make sure your NVR is powered on.

Failed to Access the PoE NVR Locally

If you failed to access the PoE NVR locally via App, please try the following solutions:

• Connect the NVR (LAN port) to your router with a network cable.

• Swap another Ethernet cable or plug the NVR to other ports on the router.

• Go to Menu -> System -> Maintenance and restore all settings.

Failed to Access the PoE NVR Remotely

If you failed to access the PoE NVR remotely via App, please try the following solutions:

• Make sure you can locally access this NVR system.

• Please connect your phone ounder the same network (LAN) of your NVR and see if you can visit any

website to verify whether there is Internet access available.

• Please reboot your NVR and home router and try again.

If there are more support needed, please contact Uniden Support.

Troubleshooting

Model App Cam 4K NVR-8

Video & Audio

Input

IP Video Input PoE IP Camera x 8

Audio Input Cameras with Built-in Mic

Video & Audio

Output

HDMI Output 3840x2160, 1920x1080, 1440x900, 1280x1024, 1280x800, 1280x720,

1024x768

VGA Output 1920x1080, 1440x900, 1280x1024, 1280x800, 1280x720, 1024x768

Audio Output 1CH RCA

Decoding

Live View/Playback Resolution 3840x2160, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080p,

720p

Video Format H.264/H.265

Synchronous Playback Up to 4 Channels

HDD Capacity 2TB

External

Interface

USB Port 2 x USB 2.0

Lan Port 1 x RJ45 10M/100M Ethernet

PoE Port 8 x RJ45 10M/100M PoE Ethernet IEEE 802.3 at

General

PoE Power up to 25W

Power Input DC 48V/2A

Power Consumption up to 95w

Operating Temperature -10°C~+45°C

Operating Humidity 10% to 90%

Specications

Model App Cam 4K NVR-16

Video & Audio

Input

IP Video Input PoE IP Camera x 16

Audio Input Cameras with Built-in Mic

Video & Audio

Output

HDMI Output 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768

VGA Output 1920x1080, 1280x1024, 1280x720, 1024x768

Audio Output 1CH RCA

Decoding

Live View/Playback Resolution 3840x2160, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080p,

720p

Video Format H.264/H.265

Synchronous Playback Up to 4 Channels

HDD Capacity 3TB

External

Interface

USB Port 2 x USB 2.0

Lan Port 1 x RJ45,10M/100M Ethernet

PoE Port 16 x RJ45 10M/100M PoE Ethernet IEEE 802.3 af/at

General

PoE Power up to 25W

Power Input DC 48V/2.5A

Power Consumption up to 95w

Operating Temperature -10°C~+45°C

Operating Humidity 10% to 90%

Uniden App Cam 4KNVR-8/16

Terms of Warranty: Uniden Aust warrants to the original retail purchaser only that the Uniden App Cam 4KNVR-

8/16 (“the Product”), will be free from defects in materials and craftsmanship for the duration of the warranty period,

subject to the limitations and exclusions set out below.

Warranty Period: This warranty to the original retail purchaser is only valid in the original country of purchase for a

Product first purchased either in Australia or New Zealand and will expire, as indicated below, from the date of original

retail sale.

Product 1 Year

Accessories 90 Days

If a warranty claim is made, this warranty will not apply if the Product is found by Uniden to be:

A. Damaged or not maintained in a reasonable manner or as recommended in the relevant Owner’s Manual;

B. Modified, altered or used as part of any conversion kits, subassemblies or any configurations not sold by Uniden

Aust;

C. Improperly installed contrary to instructions contained in the relevant Owner’s Manual

D. Repaired by someone other than an authorized Uniden Repair Agent in relation to a defect or malfunction

covered by this warranty; or

E. Used in conjunction with any equipment, parts or a system not manufactured by Uniden.

Important:

Satisfactory evidence of the original purchase is required for warranty service. Please refer to our Uniden

website for any details or warranty durations offered in addition to those contained below.

Warrantor:

The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”).

WARRANTY
