Umbrella Mesh Network Umbra Legacy Manuel utilisateur
1
To arm enre system—both interior and perimeter
• Close all windows and doors (the status screen will say “OF” - if any numbers are
shown, those sensors will need to be closed)
• Using App—Press the Padlock/Home Icon on your App and select “Away Arm” from
the menu
• Using Keyfob—Press the Locked Padlock on your keyfob
• Using Keypad—Press and hold the “AWAY” Padlock for 2 seconds
• On Umbra Legacy Panel—Press and hold the “AWAY” Padlock for 2 seconds
• The system will display “ON” and begin exit countdown
• Exit premises before the delay expires
To disarm system when you return
• When you enter through the door, the keypad will emit the entry delay tone
• Using App—Press the Padlock/Home icon on your App and select “Disarm” from the
menu
• Using Proximity Card—Present your proximity tag to the reader area of the panel
• Using Keyfob—Press the Unlock Padlock on your keyfob
• Using Keypad—Enter your 4 –digit user code followed by the “DISARM” Unlock icon,
or present your user proximity tag within the entry delay. (If the keypad is baery on-
ly—press and hold the * key for 2 seconds to acvate proximity reader)
• If you make an error, press the “*” key and try again.
• The system will display “OF” when disarmed
To arm perimeter of building and sll move freely inside
• Close all windows and doors (the status screen will say “OF” - if any numbers are
shown, those sensors will need to be closed)
• Using App—Press the Padlock/Home Icon on your App and select “Home Arm” from
the menu
• Using Keyfob—Press the Home Icon on your keyfob
• Using Keypad—Press and hold the “HOME” Icon for 2 seconds
• On Umbra Legacy Panel—Press and hold the “HOME” icon for 2 seconds
Umbra Legacy
User Quick guide - Brought to you by Umbrella Mesh Network
Umbrella Mesh Network, LLC
510 W. Amador Ave., Las Cruces, NM 88005
(855) 602-5276 Ben@umbrellameshnetwork.com
2
Know your alarm:
Umbra Legacy Panel
Keypad (Hold * to acvate Prox)
Keyfob
Prox tag
(Disarm)
Power
Arm
Alarm
WiFi
App
Away Stay Enroll WiFi SOS
Arm Away
Disarm
Arm Stay
SOS
Arm Away
Disarm
Arm Stay
SOS
Arm Away
Arm Stay
& Disarm
Umbra Legacy
User Quick guide - Brought to you by Umbrella Mesh Network
Umbrella Mesh Network, LLC
510 W. Amador Ave., Las Cruces, NM 88005
(855) 602-5276 Ben@umbrellameshnetwork.com
3
Umbra Legacy
User Quick guide - Brought to you by Umbrella Mesh Network
Umbrella Mesh Network, LLC
510 W. Amador Ave., Las Cruces, NM 88005
(855) 602-5276 Ben@umbrellameshnetwork.com
Know your alarm: Zone List
Circle Applicable
Zone # Descripon Arm Home Arm Away Type
1Yes / No Yes / No Wireless
2Yes / No Yes / No Wireless
3Yes / No Yes / No Wireless
4Yes / No Yes / No Wireless
5Yes / No Yes / No Wireless
6Yes / No Yes / No Wireless
7Yes / No Yes / No Wireless
8Yes / No Yes / No Wireless
9Yes / No Yes / No Wireless
10 Yes / No Yes / No Wireless
11 Yes / No Yes / No Wireless
12 Yes / No Yes / No Wireless
13 Yes / No Yes / No Wireless
14 Yes / No Yes / No Wireless
15 Yes / No Yes / No Wireless
16 Yes / No Yes / No Wireless
17 Yes / No Yes / No Wireless
18 Yes / No Yes / No Wireless
19 Yes / No Yes / No Wireless
20 Yes / No Yes / No Wireless
21 Yes / No Yes / No Wireless
22 Yes / No Yes / No Wireless
23 Yes / No Yes / No Wireless
24 Yes / No Yes / No Wireless
25 Yes / No Yes / No Wireless
26 Yes / No Yes / No Wireless
27 Yes / No Yes / No Wireless
28 Yes / No Yes / No Wireless
29 Yes / No Yes / No Wired/Wireless
30 Yes / No Yes / No Wired/Wireless
31 Yes / No Yes / No Wired/Wireless
32 Yes / No Yes / No Wired/Wireless
